Authentic Hendrix
'68 Shrine Series
Band of Gypsys
Fuzz Face Distortion
This special edition of the Band of Gypsys Fuzz
pays tribute to the legendary Jimi Hendrix with a
custom finish that remixes prolific and celebrated
rock artist John Van Hamserveld's famous 1968
Shrine Auditorium concert poster art. Packed into
an MXR mini housing, this pedal is based on a
mysterious Fuzz Face Distortion that Jimi Hendrix
used at several iconic shows between 1969 and
1970, most notably the historic Band of Gypsys
performance. Red with white knobs, this particular
fuzz sounded like a completely different animal
from any of the other Fuzz Face pedals in his
arsenal, snarling with an aggressive, biting tone.
jimdunlop.com/jhms4
®
JHMS4

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Authentic Hendrix 68 Shrine Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Dunlop Authentic Hendrix 68 Shrine Series

  • Page 1 JHMS4 Authentic Hendrix ™ ‘68 Shrine Series Band of Gypsys ™ Fuzz Face Distortion ® This special edition of the Band of Gypsys Fuzz pays tribute to the legendary Jimi Hendrix with a custom finish that remixes prolific and celebrated rock artist John Van Hamserveld’s famous 1968 Shrine Auditorium concert poster art.
  • Page 2 External Controls 1 OUTPUT knob controls overall volume of effect 2 TONE knob shapes EQ of effect 3 FUZZ knob controls intensity of fuzz effect 4 FOOTSWITCH toggles effect on/bypass (blue LED indicates on) JHMS4 | AUTHENTIC HENDRIX ’68 SHRINE SERIES BAND OF GYPSYS FUZZ 2 ™...
  • Page 3 Run a cable from your guitar to JHMS4’s INPUT jack and ™ ® another cable from JHMS4’s OUTPUT jack to your amplifier. Fuzz is powered by the Dunlop ECB003 9-volt adapter or an MXR Brick Series power supply (each sold Start with OUTPUT, TONE, and FUZZ controls at 12 o’clock.
  • Page 4 Specifications Input Impedance 30 kΩ Output Impedance Max Volume 33 kΩ Mid Volume 80 kΩ Noise Floor* -83 dBV Bypass True Hardwire Current Draw 4.3 mA Power Supply 9 volts DC JHMS4 | AUTHENTIC HENDRIX ’68 SHRINE SERIES BAND OF GYPSYS FUZZ 4 ™...
