Mechanical Information
14 Pinout
14.1 Three-Pins Header - J1
Pin
Function
1
OFF
2
GND
3
VRTC
14.2 Analog
Pin
Function
1
NC
2
IOREF
3
Reset
4
+3V3
5
+5V
6
GND
7
GND
8
VIN
9
A0
10
A1
11
A2
12
A3
13
A4
14
A5
15
A6
16
A7
17
A8
18
A9
19
A10
20
A11
21
DAC0
22
DAC1
23
CANRX
24
CANTX
14 / 21
Type
Digital
Power
Reset
Type
Description
NC
Not Connected
IOREF
Reference for digital logic V - connected to 3.3V
Reset
Reset
Power
+3V3 Power Rail
Power
+5V Power Rail
Power
Ground
Power
Ground
Power
Voltage Input
Analog
Analog input 0 /GPIO
Analog
Analog input 1 /GPIO
Analog
Analog input 2 /GPIO
Analog
Analog input 3 /GPIO
Analog
Analog input 4 /GPIO
Analog
Analog input 5 /GPIO
Analog
Analog input 6 /GPIO
Analog
Analog input 7 /GPIO
Analog
Analog input 8 /GPIO
Analog
Analog input 9 /GPIO
Analog
Analog input 10 /GPIO
Analog
Analog input 11 /GPIO
Analog
Digital to Analog Converter 0
Analog
Digital to Analog Converter 1
Digital
CAN Bus Receive
Digital
CAN Bus Transfer
Arduino® GIGA R1 WiFi
Arduino® GIGA R1 WiFi
Description
3V3 Enable Pin (U6)
Ground
Real Time Clock Battery
Modified: 01/03/2023
