IRSAP TESI3 EH-600-8 Instructions Manual

STEEL MULTI COLUMN
Please read these instructions and terms and conditions carefully prior to installation. Failure to do so may invalidate the warranty.
Drawings
Bracket Positions
Wall Ties should be logically positioned to
prevent Steel Multi Column from falling
away from the wall, usually in line with Wall
x x
Brackets. If more than 2 brackets have been
supplied these should be spaced evenly.
= typical Wall Bracket positions
x
= typical Wall Tie positions
Mounting Options
Depending on which mounting option you have chosen you will receive the correct number of brackets / feet from one of the following;
+
1 - Standard Wall Brackets 2 - Stud Wall Brackets
+
F3
30 - 40 mm
F2
F1
F1 = 780 N
F2 = 400 N F3
30 - 40 mm
Pipe Centres
F2
F1
F1 = 780 N
F2 = 400 N
Pipe centres left to right = width of radiator plus valves
Pipe centres from wall =
10
Mounting Option
Standard Wall Brackets
64mm - 74mm
10
Stud Wall Brackets 70mm- 80mm
Floor Mounts / Slip on Feet / Cast Feet 64mm - 74mm
MCF_SS_1.2
Fitting Instructions
3 - Floor Mounts
If ordered position
evenly between
sections beneath
the radiator.
2 Columm 3 Columm 4 Columm
82mm - 92mm 102mm - 112mm 120mm - 130mm 140mm - 150mm
70mm- 80mm 95mm-130mm
82mm - 92mm 102mm - 112mm 120mm - 130mm 140mm - 150mm
Multi Column Orientation
Blanking Air vent
plug
Flow Return
Diverter position
4 - Slip on Feet
30mm
If ordered slip on
desired sections
105mm
evenly beneath
radiator.
104mm
5 Columm 6 Columm
95mm-130mm 129mm-148mm
(Horizontal & Vertical)
Wall Ties are supplied with every order
5 - Cast Feet
If ordered position
evenly between
100mm
sections beneath
the radiator.
1. Unpack & Inspect
This product should have reached you in perfect condition. Please carefully unpack & inspect
this radiator & all fittings. Your point of purchase must be notified of any shortages or damage
within 28 days of delivery.
Wall ties adjust from
32mm to 42mm
100mm
