PRODUCT MANUAL
PORTABLE SINGLE POST LIFT
Lifting Capacity: 6000lbs, Max. Lifting Height: 72"
MODEL: TMG-ALSP60
Please read the product manual completely before assembly
Check against the parts list to make sure all parts are received
Wear proper safety goggles or other protective gears while in assembly
Missing parts or questions on assembly?
Please call: 1-877-761-2819 or email: cs@tmgindustrial.com
Do not return the product to dealer, they are not equipped to handle your requests
WWW.TMGINDUSTRIAL.COM
Toll Free:1-877-761-2819

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TMG-ALSP60 and is the answer not in the manual?

Questions and answers

Related Manuals for TMG TMG-ALSP60

Summary of Contents for TMG TMG-ALSP60

  • Page 1 PRODUCT MANUAL PORTABLE SINGLE POST LIFT Lifting Capacity: 6000lbs, Max. Lifting Height: 72” MODEL: TMG-ALSP60 Please read the product manual completely before assembly Check against the parts list to make sure all parts are received Wear proper safety goggles or other protective gears while in assembly Missing parts or questions on assembly? Please call: 1-877-761-2819 or email: cs@tmgindustrial.com...

  • Page 2: Table Of Contents

    Content 1Safety ..................................3 1.1 Introduction ..............................3 1.2 Intended Use ............................... 3 1.3 Safety Instructions for Commissioning ....................3 1.4 Safety Instructions for Operation ......................3 1.5 Safety Instructions for Servicing ......................3 1.6 Safety Features ............................4 1.7 Warning Labels ............................4 1.8 Disposal of Used Oil ...........................

  • Page 3: 1Safety

    1. Safety 1.1 Introduction Thoroughly read this manual before operating the lift and comply with the instructions. Always display the manual in a conspicuous location. Personal injury and property damage incurred due to non-compliance with these safety instructions are not covered by the product liability regulations. 1.2 Intended Use This single column vehicle lift is classified as movable model.

  • Page 4: Safety Features

    1.6 Safety Features 1.6.1 Hold-to-run Type Control The operator is required to hold the controls in the engaged position to raise or lower the lift. 1.6.2 Equalizing System The lift is provided with distributing and connecting flow valve to ensure level movement of both carriages.
  • Page 5 WWW.TMGINDUSTRIAL.COM P05/21 Toll Free:1-877-761-2819...

  • Page 6: Disposal Of Used Oil

    1.8 Disposal of used oil Used oil, which is removed from the power unit and the plant during an oil change, must be treated as a polluting product, in accordance with the legal prescriptions of the country in which the lift is installed. 1.9 Machine demolition The machine must be demolished by authorized technicians, just like for assembling.
  • Page 7 1350-1840mm 1100mm 1300mm 1400-2060mm 1510-2210mm 1580-2325mm WWW.TMGINDUSTRIAL.COM P07/21 Toll Free:1-877-761-2819...

  • Page 8: Main Technical Mechanism Parameters Table

    3. Main Technical Mechanism Parameters Table 3.1 Products Specifications TMG-ALSP60 Lifting capacity: 6000lbs(2700kg) Max. lifting height 72”(1830 mm) Width of vehicle lifted ≤1800 mm Lifting speed 50mm/s Working voltage AC110V/60Hz, Single Phase Power 3HP(2.2kw) Safety catch Manual Noise <70 dB...

  • Page 9: Packing, Transport And Storage

    4. Packing, transport and storage Only skilled personnel who are familiar with the lift and this manual shall be allowed to carry out packing, lifting, handling, transport and unpacking operations. 4.1 Packing 90% components were pre-assembled before shipment, and packed with blister packing in wood carton. Arms, adapters and rubber pads were put in the lift.

  • Page 10: Installation

    5. Installation 5.1 Working Site The user should prepare the working site for the lift before its arrival 5.1.1 Power Source The working site must be equipped with certain power. Install safety distribution box with a 4-hole socket around the operation position. 5.1.2 Ground The lift must be placed on flat and hard ground, which is made of cement or bricks, with the load at the position of vertical post of 3t/m2.
  • Page 11 5.2.1 After unpacking, check the following components Description Quantity Description Quantity Stand column assembly Lifting frame assembly Power unit assembly Back arm assembly Tow truck assembly Under frame assembly Extension support Front arm assembly Back arm assembly WWW.TMGINDUSTRIAL.COM P11/21 Toll Free:1-877-761-2819...
  • Page 12 5.2.2 Installation Lifting Frame Assembly Choose a flat and empty site,open the package, find the under frame and lifting frame. Unit is heavy. Do not attempt to lift and remove the unit from the carton. Place the under frame(1) and lifting frame(12) on the ground Install longer arm(15) ,whirling arm(22）...
  • Page 13 Install the post(2) on the under frame(1), and tighten all bolts with under frame and lifting frame. Install the hydraulic tow truck(43) To avoid serious bodily injury or death,  and/or property damage. Do not exceed the rated load capacity. When not in use, do not allow heavy ...
  • Page 14 Install the power unit(49)， connect the hydraulic hose (50) from the power unit to cylinder(30) RISK OF EXPLOSION! This equipment has internal arcing or parts that may spark and should not be exposed to flammable vapors. Motor should not be located in a recessed area or below floor level.

  • Page 15: Operation Instruction

    6. Operation instruction 6.1 Operation Rules for mechanism System 6.1.1 The movable single column lift is provided with separate traveling mechanism. Shake the hauling handle of the steering rear wheel forwards and backwards to make the vertical column off the ground, then you can push or pull the lift.
  • Page 16 10) Pull the safety unlock handle to make the flitting platform unlocked. 11) To adjust lifting pad, turn it anticlockwise to make it rise ( adjustment distance of 100mm) 12) Press the button again and pay attention to lifting arm and the vehicle lifted until lifting is safe and reliable.

  • Page 17: Use Lifting Arm

    6.4 Use lifting arm 6.4.1 Movable Lift a. According to the position under the vehicle chassis where the lifting arm is located, the supporting arm on the lifting arm (close to the vertical post) may be pushed and pulled up and down or to left and right, as the following figure: b.

  • Page 18: Troubleshooting

    7. Maintenance 7.1.1 For daily maintenance and service of the lift, see operation steps, use and cautions described in the previous page. 7.1.2 The working environment and the surface of this machine should be cleaned usually. 7.1.3 During the use of this machine, if any oil leaking is found, check the leakage source. Check whether the screw of the hydraulic oil hose is tighten, if it is loosen, it should be tighten.

  • Page 19: Parts Breakdown

    9. Parts Breakdown 1. Exploded Drawing WWW.TMGINDUSTRIAL.COM P19/21 Toll Free:1-877-761-2819...

  • Page 20: Parts List

    2. Parts List Ref# Description Ref# Description Under frame Fixed pin Stand column Lower fixed seat Outer hexagon screw Nut M20 M16x45 Washer Ф16 Nut M8 Washer Ф12 Inner hexagon screw M8x25 Outer hexagon screw Draw-bar M12x30 Loading roller Washer Ø8 Bearing 62042RS Loading wheel Ø160x50 Shaft for front wheel...

  • Page 21: Hydraulic Diagram

    3. Hydraulic Diagram 1. Cylinder 2. Filter 3. Oil pump 4. Motor 5. One-way valve 6. Manual release valve 7. Throttle valve 8. Relief valve 9. Anti-leakage valve WWW.TMGINDUSTRIAL.COM P21/21 Toll Free:1-877-761-2819...
