BRAVOS
SECADORA ELÉCTRICA BRAVOS
SÉCHEUSE ÉLECTRIQUE BRAVOS
FOR QUESTIONS ABOUT FEATURES, OPERATION/PERFORMANCE,
PARTS, ACCESSORIES OR SERVICE CALL: 1.800.688.9900
IN CANADA, CALL: 1.800.807.6777
VISIT OUR WEBSITE AT WWW.MAYTAG.COM
IN CANADA, WWW.MAYTAG.CA
W10088777A
FABRIC CARE SYSTEM ELECTRIC DRYER
TM
USE & CARE GUIDE
CUIDADO DE LA TELAS
MANUAL DE USO Y CUIDADO
SOIN DES TISSUS
GUIDE D'UTILISATION ET D'ENTRETIEN
SI TIENE PREGUNTAS RESPECTO A LAS CARACTERÍSTICAS,
FUNCIONAMIENTO, RENDIMIENTO, PARTES, ACCESORIOS O
SERVICIO TÉCNICO, LLAME AL: 1.800.688.9900
O VISITE NUESTRO SITIO WEB EN
CON SISTEMA DE
TM
AVEC SYSTÈME DE
TM
WWW.MAYTAG.COM
AU CANADA, POUR ASSISTANCE, INSTALLATION OU SERVICE,
COMPOSER LE : 1.800.807.6777
OU VISITEZ NOTRE SITE INTERNET À
WWW.MAYTAG.CA
