Front Panel Without the Bezel
Figure 3 shows the front panel of the SCG without the bezel. For descriptions of the
numbered parts, refer to
Figure 3. SCG front panel without the bezel
1
2
Table 2. SCG front panel parts (without the bezel)
Number
1
2
3
4
5
SmartCell Gateway 200 Getting Started Guide for Release 1.1.2 (GA), 800-70508-001 Rev C
Table 2.
Description
ESD ground strap attachment
Hard drive bays (the SCG has two 600GB hard drives)
Control panel (buttons and status indicators, see
Front Panel" on page 8)
RJ45 serial port (COM2 / serial B). Use only the console cable provided to
connect this port to another device.
CAUTION!
The SCG has two RJ45 serial ports – one on the front panel and one on
the rear panel. You can only use one of these two ports at any given time.
Using them simultaneously will cause both serial ports to become
unresponsive.
USB port (not used)
Before You Begin
Get to Know the Physical Features of the SCG
4
3 5
"Control Panel on the
7
