Nortel 1120E User Manual

Nortel IP Phone 1120E features
• Four user-defined feature keys with labels and indicators
• Four soft keys
• Graphical, high-resolution LCD display, backlit, with adjustable contrast
• High-quality speaker phone
• Volume control keys for adjusting ringer, speaker, handset, and headset volume
• Six specialized feature keys:
— Quit, Directory, Message/Inbox, Shift/Outbox, Services, Copy
• Six call-processing fixed keys:
— Mute, Handsfree, Goodbye, Expand to PC, Headset, Hold
• Gigabit Ethernet ports
• Built-in gigabit Ethernet switch for shared PC access
• Headset jack with an On/Off key
• USB port to support a keyboard or mouse
• Automatic network configuration
• Graphical XAS
• Hearing-aid compatibility
User-defined feature keys
Feature Status Lamp*
Handset
Speaker
Copy key
Services key
Quit/Stop key
Volume control
Mute key
Handsfree key
Dialpad
Figure 2
*Note: If supported by your server, the Feature Status Lamp provides a user-defined alert.
Connectors Contact your system administrator to find out if this feature is available for you.
Expansion module port*
PC Ethernet port
LAN Ethernet port
Tilt lever
Link lamp
USB connector AC adapter jack
Headset jack
Handset jack
Nortel IP Phone 1120E Emissions Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures: reorient or relocate the
receiving antenna, increase the separation between the equipment and receiver, connect the
equipment into an outlet on a circuit different from that to which the receiver is connected, or
consult the dealer or an experienced radio or TV technician for help.
The user should not make changes or modifications not expressly approved by Nortel Networks.
Visual Alerter/Message Waiting
indicator Any such changes could void the user's authority to operate the equipment.
This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la
classe B est conforme à la norme NMB-003 du Canada.
High-resolution
graphical display screen
This device complies with the essential requirements and other relevant provisions of R&TTE
Soft keys directive 1999/5/EC. A copy of the Declaration may be obtained from Nortel Networks GmbH
Navigation keys
address: Ingolstaedter Strasse 14-18, 80807 Munich Germany.
Message/Inbox key
Shift/Outbox key
Use only with Nortel-approved Limited Power Source (output rated 48 V DC, 520mA.) OR using
Directory key
Power over LAN options, including standard power over Ethernet.
Enter key
Goodbye key
この装置は、情報処理装置等電波障害自主規制協議会（ＶＣＣＩ）の基準に基づくクラス B 情
Expand to PC key
報技術装置です。この装置は、家庭環境で使用することを目的としていますが、この装置がラ
Headset key
ジオやテレビジョン受信機に近接して使用されると、受信障害を引き起こすことがあります。
Hold key
取扱説明書に従って正しい取り扱いをして下さい。
Warning: The earpiece/mouthpiece region on the handset can attract and retain small objects.
Privacy of communications may not be ensured when using this telephone. To prevent radio
interference to the licensed service, this device must be operated indoors only and should be kept
away from windows to provide maximum shielding.
Date: June 2007
Document Release: Standard 01.01
Document Number: NN43112-100
Copyright © 2007 Nortel Networks.
All rights reserved.
* Nortel, the Nortel logo, and the Globemark are trademarks of Nortel Networks.
To provide feedback or report a problem in this document, go to www.nortel.com/documentfeedback.
Regulatory Information
IP Phone 1120E
Getting Started
