6.2. Connector Descriptions

X1 Power Input
Pin Signal
1 8-30V DC-Input
X2 ATX Connector
Pin Signal
1 +3.3V
3 GND
5 GND
7 GND
9 +5VSB
11 +3.3V
13 GND
15 GND
17 GND
19 +5V
X11 LVDS
Pin Signal
1 LVDS_A0-
3 GND
5 LVDS_A1-
7 LCD BKL (dep. J5)
9 LVDS_A2-
11 LCD VDD (dep 3)
13 LVDS_A3-
15 NC
NC
17
19 LVDS_Clock-
The LVDS interface works only if the J6 Jumper is not installed.
X14 Video Input Channel
Pin Signal Name
1 Video Signal
2 Ground
The Video IN interface works only if the J6 Jumper is installed.
Pin Signal
2 Ground
Pin Signal
2 +3.3V
4 +5V
6 +5V
8 PWR-OK
10 +12V
12 -12V
14 PS-ON#
16 GND
18 -5V
20 +5V
Pin Signal
2 LVDS_A0+
4 GND
6 LVDS_A1+
8 LCD BKL (dep. J5)
10 LVDS_A2+
12 LCD VDD (dep 3)
14 LVDS_A3+
16 NC
NC
18
20 LVDS_Clock+
Function in/out
CVBS In
