Authentic Hendrix
'68 Shrine Series
Uni-Vibe Chorus/Vibrato
This special edition of the Uni-Vibe Chorus/Vibrato
pays tribute to the legendary Jimi Hendrix with a
custom finish that remixes prolific and celebrated
rock artist John Van Hamserveld's famous 1968
Shrine Auditorium concert poster art. Packed
into an MXR mini housing, this pedal delivers the
thick wash of tones and textures that permeate
the landmark Band of Gypsys album in all of their
stunning analog glory at a fraction of the size of
the vintage Shin-ei unit that Jimi Hendrix used
from 1969 to 1970.
jimdunlop.com/jhms3
®
JHMS3

Advertisement

loading
Need help?

Need help?

Do you have a question about the Authentic Hendrix 68 Shrine Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Dunlop Authentic Hendrix 68 Shrine Series

  • Page 1 JHMS3 Authentic Hendrix ™ ‘68 Shrine Series Uni-Vibe Chorus/Vibrato ® This special edition of the Uni-Vibe Chorus/Vibrato pays tribute to the legendary Jimi Hendrix with a custom finish that remixes prolific and celebrated rock artist John Van Hamserveld’s famous 1968 Shrine Auditorium concert poster art.
  • Page 2 External Controls 1 SPEED knob controls sweep rate of effect 2 LEVEL knob controls overall volume of effect 3 VIBE switch toggles between chorus mode and vibrato mode 4 DEPTH knob controls overall intensity of effect 5 FOOTSWITCH toggles effect on/bypass (white LED indicates on) JHMS3 | AUTHENTIC HENDRIX ’68 SHRINE SERIES UNI-VIBE CHORUS/VIBRATO 2...
  • Page 3 Run a cable from your guitar to the JHMS3’s INPUT jack ™ ® and run another cable from the JHMS3’s OUTPUT jack Chorus/Vibrato is powered by the Dunlop ECB003 to your amplifier. 9-volt adapter or an MXR Brick Series power supply ®...
  • Page 4 Specifications VIBE OFF Input Impedance 600 kΩ Output Impedance Full Volume 29 kΩ Half Volume 33 kΩ Max Input 0 dBV Max Output 8 dBV Noise Floor* -97 dBV Speed Control 0.5 Hz to 10.5 Hz Bypass True Hardwire VIBE ON Input Impedance 730 kΩ...
