  • Page 3 ® Safety, Setup, Operation & Maintenance Manual LT40L AH rev. D6.04 LT40L AH Wide rev. D6.04 Safety is our #1 concern! Read and understand all safety information and instructions before oper- ating, setting up or maintaining this machine. Form #940 This is the original language for the manual.
  • Page 4 From Europe call our European Headquarters and Manufacturing Facility in Kolo, Poland at +48-63-2626000. Please have the vehicle identification number and your customer number ready when you call. Wood-Mizer will accept these methods of payment: Visa, Mastercard, or Select Purchase ...
  • Page 5 Sawmill and Customer Identification Each Wood-Mizer sawmill has a 17-digit Vehicle Identification Number (VIN). See the fig- ure below for VIN locations. See the chart for VIN description. V.I.N. LOCATIONS X X G W M 1 0 0 1 V.I.N. DESCRIPTION.
  • Page 6 Each sawmill is also identified with a model number which includes the base model and the engine/motor configuration. See the figure for a description of the model number. LT40 Engine/Motor Basic Sawmill I.D. Configuration MODEL NUMBER DESCRIPTION. When you pick up your mill, you will receive a customer number. Both the VIN and your customer number expedite our service to you.

  • Page 7: Table Of Contents

    Table of Contents Section-Page SECTION 1 SAFETY & GENERAL INFORMATION Blade Handling..................1-2 Sawmill Setup..................1-3 Sawmill Operation..................1-4 Sawmill Maintenance ................1-8 Transporting the Sawmill ..............1-14 Belt Sizes ....................1-14 Blade Sizes ...................1-15 Cutting Capacity ...................1-16 Motor Specifications ................1-17 1.10 Noise Level...................1-17 1.11 Overall Dimensions ................1-18 1.12 Chains ....................1-19 1.13...
  • Page 8 Table of Contents Section-Page Blade Guides ..................3-2 Sawdust Removal ...................3-2 Carriage Track, Wiper & Scrapers ............3-3 Vertical Mast Rails .................3-4 Drum Switches ..................3-4 Miscellaneous ..................3-4 Blade Tensioner..................3-5 Blade Wheel Belts ..................3-6 3.10 Drive Belt Adjustment................3-6 3.11 Hydraulic System ...................3-7 3.12 Drive Bearing ..................3-8 3.13 Up/Down System..................3-9...
  • Page 9 Table of Contents Section-Page SECTION 6 HYDRAULIC INFORMATION LT 40/70L DH Hydraulic Schematic .............6-1 LT 40/70L DH Hydraulic Hoses ............6-3 Table of Contents SW-07doc1214223...
  • Page 10 Getting Service Wood-Mizer is committed to providing you with the latest technology, best quality and strongest customer service available on the market today. We continually evaluate our customers’ needs to ensure we’re meeting current wood-processing demands. Your comments and suggestions are welcome.
  • Page 11 Branches & Authorized Sales CentersWood-Mizer Locations (North and South America) EUROPE UNITED STATES European Headquarters World Headquarters Wood-Mizer Industries Sp. z o.o. Wood-Mizer LLC Nagórna 114, 62-600 Koło, Poland 8180 West 10th Street Tel.: +48-63-26-26-000 Indianapolis,Indiana 46214-2400, Fax: +48-63-27-22-327 www.woodmizer.eu Tel.: +1-317-271-1542...
  • Page 12 CROATIA Krešimir Pregernik ITALY Pasquale Felice SERBIA Dragan Markov Pregimex d.o.o. Wood-Mizer Italia Srl Wood-Mizer Balkan d.o.o. S. Batušiæa 31, 10090 Zagreb Cda. Capoiaccio SN Svetosavska GA 3/3; P. Fah 25 Tel.:/Fax: +3851-38-94-668 86012 Cercemaggiore 23 300 Kikinda Krešimir Pregernik Campobasso Tel.:/Fax: +381-230-25-754...
  • Page 13 Robert Moxham DENMARK Kevin Christiansen TRANSILVANIEI Nr. 5 Regional Direction - Asia Kevin Christiansen's Sibiu, Cisnadie 555300 Wood-Mizer Asia Manufacturing Co., Ltd. savværker PMV Tel.:/Fax: : +40-369-405-433 No.2, Gongyequ 40th Rd. Xitun District, Arnborgvej 40, 7330 Brande- Fasterholt GSM: +40-745-707-323 Taichung City, 40768, Taiwan, R.O.C.

  • Page 14: Safety & General Information

    It is always the owner's responsibility to comply with all applicable federal, state and local laws, rules and regulations regard- ing the ownership, operation and towing of your Wood-Mizer sawmill. All Wood-Mizer mill owners are encouraged to become thoroughly familiar with these applicable laws and comply with them fully while using or towing the mill.

  • Page 15: Blade Handling

    Safety & General Information Blade Handling Blade Handling DANGER! Shut off the sawmill motorbefore changing the blade. Fail- ure to do so will result in serious injury. WARNING! Always wear gloves and eye protection when handling bandsaw blades. Changing blades is safest when done by one person! Keep all other persons away from area when coiling, carrying or changing a blade.

  • Page 16: Sawmill Setup

    Safety & General Information Sawmill Setup Sawmill Setup WARNING! Securely fasten the feet of a stationary sawmill to the floor before operating the sawmill. Failure to do so may result in serious injury or death. WARNING! Always make sure the trailer is supporting the sawmill frame when operating a sawmill with adjustable outriggers.

  • Page 17: Sawmill Operation

    Safety & General Information Sawmill Operation Sawmill Operation DANGER! Make sure all guards and covers are in place and secured before operating or towing the sawmill. Failure to do so may result in serious injury. Be sure the blade housing and pulley covers are in place and secure. Use the safety retainer pin and cable to fasten blade housing covers.
  • Page 18 Safety & General Information Sawmill Operation WARNING! Never use the board return table as a platform to stand on. This table is designed and intended to assist in the removal of boards only. Standing on the table may result in serious injury. WARNING! Use ONLY water with the water lube accessory.
  • Page 19 Safety & General Information Sawmill Operation CAUTION Before loading a log, be sure the cutting head is moved far enough forward so the log does not hit it. Failure to do so may result in machine damage. CAUTION! Nie zostawiać załączonych dźwigni sterowania hydrauliką podczas postoju maszyny.
  • Page 20 Safety & General Information Sawmill Operation DANGER! The electric box door must always be closed, even when the sawmill is not in use. DANGER! Always disconnect the power when the sawmill has been not in use for a long period. DANGER! Any maintenance or repair must be done with the power off (the plug must be taken out of the outlet).

  • Page 21: Sawmill Maintenance

    Safety & General Information Sawmill Maintenance Sawmill Maintenance WARNING! Always secure the cutting head with a chain or a brace before adjusting the up/down chain. The cutting head may fall, causing severe injury or death. WARNING! Always secure the cutting head with a chain or a brace before adjusting the mast pads.
  • Page 22 Safety & General Information Sawmill Maintenance CAUTION! Do not overtighten the contact set screws on the hydraulic valve assembly. Overtightening may cause the threads in the screw hole to strip. CAUTION! Due to variations in the vertical mast, the pad spacing may vary throughout the travel of the saw head.
  • Page 23 Safety & General Information Sawmill Maintenance TABLE 1-1 099219 Blade tension. Turning the bolt clockwise will increase the blade tension and turning the bolt counterclockwise will decrease the tension. 099219 099223 Blade tension - See manual. 099223 099221 CAUTION! Keep all persons a safe distance away from work area when operating the machine.
  • Page 24 Safety & General Information Sawmill Maintenance TABLE 1-1 096316 CAUTION! Do not open or close the electric box when the switch is not in the “0” position. 096319 CAUTION! Disconnect power supply before opening the box. 099222 CAUTION! Sawdust outlet. Protect eyes! 099542 CAUTION! Trailer.
  • Page 25 Safety & General Information Sawmill Maintenance TABLE 1-1 512235 Clean chain from sawdust every 50 hours of operation or once a week 512235 512157 Lubricate chain every 50 hours of opera- tion or once a week 512157 S12004G CAUTION! Always wear safety goggles when operating the sawmill! S12005G CAUTION! Always wear protective ear...
  • Page 26 Safety & General Information Sawmill Maintenance TABLE 1-1 P11789 Aligning the blade on the wheels P85070 CE safety certification 099401 Russian safety certification 099401 S20097E 2930 RPM - Motor rotation direction 2930 RPM S20097E 1-13 doc121422 Safety & General Information...

  • Page 27: Transporting The Sawmill

    1. Check all lights and signals for correct operation. 2. Make sure the overrunning brake is functioning properly. Adjust if necessary. 3. Check to see tires are properly inflated. Belt Sizes See Table 1-2. Belt sizes for the LT40L AH are shown. Description Belt Size Wood-Mizer...

  • Page 28: Blade Sizes

    Blade Sizes Blade Sizes See Table 1-3. Wood-Mizer TRU•SHARP™ offers three types of blades to provide efficient sawing for all models of sawmills. The engine/motor size of your sawmill and the type of wood you saw should determine which blade you choose for optimum performance.

  • Page 29: Cutting Capacity

    LT40M AH with Optional 24' Bed Exten- 91,5 cm (36") 13,7 m (45') sion LT40L AH 91,5 cm (36") 8,4m TABLE 1-4 Maximum log capacity for a basic mill is 4400 lbs. (1996 Kg). Logs over 4400 lbs. must be distributed so that neither the basic mill or extension is loaded beyond the 4400 lb.

  • Page 30: Motor Specifications

    Safety & General Information Motor Specifications Motor Specifications See Table 1-7. The power options available for the LT40S/M/L AH sawmills are listed below. Model Manufacturer Rated Current at Rated speed Weight output 380V, 50Hz 3Sg 160M-2B-HM-T Tamel SA, 15kW 28,1 A 2930 RPM 117 Kg Motor, Tamel...

  • Page 31: Overall Dimensions

    Safety & General Information Overall Dimensions 1.11 Overall Dimensions See Table 1-10. The overall dimensions of the Wood-Mizer LT40S/M/L AH sawmills are listed below. Model With Weight Length Width Height Weight (Operating Position w/Trailer with Loading Arms) LT40S AH 6,7 m...

  • Page 32: Chains

    Safety & General Information Chains See figure 1-2. FIG. 1-2 1.12 Chains See Table 1-11. The load capacity of the chains is listed below. Load Capacity According to ISO Nr 08A-1 Power Feed Chain 1780N Up/Down Chain 1780N TABLE 1-11 1.13 Hydraulic System See Table 1-12.

  • Page 33: Dust Extractor Specifications

    Safety & General Information Dust Extractor Specifications 1.14 Dust Extractor Specifications See Table 1-13. Specifications of the dust extractors used on the resaw for each saw head are listed below. Airflow 1200 m 3937ft Inlet diameter 100 mm (5.9”) Motor power 1,5 kW Number of sacks 1 pcs...

  • Page 34: Components

    Safety & General Information Components 1.15 Components See figure 1-3. The major components of the Wood-Mizer LT40L AH are shown below. FIG. 1-3 See Table 1-14. Hydraulic Control Box Control Box Power Cord Connection Motor Hydraulic Log Loader Blade Tensioner...

  • Page 35: Electrical Information

    Safety & General Information Electrical Information 1.16 Electrical Information See figure 1-4. The Hydraulic Pump Electrical Diagram is shown below. FIG. 1-4 Safety & General Information doc121422 1-22...
  • Page 36 Safety & General Information Electrical Information Description (See Figure above): Symbol Name - type Wood-Mizer # Socket, 16A E85239 Main Switch, ABB OT16E3 89801 Contactor, LC1K0910B7 084451 Thermal Relay, LR2K0316 84456 Pump Motor, SLg100L-4PC Phase Controller, RM3TG2 084452 Time Relay, RE8RA...

  • Page 37: Setup & Operation

    Setup & Operation Sawmill Setup SECTION 2 SETUP & OPERATION Sawmill Setup IMPORTANT! Before starting to use the sawmill you have to meet the following conditions: Set up the sawmill on firm and level ground.  The sawmill can be operated with the sawdust collection system only. ...

  • Page 38: Stationary Sawmill Setup

    Setup & Operation Stationary Sawmill Setup Setting the phases in the phase inverter correctly will ensure correct rotation directions of all sawmill motors. Stationary Sawmill Setup See Figure 2-1. Prepare a firm, level area where the sawmill can be anchored. There should be enough room around the sawmill for operators, sawdust removal, log loading and board removal.

  • Page 39: Sawmills With Cable Guide

    Setup & Operation Sawmills with cable guide See Figure 2-2. Bed Rail Side Support Sm0130b FIG. 2-2 Sawmills with cable guide See Figure 2-3. The figure below shows setup of the sawmill, the control box and the guiding rail col- umns.
  • Page 40 Setup & Operation Sawmills with cable guide FIG. 2-3 LT40MRC See Figure 2-4. The electrical wires should be installed on the guiding rail as shown below. doc121422 Setup & Operation...
  • Page 41 Setup & Operation Sawmills with cable guide FIG. 2-4 See Figure 2-5. Install the rail bracket arm as shown below. M8x30 Bolt FIG. 2-5 Setup & Operation doc121422...
  • Page 42 Setup & Operation Sawmills with cable guide See Figure 2-6. Install the guiding rail. FIG. 2-6 doc121422 Setup & Operation...
  • Page 43 Setup & Operation Sawmills with cable guide See Figure 2-7. FIG. 2-7 Setup & Operation doc121422...
  • Page 44 Setup & Operation Sawmills with cable guide See Figure 2-8. The figure below shows how the cable hanger should be set. FIG. 2-8 Unbolt the four bolts, rotate the hanger 90 degrees to the right and tighten the bolts. doc121422 Setup &...

  • Page 45: Portable Sawmill Setup

    Setup & Operation Portable Sawmill Setup Portable Sawmill Setup WARNING! Do not set up the mill on ground with more than a 10 degree incline. If setup on an incline is necessary, put blocks under one side of the mill or dig out areas for outrigger legs to keep mill level. Setting up the mill on an incline could cause it to tip over, resulting in serious personal injury.
  • Page 46 Setup & Operation Portable Sawmill Setup See Figure 2-9. Adjustment Bolt Travel Lock Pin Locking Pin Outrigger Leg FIG. 2-9. OUTRIGGER ADJUSTMENT. CAUTION! When setting up the sawmill on boggy terrain (such as deep mud or sand), place a board or a metal plate under each outrig- ger leg to prevent the legs from sinking.
  • Page 47 Setup & Operation Portable Sawmill Setup CAUTION! To prevent fender damage, remove fenders before operat- ing sawmill or loading logs. 6. Use the carriage forward/reverse switch (left side of control box) to move the cutting head toward the front end of the mill. Lower and set the remaining rear outriggers. 7.

  • Page 48: Middle Track Cover

    Setup & Operation Middle Track Cover Middle Track Cover Before operating the sawmill do as follows: 1. Clean the upper and lower rails to remove any sawdust and rust preventives. 2. Unbolt and remove the middle track cover from its storage position. 3.

  • Page 49: Replacing The Blade

    Setup & Operation Replacing The Blade Replacing The Blade DANGER! Always disengage the blade and shut off the sawmill engine before changing the blade. Failure to do so will result in serious injury. WARNING! Always wear gloves and eye protection when handling bandsaw blades.

  • Page 50: Tensioning The Blade

    Setup & Operation Tensioning The Blade Tensioning The Blade See Figure 2-12. Tension the blade by turning the hydraulic tensioning handle clockwise until the tension gauge indicates the recommended tension. Blade Tensioner Gauge Blade Tensioner Handle Cant Control FIG. 2-12 See Table 2-2.

  • Page 51: Tracking The Blade

    Setup & Operation Tracking The Blade Tracking The Blade 1. Make sure the middle blade housing cover is closed and all persons are clear of the open side of the saw head. 2. Start the motor by pushing the START button located on the control box. WARNING! Do not spin the blade wheels by hand.

  • Page 52: Starting The Motor

    Setup & Operation Starting The Motor housing covers. IMPORTANT! After aligning the blade on the wheels, always double-check the blade guide spacing and location. (See Section 5 for more information.) Starting The Motor See the appropriate manual supplied with your specific motor configuration for starting and operating instructions.

  • Page 53: Hydraulic Control Operation

    Setup & Operation Starting The Motor After installation, test the sawmill for proper motor rotation. If rotation is incorrect, turn the motor off pushing the STOP button located on the control box. Turn the main switch on the starter box to the OFF (“0”) position. Disconnect the power cord on the left side of the starter box.
  • Page 54 Setup & Operation Starting The Motor movement of each clamp is controlled with a separate lever. Main Clamp In/Out Main Clamp Up/Down Log Turner Front Toe Board Log Loader Rear Toe Board FIG. 2-14 2-18 doc121422 Setup & Operation...
  • Page 55 Setup & Operation Starting The Motor See Figure 2-15. A/DH5 Hydraulic System Front Rear Clamp Clamp Rear Front Up/Down Clamp Up/Down Clamp A/DH3 Up/Down Up/Down Front Clamp Rear Clamp Front Rear In/Out In/Out HD0185 Clamp Clamp In/Out In/Out FIG. 2-15 See Figure 2-16.
  • Page 56 Setup & Operation Starting The Motor do so will result in serious injury.CAUTION! Always make sure the engine is running before operating the hydraulic controls. Operating the controls without the engine running will result in power drainage from the battery. Holding the hydraulic switches halfway up or down also will cause excessive drainage from the battery.
  • Page 57 Setup & Operation Starting The Motor 1. Move the clamp out and down so it will not get in the way of logs being loaded onto the bed. Lower the clamp in/out lever to move the clamp out toward the loading side of the sawmill. Lower the clamp up/down lever to lower the clamp below the bed level.

  • Page 58: Loading, Turning, And Clamping Logs

    Setup & Operation Loading, Turning, And Clamping Logs 2.11 Loading, Turning, And Clamping Logs CAUTION! Be sure the pivot rails, turning arm, clamp, and toe boards are below bed level before loading a log onto the bed. Failure to do so may result in machine damage or cause misalignment.
  • Page 59 Setup & Operation Loading, Turning, And Clamping Logs To Turn Logs 1. Raise the turner lever to engage the log turner arm. Let the arm rise until it touches the log and starts to turn it. 2. Spin the log against the side supports until it is turned the way you want it for the first cut. If you want to turn the log more, do the following steps.
  • Page 60 Setup & Operation Loading, Turning, And Clamping Logs To Clamp Logs 1. Raise the clamp in/out lever and clamp the log against the side supports. 2. Lower the turner lever until the turner arm falls below the bed. 3. When the turner arm is lowered all the way, the side supports will begin to lower. Back the clamp off slightly, and let the side supports come down until they are positioned below the level of your first few cuts.

  • Page 61: Up/Down Operation

    Setup & Operation Up/Down Operation 2.12 Up/Down Operation 1. Install a blade, if needed, and check for correct blade tension. (See Section 2.7). 2. Set the cutting head to the desired height. (The blade height scale shows the height of the blade above the bed rails.) See Figure 2-17.

  • Page 62: Blade Guide Arm Operation

    Setup & Operation Blade Guide Arm Operation 2.13 Blade Guide Arm Operation 1. Look down the length of the log to see its maximum width. The outer blade guide should be adjusted to clear the widest section of the log by less than 1" (25.4 mm). 2.

  • Page 63: Clutch/Brake Operation

    Setup & Operation Clutch/Brake Operation 2.14 Clutch/Brake Operation NOTE: If your sawmill is equipped with the Remote Option, see the option manual for clutch/brake operation. 1. Clear any loose objects from the area of the blade, motor, and drive belt. 2.
  • Page 64 Setup & Operation Clutch/Brake Operation 4. To engage the blade, pull the lever down until it locks in the down position. This engages the drive mechanism, releases the blade brake, and increases the engine speed to full throttle. To disengage the blade, raise the clutch/brake lever to the up position. This disengages the drive belt, engages the blade brake, and returns the engine to idle.

  • Page 65: Power Feed Operation

    Setup & Operation Power Feed Operation 2.15 Power Feed Operation See Figure 2-20. The power feed system moves the carriage forward and backward by using two switches on the control panel. Carriage Forward Forward Feed Rate Carriage Reverse 3H0280a1 FIG. 2-20 Carriage Feed Rate The carriage feed rate switch controls the speed at which the carriage travels forward.
  • Page 66 Setup & Operation Power Feed Operation WARNING! Be sure the power feed switch is in the neutral position before turning the key switch to the (#2) or (#1) position. This prevents accidental carriage movement. which may cause serious injury or death.

  • Page 67: Cutting The Log

    Cutting The Log 2.16 Cutting The Log The following steps guide you through normal operation of the Wood-Mizer sawmill. 1. Once the log is placed where you want it and clamped firmly, turn the key switch to the accessory (#2) position.

  • Page 68: Edging

    27 - 29 mm for each board. 2.17 Edging The following steps guide you through edging boards on the Wood-Mizer sawmill. 1. Raise the side supports to 1/2 the height of the flitches, or the boards that need to be edged.

  • Page 69: Optional Cutting Procedure For Super Series Mills

    Setup & Operation Optional Cutting Procedure for Super Series Mills 2.18 Optional Cutting Procedure for Super Series Mills In order to achieve maximum production rates with Super Series mills; it may be desirable to leave the blade engaged when returning the carriage. (Normal operation procedures recommend disen- gaging the blade before returning the carriage for maximum blade life and fuel economy.) DANGER! If leaving the blade engaged for maximum production rates,...

  • Page 70: Blade Height Scale

    Setup & Operation Blade Height Scale 2.19 Blade Height Scale See Figure 2-21. The blade height scale is attached to the carriage head frame. It includes: a blade height indicator  an inch scale  a quarter scale  Blade Height Quarter Indicator Scale...
  • Page 71 Setup & Operation Blade Height Scale Example: You want to cut 1" (25 mm) random width boards from a log. Position the blade for the first cut. Move the carriage to an even measurement on the inch scale. Make a trim cut. Return the car- riage for the second cut and lower it 1 1/8"...

  • Page 72: Water Lube Operation

    Setup & Operation Water Lube Operation 2.20 Water Lube Operation See Figure 2-22. The Water Lube System keeps the blade clean. Water flows from a 5-gallon (18.9 liter) bottle through a hose to the blade guide where the blade enters the log. A valve in the bottle cap controls the amount of water flow.

  • Page 73: Preparing The Sawmill For Towing

    (#0). 2.21 Preparing The Sawmill For Towing The Wood-Mizer trailer package makes transporting your sawmill easy and convenient. To get your sawmill ready for towing, follow these instructions. 1. Move the saw carriage to the front end of the sawmill. Raise the rear outriggers.
  • Page 74 Setup & Operation Preparing The Sawmill For Towing CAUTION! Move the hydraulic clamp and turner to provide maximum ground clearance before towing. Failure to do so may result in damage to the sawmill. 3. Move the carriage forward to the travel position over the rear bed rail. 4.
  • Page 75 Setup & Operation Preparing The Sawmill For Towing See Figure 2-25. Loosen jam nut and turn bolt to raise or lower stop bolt FIG. 2-25 9. Use the hydraulic controls to raise the log turner and loader as high as they will go. Manually lift the loader and hook the loader chains to the sawmill frame.
  • Page 76 Setup & Operation Preparing The Sawmill For Towing 12. Remove all loose objects from the bed of the mill. Store the outrigger jack handle in the bracket pro- vided on the rear/loading-side outrigger guide. Reel in the winch cable. Remove the winch handle. 13.
  • Page 77 Setup & Operation Preparing The Sawmill For Towing Setup & Operation doc121422 2-41...

  • Page 78: Maintenance

    Maintenance Wear Life SECTION 3 MAINTENANCE This section lists the maintenance procedures that need to be performed. The Short Interval Maintenance Schedule lists procedures that need to be performed every 4, 8 or 25 hours.The Maintenance Log lists procedures that need to be performed every 50, 100, 200, or 1000 hours.

  • Page 79: Blade Guides

    Maintenance Blade Guides Blade Guides 1. Check the rollers for performance and wear every blade change. Make sure the rollers are clean and spinning freely. If not, rebuild them. Replace any rollers which have worn smooth or have become cone shaped. See The LT40S/M AH Parts manual for blade guide rebuild kits and complete roller assemblies.

  • Page 80: Carriage Track, Wiper & Scrapers

    Maintenance Carriage Track, Wiper & Scrapers Carriage Track, Wiper & Scrapers See Figure 3-2. 1. Clean the upper and lower track rails to remove any sawdust and sap buildup every eight hours of operation. Lubricate the lower track rail by wiping it with Dexron III ATF. 2.

  • Page 81: Vertical Mast Rails

    Lubricate the up/down and power feed drum switch contacts inside the control panel every fifty hours of operation. Use only contact grease supplied by Wood-Mizer. Remove the control panel cover. Use a cotton swab to apply grease to the switch contact ends.

  • Page 82: Blade Tensioner

    Maintenance Blade Tensioner Blade Tensioner 1. Lubricate the chrome rods of the tensioner system with a heavy duty teflon spray lubri- cant every 50 hours of operation. 2. Lubricate the tensioner screw handle with a grade lithium grease as needed. See Figure 3-3.

  • Page 83: Blade Wheel Belts

    Maintenance Blade Wheel Belts Manually extend the rear piston (the front piston should remain extended).  Use a small funnel or cup to completely fill the block with hydraulic fluid. When full,  place the fill plug in the fill plug hole and thread 1-2 turns. Manually push the rear piston all the way in to allow excess oil and air to bleed from system through the plug.

  • Page 84: Hydraulic System

    Maintenance Hydraulic System 3.11 Hydraulic System 1. Check the hydraulic fluid level every 50 hours of operation. Add fluid as necessary. The level in the hydraulic pump should be 19mm from the top with all cylinders collapsed. If humidity is a problem or the mill is used outside in humid weather, drain and replace two quarts (.95 liters) of fluid every six months.

  • Page 85: Drive Bearing

    Maintenance Drive Bearing 3.12 Drive Bearing Refill the fluid in the drive-side cylinder bearing housing every 500 hours of operation. Remove the top and bottom oil plugs. Pour an Automatic Transmission Fluid (ATF, SAE 30) into the top hole until it begins to flow from the bottom hole. Reinstall the square oil plug to the bottom hole and the vented oil plug to the top hole.

  • Page 86: Up/Down System

    Maintenance Up/Down System 3.13 Up/Down System See Figure 3-7. Up/Down Gear Reducer Shaft Bearing FIG. 3-7 1. Super model up/down systems feature a spring loaded belt design. Belt tension is auto- matically maintained and requires no adjustment. Replace the belt when adequate belt tension can no longer be obtained.
  • Page 87 Maintenance Up/Down System See Figure 3-8. FIG. 3-8 Maintenance AHDSdoc121422 3-10...

  • Page 88: Power Feed

    Maintenance Power Feed 3.14 Power Feed 1. Adjust the power feed belt as needed. When the power feed belt gets loose, it will begin slipping. This causes the carriage to not move forward when cutting. To retighten the belt: See Figure 3-9. Remove the four cover bolts and belt cover and measure the belt ten- sion.

  • Page 89: Adjusting The Air Gap Of The Up/Down Feed Brake

    Maintenance Adjusting the Air Gap of the Up/Down Feed Brake. See Figure 3-10. 3H0018B Feed Chain Adjustment Nuts FIG. 3-10 3.15 Adjusting the Air Gap of the Up/Down Feed Brake. 1. The air gap widens as a result of brake disc wear. The gap must not be greater than 0.5mm.
  • Page 90 Maintenance Adjusting the Air Gap of the Up/Down Feed Brake. 3-13 AHDSdoc121422 Maintenance...
  • Page 91 LT40 Series A/DH Short Interval Maintenance Schedule (Check engine and option manuals for additional maintenance procedures) PROCEDURE MANUAL REFERENCE EVERY BLADE CHANGE Check Blade Guide Roller Performance See Section 3.2 Remove Excess Sawdust From Blade Wheel Housings And Sawdust Chute See Section 3.3 Check Blade Screw See Section 3.2...
  • Page 92 WOOD-MIZER LT40 SERIES A/DH MAINTENANCE LOG (Check Engine And Option Manuals For Additional Maintenance Procedures) PROCEDURE MANUAL TOTAL HOURS OF OPERATION REFERENCE FILL IN THE DATE AND THE MACHINE HOURS AS YOU PERFORM EACH PROCEDURE. A SHADED BOX INDICATES MAINTENANCE IS NOT NEEDED AT THIS TIME.
  • Page 93 WOOD-MIZER LT40 SERIES A/DH MAINTENANCE LOG (Check Engine And Option Manuals For Additional Maintenance Procedures) PROCEDURE MANUAL TOTAL HOURS OF OPERATION REFERENCE FILL IN THE DATE AND THE MACHINE HOURS AS YOU PERFORM EACH PROCEDURE. A SHADED BOX INDICATES MAINTENANCE IS NOT NEEDED AT THIS TIME.
  • Page 94 WOOD-MIZER LT40 SERIES A/DH MAINTENANCE LOG (Check Engine And Option Manuals For Additional Maintenance Procedures) PROCEDURE MANUAL TOTAL HOURS OF OPERATION REFERENCE FILL IN THE DATE AND THE MACHINE HOURS AS YOU PERFORM EACH PROCEDURE. A SHADED BOX INDICATES MAINTENANCE IS NOT NEEDED AT THIS TIME.
  • Page 95 WOOD-MIZER LT40 SERIES A/DH MAINTENANCE LOG (Check Engine And Option Manuals For Additional Maintenance Procedures) PROCEDURE MANUAL TOTAL HOURS OF OPERATION REFERENCE FILL IN THE DATE AND THE MACHINE HOURS AS YOU PERFORM EACH PROCEDURE. A SHADED BOX INDICATES MAINTENANCE IS NOT NEEDED AT THIS TIME.
  • Page 96 30doc121422...

  • Page 97: Troubleshooting Guide

    Troubleshooting Guide Sawing Problems SECTION 4 TROUBLESHOOTING GUIDE Sawing Problems PROBLEM CAUSE SOLUTION Blades Dull Quickly Dirty logs Clean or debark logs, especially on entry side of the cut When grinding teeth, heating Grind just enough metal to restore too much and causing teeth to sharpness to the teeth.
  • Page 98 Troubleshooting Guide Sawing Problems PROBLEM CAUSE SOLUTION Boards Thick Or Thin On Stress in log which causes log After log has been squared, take Ends Or Middle Of Board. to not lay flat on the bed. equal cuts off opposing sides. Take a board off the top.

  • Page 99: Electrical Problems

    Troubleshooting Guide Electrical Problems Electrical Problems PROBLEM CAUSE SOLUTION Up/down Excessively Slow. Vertical wear pads too tight. Adjust pads. Up/down belt loose. Adjust belt to be as loose as possible without slipping Up/down Or Power Feed Worn/dirty contacts in drum Replace switch or remove control Motors Do Not Work.

  • Page 100: Power Feed Problems

    Drum switch is dirty. Clean drum switch and lubricate Speeds Or Does Not Move with contact grease supplied by Until Speed Is Above Halfway Wood-Mizer. Mark. Drum switch contacts are bad Check that contacts are in good condition and positively close cir- cuit.
  • Page 101 Troubleshooting Guide Power Feed Problems PROBLEM CAUSE SOLUTION Power Feed Motor Overheats. Middle track oiler is dragging. Clean middle track oiler and lubricate with 30-weight oil or ATF (Automatic Transmission Fluid) such as Dexron II. Allow motor to cool before restarting. Ground is not level.

  • Page 102: Hydraulic Problems

    Troubleshooting Guide Hydraulic Problems Hydraulic Problems PROBLEM CAUSE SOLUTION You Can Actuate Any Hydrau- Carriage not positioned prop- Make sure carriage contact bracket is lic Handle, But Get No erly to provide power to the adjusted far enough forward for battery Response From The Pump.
  • Page 103 Troubleshooting Guide Hydraulic Problems You Can Get Response From Valve assembly switch con- Locate the valve switch at the bottom the Pump By Actuating All tacts are not properly adjusted of the valve assembly. Use a 3MM But One or Two Handles allen wrench to loosen the set screw on each of the five switch contacts.
  • Page 104 Troubleshooting Guide Hydraulic Problems PROBLEM CAUSE SOLUTION Pump Motor Runs With Little Low fluid level Check fluid level. Add an all-season Or No Response From The hydraulic fluid such as Amoco Rycon Cylinders Oil MV or Mobil Multipurpose ATF (automatic transmission fluid) until level is 4 - 4 1/2"...
  • Page 105 Troubleshooting Guide Hydraulic Problems PROBLEM CAUSE SOLUTION Hydraulic Side Supports Go Dirt in sequence valve Remove sequence valves and clean Down Before Or At Same thoroughly with kerosene. NOTE: Be Time As Log Turner sure to reassemble the valve and install it in its original position on the cylinder Retainer in sequence valve...

  • Page 106: Motor And Drive Pulleys Alignment

    Troubleshooting Guide Motor and Drive Pulleys Alignment Motor and Drive Pulleys Alignment 1. Install the drive belt. 2. Use a straight edge to align the engine/motor pulley to the drive pulley. 3. Check front-to-back movement of the engine does not exceed 6,5 mm (1/4"). Tighten the motor mount U-bolts if necessary.

  • Page 107: Hydraulic Pressure Test

    Troubleshooting Guide Hydraulic Pressure Test Hydraulic Pressure Test CAUTION! Pressure should not exceed 16 MPa. Pressure above 16 MPa may damage the hydraulic hoses. Troubleshooting Guide AHDSdoc121422 4-11...

  • Page 108: Sawmill Alignment

    SECTION 5 SAWMILL ALIGNMENT Pre-Alignment Procedures The Wood-Mizer sawmill is factory aligned. Two alignment procedures are available to realign the sawmill if necessary. The Routine Alignment instructions should be performed as necessary to solve sawing problems not related to blade performance. The Complete Alignment procedure should be performed approximately every 1500 hours of operation (sooner if you regularly transport the sawmill over rough terrain).

  • Page 109: Frame Setup

    Sawmill Alignment Frame Setup Frame Setup Stationary sawmills should be setup on firm, level ground before proceeding with align- ment. Shim the feet so the weight of the sawmill is evenly supported. Portable sawmills should also be setup on firm, level ground: LT40S AH: Adjust the two middle outriggers on the main frame tube down just enough to lift weight from the trailer tire.
  • Page 110 Sawmill Alignment Blade Installation And Alignment WARNING! Do not spin the blade wheels by hand. Spinning the blade wheels by hand may result in serious injury. 3. Turn off the engine, remove the key and check the position of the blade on the blade wheels.
  • Page 111 Sawmill Alignment Blade Installation And Alignment See Figure 5-3. For horizontal adjustment, use the horizontal adjustment nuts. If the blade is running too far back on the drive-side blade wheel, locate the long U-bolt on the right which mounts the bearing housing to the mounting plates. Loosen the hex nuts on the U-bolt (on the back side of the back plate).

  • Page 112: Saw Head Slide Pad Adjustment

    Sawmill Alignment Saw Head Slide Pad Adjustment Saw Head Slide Pad Adjustment There are eight nylon pads positioned between the saw head frame and vertical mast. The spacing of the pads is factory set and rarely needs adjusting. To check the pad spac- ing, perform the following steps.

  • Page 113: Adjusting The Lower Track Rollers

    Sawmill Alignment Adjusting The Lower Track Rollers 3. Loosen the upper locking bolts and turn the adjusting bolt as necessary to provide the pad spacing described in punkt 1. 4. Lower the saw head to the bottom of the vertical mast. Check the bottom set of four pads. There should be a small gap between one of the outer pads and the mast rail.
  • Page 114 Sawmill Alignment Adjusting The Lower Track Rollers SM0135B Upper Rollers (4) Stop Screw (2) Stop Bolt (2) Inside Lower Rollers (2) Bottom Lower Horizontal Rollers (2) Vertical Adjustment Adjustment Bolt Nuts FIG. 5-5 5. Remove the blade guides, or adjust them so that they do not touch the blade. 6.
  • Page 115 Sawmill Alignment Adjusting The Lower Track Rollers CAUTION! It is important that the lower stop bolts are prop- erly adjusted to secure the carriage on the track rail. Failure to properly adjust the stop bolts can cause saw head dam- age, especially during mill transportation.

  • Page 116: Adjusting Bed Rails To The Blade

    Sawmill Alignment Adjusting Bed Rails To The Blade Adjusting Bed Rails To The Blade 1. Move the vertical clamp to its lowest position. Before using the clamp tube as a reference to set the blade, make sure it is level. 2.
  • Page 117 Sawmill Alignment Adjusting Bed Rails To The Blade 6. Move the saw head so the blade is positioned over the center of the front main bed rail. 7. Measure the distance between the bottom of the blade and the bed rail at each end of the bed rail.

  • Page 118: Blade Guide Arm Alignment

    Blade Guide Arm Alignment Each Wood-Mizer sawmill has two blade guide assemblies that help the blade maintain a straight cut. The two blade guide assemblies are positioned on the saw head to guide the blade on each side of the material being cut.
  • Page 119 Sawmill Alignment Blade Guide Arm Alignment See Figure 5-9. Loosen the jam nuts and turn the adjustment bolts in to tighten the blade guide arm rollers. Retighten the jam nuts. Roller Adjustment Bolts FIG. 5-9 After tightening the blade guide arm rollers, check that the arm is aligned properly. 3.
  • Page 120 Sawmill Alignment Blade Guide Arm Alignment See Figure 5-10. Measure distance between roller flange and blade Zmierzyć odległość pomiędzy kołnierzem rolki prowadzącej with arm open and closed piłę a piłą przy ramieniu prowadnika piły przesuniętym w kierunku wewnętrznym oraz zewnętrznym. 3H0802-10b FIG.
  • Page 121 Sawmill Alignment Blade Guide Arm Alignment See Figure 5-11. Loosen the horizontal adjustment bolt jam nuts. To tilt the arm in toward the blade, loosen the right bolt and tighten the left bolt. To tilt the arm out away from the blade, loosen the left bolt and tighten the right bolt.
  • Page 122 Sawmill Alignment Blade Guide Arm Alignment See Figure 5-12. Measure from blade guide arm to bed rail with arm open and closed FIG. 5-12 7. Adjust the blade guide arm to 1/2" (15 mm) from fully open. Measure the distance from the bottom of the blade guide mounting block to the bed rail.
  • Page 123 Sawmill Alignment Blade Guide Arm Alignment See Figure 5-13. Loosen the vertical adjustment bolt jam nuts. To tilt the blade guide arm down, loosen the right bolt and tighten the left bolt. To tilt the blade guide arm up, loosen the left bolt and tighten the right bolt.

  • Page 124: Blade Deflection

    Sawmill Alignment Blade Deflection Blade Deflection Perform the following steps to achieve proper blade deflection with the blade guides. 1. Raise the carriage until the blade is 15" (375 mm) above a bed rail. Measure the actual distance with a tape from the top of the rail to the bottom of the blade. 2.

  • Page 125: Blade Guide Vertical Tilt Adjustment

    Sawmill Alignment Blade Guide Vertical Tilt Adjustment Blade Guide Vertical Tilt Adjustment Check that the blade guide does not tilt the blade up or down. A Blade Guide Alignment Tool (BGAT) is provided to help you measure the vertical tilt of the blade. 1.
  • Page 126 Sawmill Alignment Blade Guide Vertical Tilt Adjustment See Figure 5-16. Loosen jam nuts and turn screws to tilt roller up or down SM0070 FIG. 5-16 8. Move the carriage forward so the back end of the tool is over the bed rail. 9.

  • Page 127: Blade Guide Spacing

    Sawmill Alignment Blade Guide Spacing 5.10 Blade Guide Spacing HINT: When adjusting blade guide spacing, loosen the top set screw and one side set screw only. This will ensure horizontal and vertical tilt adjustments are maintained when the set screws are retightened. 1.

  • Page 128: Horizontal Tilt Adjustment

    Sawmill Alignment Horizontal Tilt Adjustment 5.11 Horizontal Tilt Adjustment 1. Finally, both blade guides must be tilted horizontally. Adjust the blade guide arm halfway See Figure 5-18. FIG. 5-18 2. Place the Blade Guide Alignment Tool against the face of the outer blade guide roller. 3.

  • Page 129: Horizontal Adjustment Of Side Supports

    Sawmill Alignment Horizontal Adjustment of Side Supports 5.12 Horizontal Adjustment of Side Supports Logs and boards are clamped against the side supports when sawing. The sides supports must be square to the bed to ensure square lumber. 1. Swing the side support down. 2.

  • Page 130: Vertical Adjustment Of Side Supports

    Sawmill Alignment Vertical Adjustment of Side Supports 5.13 Vertical Adjustment of Side Supports 1. Place a flat board across the bed rails. 2. Swing a side support up so that it is vertical. 3. Pull back at the top of the support to eliminate slack as if a log were being clamped against it.

  • Page 131: Clamp Stop/Stop Bolt Adjustment

    Sawmill Alignment Clamp Stop/Stop Bolt Adjustment 5.14 Clamp Stop/Stop Bolt Adjustment 1. Once the side supports are aligned, pivot them down to their horizontal position. 2. Tie a string across the face of the side supports. See Figure 5-21. 3. Loosen the clamp stop bolts and adjust the clamp stop until it touches the string. Loosen the jam nut and adjust the bolt on the middle-rear bed rail until it touches the string.

  • Page 132: Saw Head Tilt

    Sawmill Alignment Saw Head Tilt 5.15 Saw Head Tilt As the blade enters a wide log or cant, the outside of the saw head will drop down slightly. To compensate for the drop, use the lower track roller horizontal bolts to raise the outside of the saw head 1/16"...

  • Page 133: Blade Height Scale Adjustment

    Sawmill Alignment Blade Height Scale Adjustment 5.16 Blade Height Scale Adjustment After the entire sawmill has been aligned and all adjustments made, check that the blade height scale indicates the true distance from the blade to the bed rails. 1. Move the saw head so the blade is positioned directly above one of the bed rails. Mea- sure from the bottom edge on a down-set tooth of the blade to the top of the bed rail (or stainless steel sleeve if applicable).
  • Page 134 Sawmill Alignment Blade Height Scale Adjustment 5-27 AHDSdoc121422 Sawmill Alignment...
  • Page 135 Hydraulic Information LT 40/70L DH Hydraulic Schematic SECTION 9 HYDRAULIC INFORMATION LT 40/70L DH Hydraulic Schematic FIG. 9-1 HYDRAULIC SCHEMATIC Hydraulic Information 60HDdoc121422...
  • Page 136 Hydraulic Information LT 40/70L DH Hydraulic Schematic Log Loader - Middle Toe Board - Clamp In/Out - Turner - Side Supports - Front Pull-Down Clamp, In/Out - Front Pull-Down Clamp, Up/Down - Rear Toe Board - Front Toe-Board - Rear Pull-Down Clamp, In/Out - Rear Pull-Down Clamp, Up/Down - Clamp Up/Down - 60HDdoc121422...
  • Page 137 Hydraulic Information LT 40/70L DH Hydraulic Hoses LT 40/70L DH Hydraulic Hoses See Table 9-1. Color LENGTH Application QTY. Wood-Mizer Code "A" Part No. 0,65m Hose 3/8” Section Link 089844 0,43m Hose 3/8” Section To Oil Flow Divider. 089845 Orange 2,8m Hose 3/8”...
  • Page 138 Hydraulic Information LT 40/70L DH Hydraulic Hoses White/Or 2,7m Hose 1/4” 3rd Clamp In/Out 089867 ange Blue/Red 0,6m Hose 1/4” 3rd Clamp Up/Down 089868 TABLE 9-2 60HDdoc121422 Hydraulic Information...
  • Page 139 EC declaration of conformity according to EC Machinery Directive 2006/42/EC, Annex II, 1.A Manufacturer: Wood-Mizer Industries sp. z o.o. Nagórna 114, 62- Tel. +48 63 26 26 000 This declaration of conformity is issued under the sole responsibility of the manufacturer.

This manual is also suitable for:

Lt40l ah wide

Table of Contents
