Wood-Mizer
Safety, Setup, Operation
& Maintenance Manual
LT30HD
LT30HD Super
LT40HD
LT40HD Super
Safety is our #1 concern! Read and understand
all safety information and instructions before oper-
ating, setting up or maintaining this machine.
October 2004
®
Sawmill
rev. F8 - F9.01
rev. F8 - F9.01
rev. F8 - F9.01
rev. F8 - F9.01
Form #688

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LT30HD and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Wood-mizer LT30HD

Summary of Contents for Wood-mizer LT30HD

  • Page 1 ® Wood-Mizer Sawmill Safety, Setup, Operation & Maintenance Manual LT30HD rev. F8 - F9.01 LT30HD Super rev. F8 - F9.01 LT40HD rev. F8 - F9.01 LT40HD Super rev. F8 - F9.01 Safety is our #1 concern! Read and understand all safety information and instructions before oper- ating, setting up or maintaining this machine.
  • Page 2 If You Need To Order Parts... From the continental U.S., call our toll-free Parts hotline at 1-800-525-8100. Please have the vehicle identification number and your customer number ready when you call. Wood-Mizer will accept these methods of payment: Visa, Mastercard, or Select Purchase Prepayment Net 15 (with approved credit) Be aware that shipping and handling charges may apply.
  • Page 3 Take notice of all safety warnings throughout this manual and those posted on the machine. Keep this manual with this machine at all times, regardless of ownership. ® *Wood-Mizer is a registered trademark of Wood-Mizer Products, Inc. HD96doc041910...
  • Page 4 Your Vehicle Identification Number And Customer Number Each Wood-Mizer sawmill has a 17-digit Vehicle Identification Number (VIN). see the fig- ure below for VIN locations. See the chart for VIN description. Each sawmill is also identified with a model number which includes the base model and the engine/motor configuration.
  • Page 5 F8008, LT40HD rev. F8695, and LT40HD Super rev. F8129 and later are shown in the following figure. V.I.N. LOCATIONS FOR LATER MODEL MILLS. The vehicle identification number locations for mills prior to LT30HD rev. F8534, LT30HD Super rev. F8008, LT40HD rev. F8695, and LT40HD Super rev. F8129 are shown in the following figure.

  • Page 7: Table Of Contents

    Table of Contents Section-Page SECTION 1 SAFETY & GENERAL INFORMATION Blade Handling......................1-1 Sawmill Setup......................1-2 Sawmill Operation..................... 1-3 Electric Sawmill ......................1-5 Belt Sizes ........................1-9 Blade Sizes ......................1-10 Cutting Capacity...................... 1-11 Engine/Motor Specifications ................... 1-12 Overall Dimensions ....................1-13 1.10 Components......................
  • Page 8 Table of Contents Section-Page SECTION 3 MAINTENANCE Wear Life........................3-1 Blade Guides ......................3-2 Hydraulic Log Loader ....................3-3 Blade Housing ......................3-4 Carriage Track, Wiper & Scrapers ................3-5 Vertical Mast Rails ....................3-6 Drum Switches ......................3-7 Miscellaneous Lubrication ..................3-8 Blade Tensioner......................
  • Page 9 Table of Contents Section-Page SECTION 5 SAWMILL ALIGNMENT Pre-Alignment Procedures..................5-1 Frame Setup....................... 5-2 Blade Installation And Alignment................5-3 Saw Head Slide Pad Adjustment................5-5 Adjusting The Lower Track Rollers................5-7 Adjusting Bed Rails To The Blade................5-9 Blade Guide Arm Vertical Adjustment ..............5-12 Blade Guide Arm Horizontal Adjustment...............

  • Page 11: Safety & General Information

    Safety & General Information Blade Handling SECTION 1 SAFETY & GENERAL INFORMATION This symbol calls your attention to instructions concerning your personal safety. Be sure to observe and follow these instructions. This symbol accompanies a signal word. The word DANGER refers to hazards that can cause death or serious, irreversible personal injury.

  • Page 12: Sawmill Setup

    Safety & General Information Sawmill Setup Sawmill Setup WARNING! Put front outrigger down before moving cutting head from the rest position. Failure to do so may result in serious injury. WARNING! Do not set up the mill on ground with more than a 10 degree incline.

  • Page 13: Sawmill Operation

    Safety & General Information Sawmill Operation Sawmill Operation DANGER! Never operate or tow the sawmill without all guards and covers in place and secured. Be sure the blade housing and pulley covers are in place and secure. Use the safety retainer pin and cable to fasten blade housing covers.
  • Page 14 Wood-Mizer sawmill. All Wood-Mizer mill owners are encouraged to become thoroughly familiar with these applicable laws and comply with them fully while using or towing the mill.

  • Page 15: Electric Sawmill

    Safety & General Information Electric Sawmill Electric Sawmill USE PROPER PROCEDURE WHEN CONDUCTING ELECTRICAL SAFETY CHECKS AND MAINTENANCE DANGER! Make sure all electrical installation, service and/or maintenance work is performed by a qualified electrician and is in accordance with applicable electrical codes. DANGER! Hazardous voltage inside the electric sawmill discon- nect box, starter box, and at the motor can cause shock, burns, or...
  • Page 16 Safety & General Information Electric Sawmill DANGER! Lockout procedures must be used during: Changing or adjusting blades Unjamming operations Cleaning Mechanical repair Electrical maintenance Retrieval of tools/parts from work area Activities where guards or electrical panel guard is open or removed Maintenance hazards include: Blade contact...
  • Page 17 Safety & General Information Electric Sawmill SAWMILL LOCKOUT PROCEDURE Lockout procedures must be followed (see ANSI Standard Z244.1-1982 and OSHA regu- lation 1910.147). Purpose: This procedure establishes the minimum requirements for lockout of energy sources that could cause injury. Responsibility: The responsibility for seeing that this procedure is followed is binding upon all workers.
  • Page 18 Owner’s Responsibility The procedures listed in this manual may not include all ANSI, OSHA, or locally required safety procedures. It is the owner/operator’s responsibility and not Wood-Mizer Products to ensure all operators are properly trained and informed of all safety protocols.

  • Page 19: Belt Sizes

    Safety & General Information Belt Sizes Belt Sizes See Table 1-1. Belt sizes for the LT30HD/40HD and LT30HD/40HD Super are shown. Description Belt Size Wood-Mizer Part # 15hp Electric Motor Drive Belt 2BX74 P10277-2 24hp Gas Engine Drive Belt 2BX74...

  • Page 20: Blade Sizes

    Blade Sizes Blade Sizes See Table 1-2. Wood-Mizer offers three types of blades to provide efficient sawing for all models of sawmills. The engine/motor size of your sawmill and the type of wood you saw should determine which blade you choose for optimum performance.

  • Page 21: Cutting Capacity

    4400 lbs. (1996 Kg.) on a mill equipped with bed extension re- quires auxiliary log handling equipment. See Table 1-4. The performance capacity of the LT30HD, LT40HD, LT30HD Super, and LT40HD Super sawmills is listed below. Peak cutting rates are measured in 12” (30 cm) wide red oak and represent the capability of the sawmill only.

  • Page 22: Engine/Motor Specifications

    Safety & General Information Engine/Motor Specifications Engine/Motor Specifications See Table 1-5. The power options available for the LT30HD, LT40HD, LT30HD Super, and LT40HD Super sawmills are listed below. Engine/Motor Type Manufac- Model Number turer 24HP Gasoline Onan P224 Baldor Custom...

  • Page 23: Overall Dimensions

    Safety & General Information Overall Dimensions Overall Dimensions See Table 1-6. The overall dimensions of the LT30HD, LT40HD, LT30HD Super, and LT40HD Super sawmills are listed below. Model Length Width Height Weight LT30HD 19’ 11" (5.3 m) 8’ 0” (2.4 m) 7’...

  • Page 24: Components

    1.10 Components See Figure 1-1. The major components of the Wood-Mizer LT30HD, LT40HD, LT30HD Super, and LT40HD Super are shown below. FIG. 1-1...

  • Page 25: Hydraulic Schematic

    Safety & General Information Hydraulic Schematic 1.11 Hydraulic Schematic FIG. 1-2 HYDRAULIC SCHEMATIC. Safety & General Information HD96doc041910 1-15...

  • Page 26: Hydraulic Components

    Safety & General Information Hydraulic Components 1.12 Hydraulic Components Compo- Mfg. Part Manufacturer Wood-Mizer Description nent Part.# P12847 J-D Hydraulic P12847 Hydraulic Cylinder, 3" Bore X 8" Stroke P13582 J-D Hydraulic P13582 Hydraulic Cylinder, Toe Board P13582 J-D Hydraulic P13582...

  • Page 27: Hydraulic Hoses

    Hose, 1/4" X 142" Hydraulic W/Fittings White Clamp Cylinder Top (LT40HD) P12548 Hose, 1/4" X 164" Hydraulic W/Fittings Gray Front Toe Board Top (LT30HD) P12540 Hose, 1/4" X 91" Hydraulic W/Fittings Gray Front Toe Board Top (LT40HD) P12542 Hose, 1/4" X 113" Hydraulic...
  • Page 28 Loading Arm Branch Base P12538 Hose, 1/4" X 55" Hydraulic W/Fittings Blue Loading Arm Cylinder Top P12545 Hose, 1/4" X 151" Hydraulic (LT30HD) W/Fittings Blue Loading Arm Cylinder Top P12549 Hose, 1/4" X 173" Hydraulic (LT40HD) W/Fittings Loading Arm Cylinder Bottom P12545 Hose, 1/4"...

  • Page 29: Setup & Operation Stationary Sawmill Setup

    SECTION 2 SETUP & OPERATION Stationary Sawmill Setup See Figure 2-1. Set up the mill on firm footing. Level by eye. Fasten the mill to the floor to prevent any creep after prolonged use. LT30HD Stationary Sawmill LT40HD Stationary Sawmill HD0069 FIG. 2-1 NOTE: Make sure the unit is level before securing.
  • Page 30 Setup & Operation Stationary Sawmill Setup DANGER! Do not operate a stationary sawmill without the feet securely fastened to the floor. If the feet are not securely fastened, loading and turning large logs could cause the sawmill to tip over. 3.

  • Page 31: Portable Sawmill Setup

    Setup & Operation Portable Sawmill Setup Portable Sawmill Setup WARNING! Do not set up the mill on ground with more than a 10 degree incline. If setup on an incline is necessary, put blocks under one side of the mill or dig out areas for outrig- ger legs to keep mill level.
  • Page 32 Setup & Operation Portable Sawmill Setup 1. Unhitch the mill from the vehicle. See Figure 2-3. FIG. 2-3 2. Lower and set the front three outriggers. Lift the weight from the locking pin using the jack handle. Pull the locking pin to release the outrigger and lower the outrigger as necessary. Secure with the locking pin.
  • Page 33 Setup & Operation Portable Sawmill Setup Provided Adjustment Wrench Height Adjustment Nut Existing Outrigger Guide Locking Pin FAO Base SM0213 FIG. 2-3. BASE HEIGHT ADJUSTMENT (FOR FINE ADJUST OUTRIGGER ONLY). 3. Unhook the carriage safety chain, located at the bottom of the vertical mast, near the bat- tery box.
  • Page 34 Setup & Operation Portable Sawmill Setup CAUTION! Do not adjust the FAO outrigger base height while there is weight on the FAO. Damage to the FAO may result. 7. Remove the fenders by lifting them out of the slots. CAUTION! To prevent fender damage, remove fenders before operating sawmill or loading logs.

  • Page 35: Replacing The Blade

    Setup & Operation Replacing The Blade Replacing The Blade WARNING! Always wear gloves and eye protection when- ever handling bandsaw blades. Changing blades is safest when done by one person! Keep all other persons away from work area when changing blades. Do not change the blade with the engine running.

  • Page 36: Tensioning The Blade

    Setup & Operation Tensioning The Blade Tensioning The Blade See Figure 2-5. Tension the blade by turning the hydraulic tensioning handle clockwise until the tension gauge indicates the recommended tension. Blade Tensioner Gauge Blade Tensioner Handle Cant Control Handle SM0043 FIG.

  • Page 37: Tracking The Blade

    Setup & Operation Tracking The Blade Tracking The Blade Make sure the middle blade housing cover is closed and all persons are clear of the open side of the saw head. Start the engine (or motor). Pull lightly on the clutch handle, rotating the blade until the blade positions itself on the wheels.

  • Page 38: Starting The Engine (Or Motor)

    See the appropriate manual supplied with your specific engine/motor configuration for starting and operating instructions. DANGER! Read the entire manual before operating your Wood-Mizer sawmill. DANGER! Never operate the sawmill without all guards and covers in place and secured. Be sure the blade housing and pulley covers are in place and secure.

  • Page 39: Hydraulic Control Operation

    Setup & Operation Hydraulic Control Operation Hydraulic Control Operation See Figure 2-7. The hydraulic control levers become operational when the contacts at the bottom of the carriage touch the power strip on the frame tube. The hydraulic control levers will only work when the cutting head is close enough to the front end of the mill to touch the power strip.
  • Page 40 Setup & Operation Hydraulic Control Operation See Figure 2-8. The two-stage clamp can be raised or lowered by lowering the clamp lever and moving the clamp all the way out. The clamp will engage the flip arm and flip the clamp in either the up or down position.
  • Page 41 Setup & Operation Hydraulic Control Operation 7. Manually lower the log loader so the legs rest on the ground. CAUTION! Be careful when lowering the log loader. Do not drop the loader onto the ground or perform any action which might break the velocity fuse valves on the loader cylinders.

  • Page 42: Loading, Turning, And Clamping Logs

    Setup & Operation Loading, Turning, And Clamping Logs Loading, Turning, And Clamping Logs CAUTION! Be sure the pivot end rails, turning arm, clamp, and toe boards are out of the way before loading a log onto the bed. Be sure logs are positioned on the bed so that they will not damage the manual winch when loaded.
  • Page 43 Setup & Operation Loading, Turning, And Clamping Logs 5. Lower the turner lever to lower the turner arm below the log. 6. Raise the turner arm to get a new bite on the log. 7. Disengage the clamp. 8. The log can be turned now. Repeat steps 4 through 7 until the log is turned as desired. To Clamp Logs 1.

  • Page 44: Clamp Extension

    Setup & Operation Clamp Extension Clamp Extension The clamp extension stored at the end of the clamp tube can be used for clamping small cants or logs. The clamp extension is used with the hydraulic clamp in its down position. See Figure 2-9.

  • Page 45: Up/Down Operation

    Setup & Operation Up/Down Operation 2.10 Up/Down Operation 1. Install a blade, if needed, and check for correct blade tension. See Section 2.4. 2. Set the cutting head to the desired height. (The blade height scale show the height of the blade above the bed rails.) See Figure 2-10.

  • Page 46: Blade Guide Arm Operation

    Setup & Operation Blade Guide Arm Operation 2.11 Blade Guide Arm Operation 1. Look down the length of the log to see its maximum width. The outer blade guide should be adjusted to clear the widest section of the log by less than 1" (25.4 mm). 2.

  • Page 47: Clutch/Brake Operation

    Setup & Operation Clutch/Brake Operation 2.12 Clutch/Brake Operation 1. Clear any loose objects from the area of the blade, motor, and drive belt. 2. Make sure the clamp and side supports are adjusted below the level of your first few cuts. 3.

  • Page 48: Power Feed Operation

    Setup & Operation Power Feed Operation 2.13 Power Feed Operation See Figure 2-13. The power feed system moves the carriage forward and backward by using two switches on the control panel. Carriage Forward Carriage Reverse 3H0124 Forward Feed Rate FIG. 2-13 Carriage Feed Rate The carriage feed rate switch controls the speed at which the carriage travels forward.
  • Page 49 Setup & Operation Power Feed Operation DANGER! Failure to move the up/down switch to the neu- tral or "off" position when released will result in failure to stop saw head carriage movement. DANGER! Make sure the carriage fwd/rev switch is in the neutral position before turning the key switch to the on or ACC position.

  • Page 50: Cutting The Log

    Cutting The Log 2.14 Cutting The Log The following steps guide you through normal operation of the Wood-Mizer sawmill. 1. Once the log is placed where you want it and clamped firmly turn the key switch to the ACC position.

  • Page 51: Edging

    Setup & Operation Edging 2.15 Edging The following steps guide you through edging boards on the Wood-Mizer sawmill. 1. Raise the side supports to 1/2 the height of the flitches, or the boards that need to be edged. 2. Stack the flitches on edge against the side supports.

  • Page 52: Blade Height Sight Gauge

    Blade Height Sight Gauge 2.16 Blade Height Sight Gauge NOTE: Sight gauge supplied on LT30HD through F8522, LT40HD through F8458 & LT40HD Super through F8522 only. See Figure 2-14. The sight gauge is provided on the cutting head carriage to help you decide where to make the first cuts on a log.

  • Page 53: Blade Height Scale

    Setup & Operation Blade Height Scale 2.17 Blade Height Scale See Figure 2-15. The blade height scale is attached to the carriage head frame. It includes: a blade height indicator an inch scale a quarter scale Blade Height Indicator Quarter Scale Inch Scale...
  • Page 54 Setup & Operation Blade Height Scale The Quarter Scale See Table 2-2. Two quarter scales are provided with four sets of marks. Each set repre- sents a specific lumber thickness. Saw kerf and shrinkage allowance are included, but actual board thickness will vary slightly depending on blade thickness and tooth set. To choose which scale to use, determine what finished thickness you want to end up with.

  • Page 55: Water Lube Operation

    Setup & Operation Water Lube Operation 2.18 Water Lube Operation See Figure 2-16. The Water Lube System keeps the blade clean. Water flows from a 5-gallon (18.9 liter) bottle through a hose to the blade guide where the blade enters the log.

  • Page 56: Preparing The Sawmill For Towing

    Setup & Operation Preparing The Sawmill For Towing 2.19 Preparing The Sawmill For Towing The Wood-Mizer trailer package makes transporting your sawmill easy and convenient. To get your sawmill ready for towing, follow these instructions. CAUTION! If the weight of the sawmill exceeds 3,000 lbs (1361 Kg) for any reason, an auxilliary braking system (such as electric brakes) must be used.
  • Page 57 Setup & Operation Preparing The Sawmill For Towing See Figure 2-17. Rest Pin Lock Pin HD0075 FIG. 2-17 8. Continue lowering the head 3/4" (19mm). until it contacts the stop blocks on the mast rails. CAUTION! Failure to properly secure the saw head can result in severe machine damage.
  • Page 58 Setup & Operation Preparing The Sawmill For Towing 9. If necessary, adjust the two stops located at the bottom of the mast so the saw head con- tacts them after it is lowered 3/4" (19mm) past where it contacts the rest pin. See Figure 2-18.
  • Page 59 Setup & Operation Preparing The Sawmill For Towing 12. Remove all loose objects from the bed of the mill. Store the outrigger jack handle in the bracket provided on the rear/loading-side outrigger guide. Reel in the winch cable. Remove the winch handle. 13.
  • Page 60 Setup & Operation Preparing The Sawmill For Towing 2-32 HD96doc041910 Setup & Operation...

  • Page 61: Wear Life

    Maintenance Wear Life SECTION 3 MAINTENANCE This section lists the maintenance procedures that need to be performed. The Short Interval Maintenance Schedule lists procedures that need to be performed every 4, 8 or 25 hours.The Maintenance Log lists procedures that need to be performed every 50, 100, 200, 300, 500, or 1000 hours.

  • Page 62: Blade Guides

    2. Check the rollers for performance and wear every blade change. Make sure the rollers are clean and spinning freely. If not, rebuild them. Replace any rollers which have worn smooth or have become cone shaped. See The LT30HD/40HD Parts manual for blade guide rebuild kits and complete roller assemblies.

  • Page 63: Hydraulic Log Loader

    Maintenance Hydraulic Log Loader Hydraulic Log Loader Remove all sawdust and debris from around the velocity fuse valves every 8 hours of operation. The valves are located at the bottom of the log loader cylinders. Maintenance HD96doc041910...

  • Page 64: Blade Housing

    Maintenance Blade Housing Blade Housing 1. Remove the excess sawdust from the blade wheel housings and sawdust chute every blade change. See Figure 3-2. 2. Make sure the blade screw in the top center of the C-frame is 1/16" (1.5 mm) below the bottom of the blade.

  • Page 65: Carriage Track, Wiper & Scrapers

    Maintenance Carriage Track, Wiper & Scrapers Carriage Track, Wiper & Scrapers See Figure 3-3. 1. Clean the upper and lower track rails to remove any sawdust and sap buildup every eight hours of operation. Lubricate the lower track rail by wiping it with Dexron III ATF. 2.

  • Page 66: Vertical Mast Rails

    Maintenance Vertical Mast Rails Vertical Mast Rails Clean and lubricate the vertical mast rails every 50 hours of operation. Clean with solvent and remove any rust with a light-grade sand paper or emery cloth. Lubricate the mast with motor oil or automatic transmission fluid (ATF). CAUTION! Never use grease on the mast rails as it will col- lect sawdust.

  • Page 67: Drum Switches

    Lubricate the up/down and power feed drum switch contacts inside the control panel every fifty hours of operation. Use only contact grease supplied by Wood-Mizer. Remove the control panel cover. Use a cotton swab to apply grease to the switch contact ends.

  • Page 68: Miscellaneous Lubrication

    Maintenance Miscellaneous Lubrication Miscellaneous Lubrication 1. Apply a thin film of a NLGI No. 2 grade lithium grease to the blade guide arm every fifty hours of operation to help prevent it from rusting. 2. Grease the clamp mechanism, loading arm, and side supports with a NLGI No. 2 grade lithium grease every fifty hours of operation.

  • Page 69: Blade Tensioner

    Maintenance Blade Tensioner Blade Tensioner 1. Lubricate the chrome rods of the tensioner system with a heavy duty teflon spray lubri- cant, such as Gunk L508, every fifty hours of operation. 2. Lubricate the tensioner screw handle with a NLGI No. 2 grade lithium grease as needed. See Figure 3-4.

  • Page 70: Blade Wheel Belts

    Maintenance Blade Wheel Belts 3.10 Blade Wheel Belts 1. Rotate the blade wheel belts and check them for wear. Rotating the belts every 50 hours will give you longer belt life. Replace belts as necessary. Use only B57 belts manufac- tured by Goodyear or Browning.

  • Page 71: Brake Strap Adjustment

    Maintenance Brake Strap Adjustment 3.11 Brake Strap Adjustment Check the brake strap for wear every 200 hours of operation. Replace if damaged or worn. Also check and adjust the brake strap if the blade does not stop quickly, unusual sounds occur when the brake is applied, or a sudden change is noticed in the clutch handle posi- tion when the clutch is disengaged.
  • Page 72 Maintenance Brake Strap Adjustment Super models: See Figure 3-6. Loosen the two nuts on the upper brake strap bracket. Slide the bracket and brake strap down until snug. Retighten the bolts. Replace the belt cover. NOTE: Super models built before 5/96 use a different type of brake strap and bracket. This style should be retrofitted with the bracket and strap illustrated below.

  • Page 73: Hydraulic System

    Maintenance Hydraulic System 3.12 Hydraulic System 1. Check the hydraulic fluid level every fifty hours of operation. Add fluid as necessary. The level in the hydraulic pump should be 4 1/2" (114 mm) with all cylinders collapsed. If humidity is a problem or the mill is used outside in humid weather, drain and replace two quarts (.95 liters) of fluid every six months.

  • Page 74: Drive Bearing

    Maintenance Drive Bearing 3.13 Drive Bearing Refill the fluid in the drive-side cylinder bearing housing every 1000 hours of operation. Remove the top and bottom oil plugs. Pour an Automatic Transmission Fluid (ATF) such 1000 as Dexron III ATF into the top hole until it begins to flow from the bottom hole. Reinstall the square oil plug to the bottom hole and the vented oil plug to the top hole.

  • Page 75: Up/Down System

    Maintenance Up/Down System 3.14 Up/Down System 1. Grease the up/down gear reducer shaft bearing with a NLGI No. 2 grade lithium grease 1000 every 1000 hours of operation. See Figure 3-9. FIG. 3-9 Maintenance HD96doc041910 3-15...
  • Page 76 Maintenance Up/Down System 2. Adjust the up/down belt as needed. Remove the up/down housing cover. To tighten the belt, loosen the two motor mount nuts. Adjust the bolt underneath the motor upward so there is 3/8" (9.5 mm) deflection with a 7 lb. (3.2 Kg) deflection force. Tighten the jam nut to secure the bolt in place.
  • Page 77 Repeat every 5000 hours or every 2 years, whichever comes first. Super models: Drain and refill the gearbox with 24 ounces of oil after every 5000 hours of sawmill operation or every 2 years, whichever comes first. Wood-Mizer offers replacement gear oil in 8 ounce bottles. Maintenance HD96doc041910 3-17...

  • Page 78: Power Feed

    Maintenance Power Feed 3.15 Power Feed 1. Adjust the power feed belt as needed. When the power feed belt gets loose, it will begin slipping. This causes the carriage to not move forward when cutting. To retighten the belt, remove the feed motor cover. Loosen the three motor mounting bolts. See Figure 3-12.

  • Page 79: Miscellaneous Maintenance

    Maintenance Miscellaneous Maintenance 3.16 Miscellaneous Maintenance 1. Check the mill alignment every setup. See Section 5, Alignment. 2. Make sure all safety warning decals are readable. Remove sawdust and dirt. Replace any damaged or unreadable decals immediately. Order decals from your Customer Service Representative.
  • Page 81 LT30HD/40HD Short Interval Maintenance Schedule (Check engine and option manuals for additional maintenance procedures) PROCEDURE MANUAL REFERENCE EVERY 4 HOURS SEE SECTION 3.2 Lubricate Blade Guide Rollers EVERY BLADE CHANGE SEE SECTION 3.2 Check Blade Guide Roller Performance SEE SECTION 3.4...
  • Page 83 WOOD-MIZER LT30HD/LT40HD MAINTENANCE LOG (Check Engine And Option Manuals For Additional Maintenance Procedures) PROCEDURE MANUAL TOTAL HOURS OF OPERATION REFERENCE FILL IN THE DATE AND THE MACHINE HOURS AS YOU PERFORM EACH PROCEDURE. A SHADED BOX INDICATES MAINTENANCE IS NOT NEEDED AT THIS TIME.
  • Page 84 WOOD-MIZER LT30HD/LT40HD MAINTENANCE LOG (Check Engine And Option Manuals For Additional Maintenance Procedures) PROCEDURE MANUAL TOTAL HOURS OF OPERATION REFERENCE FILL IN THE DATE AND THE MACHINE HOURS AS YOU PERFORM EACH PROCEDURE. A SHADED BOX INDICATES MAINTENANCE IS NOT NEEDED AT THIS TIME.
  • Page 85 WOOD-MIZER LT30HD/LT40HD MAINTENANCE LOG (Check Engine And Option Manuals For Additional Maintenance Procedures) PROCEDURE MANUAL TOTAL HOURS OF OPERATION REFERENCE FILL IN THE DATE AND THE MACHINE HOURS AS YOU PERFORM EACH PROCEDURE. A SHADED BOX INDICATES MAINTENANCE IS NOT NEEDED AT THIS TIME.
  • Page 86 WOOD-MIZER LT30HD/LT40HD MAINTENANCE LOG (Check Engine And Option Manuals For Additional Maintenance Procedures) PROCEDURE MANUAL TOTAL HOURS OF OPERATION REFERENCE FILL IN THE DATE AND THE MACHINE HOURS AS YOU PERFORM EACH PROCEDURE. A SHADED BOX INDICATES MAINTENANCE IS NOT NEEDED AT THIS TIME.
  • Page 87 WOOD-MIZER LT30HD/LT40HD MAINTENANCE LOG (Check Engine And Option Manuals For Additional Maintenance Procedures) PROCEDURE MANUAL TOTAL HOURS OF OPERATION REFERENCE FILL IN THE DATE AND THE MACHINE HOURS AS YOU PERFORM EACH PROCEDURE. A SHADED BOX INDICATES MAINTENANCE IS NOT NEEDED AT THIS TIME.
  • Page 88 WOOD-MIZER LT30HD/LT40HD MAINTENANCE LOG (Check Engine And Option Manuals For Additional Maintenance Procedures) PROCEDURE MANUAL TOTAL HOURS OF OPERATION REFERENCE FILL IN THE DATE AND THE MACHINE HOURS AS YOU PERFORM EACH PROCEDURE. A SHADED BOX INDICATES MAINTENANCE IS NOT NEEDED AT THIS TIME.

  • Page 89: Troubleshooting Guide

    Troubleshooting Guide Sawing Problems SECTION 4 TROUBLESHOOTING GUIDE Sawing Problems PROBLEM CAUSE SOLUTION Blades Dull Quickly Dirty logs Clean or debark logs, especially on entry side of the cut When grinding teeth, heating Grind just enough metal to restore too much and causing teeth to sharpness to the teeth.
  • Page 90 Troubleshooting Guide Sawing Problems Boards Thick Or Thin On Stress in log which causes log After log has been squared, take Ends Or Middle Of Board to not lay flat on the bed equal cuts off opposing sides. Take a board off the top.

  • Page 91: Electrical Problems

    Replace drum switch or remove control panel cover and clean and lubricate contacts NOTE: Use only contact grease supplied by Wood-Mizer. Drum switch spring broken Manually move the power feed or up/down switch back to neutral or "off" position. Replace drum switch spring...
  • Page 92 Troubleshooting Guide Electrical Problems Nothing Works Electrically Dead battery Check for short circuit or turn OFF key Bad circuit breaker Replace. NOTE: A retrofit is available for Super model mills which provides a second circuit breaker. This will allow the power feed and up/down to be operated at the same time without nui- sance tripping of the breaker.

  • Page 93: Power Feed Problems

    Power Feed Problems Power Feed Problems NOTE: LT30HD Rev. F9535+, LT30HD Super Rev. F9040+, LT40HD Rev. F9823+, LT40HD Super Rev. F9439+: The power feed circuit board is equipped with LED lights to help determine if the circuit board or feed rate switch are the cause of any feed problems you may encounter.
  • Page 94 Troubleshooting Guide Power Feed Problems Chain is dragging Make sure chain is centered on cam follower bearing; Clean and lubri- cate chain; Adjust chain tension. Allow motor to cool before restarting Chain is improperly tensioned Adjust chain tension. Allow motor to cool before restarting Seat load is excessive Check seat bearings for freedom of...

  • Page 95: Power Feed Circuit Troubleshooting

    Wood-Mizer. The light will flash about once every second and will deactivate the output circuit. If the power feed motor is a Wood-Mizer replacement, replace the circuit board.
  • Page 96 Troubleshooting Guide Power Feed Circuit Troubleshooting CL - This light indicates an extreme overload condition of the power feed motor or a short in the wiring between the motor and circuit board. The light will flash about once every second and deactivate the feed system until the problem is corrected. TEMP - When lit, this light indicates the temperature of the output circuit is too high and will shut off the circuit.

  • Page 97: Hydraulic Problems

    Replace solenoid. NOTE: The See Monarch manual for trou- solenoid is not a standard automotive bleshooting solenoid type. Order from Monarch or Wood-Mizer only Low or dead battery Test battery. Replace or recharge as necessary Defective pump motor Remove motor from pump and inspect.
  • Page 98 Troubleshooting Guide Hydraulic Problems Low fluid level Check fluid level. Add an all-season hydraulic fluid such as Amoco Rycon Oil MV or Mobil Multipurpose ATF (automatic transmission fluid) until level is 4 - 4 1/2" from bottom of reservoir with all cylinders retracted Pressure relief valve moved Adjust pressure relief valve.
  • Page 99 Troubleshooting Guide Hydraulic Problems Low air temperature causing Allow fluid to warm up. Synthetic flu- fluid to thicken ids are available that allow for hydraulic operation in cold weather conditions (Univis HVI 13) Hydraulic Turner Goes Up Spring weakening in sequence Locate sequence valve at top of Before Or At Same Time As valve...

  • Page 100: Engine/Motor And Drive Pulleys Alignment

    Troubleshooting Guide Engine/Motor and Drive Pulleys Alignment Engine/Motor and Drive Pulleys Alignment 1. Install the drive belt. 2. Use a straight edge to align the engine/motor pulley to the drive pulley. Also check that the engine pulley is within 1/8" square with the drive pulley. Loosen the engine mounting bolts and rotate the engine if necessary.

  • Page 101: Power Feed Variable Speed Switch Test

    Troubleshooting Guide Power Feed Variable Speed Switch Test Power Feed Variable Speed Switch Test With the feed rate dial switch all the way down, move the shaft of the dial back and forth to see if there is a jerky response. Turn the dial and move the shaft back and forth again. Repeat several times.

  • Page 102: Power Feed Preliminary Test

    Troubleshooting Guide Power Feed Preliminary Test Power Feed Preliminary Test This test will determine if the problem is a mechanical or electrical. 1. Remove the drive belt from the power feed drive pulley. 2. Turn the key switch to the ACC position. Put the carriage fwd/rev switch into the forward position and turn the feed rate dial through all speeds.

  • Page 103: Power Feed Mechanical Test

    Troubleshooting Guide Power Feed Mechanical Test Power Feed Mechanical Test 1. Remove the weight from the track rollers. They should turn smoothly and easily with very little play. 2. Make sure the middle track cover is not bent or touching the top rail. 3.

  • Page 104: Hydraulic Pressure Test

    Troubleshooting Guide Hydraulic Pressure Test 4.10 Hydraulic Pressure Test To check hydraulic pressure: 1. Disconnect power from the pump by moving the saw head forward until it no longer con- tacts the power strip. 2. Locate the loading arm port fitting on the hydraulic valve body. See Figure 4-2.

  • Page 105: Sawmill Alignment Pre-Alignment Procedures

    SECTION 5 SAWMILL ALIGNMENT Pre-Alignment Procedures The Wood-Mizer sawmill is factory aligned. Periodically check the sawmill alignment and adjust if necessary. This chapter explains how to align the entire sawmill. Care should be taken in performing these steps. Sawmill alignment determines the accuracy and square- ness of your cuts.

  • Page 106: Frame Setup

    Shim the feet so the weight of the sawmill is evenly supported. Portable sawmills should also be setup on firm, level ground: LT30HD: Adjust the two middle outriggers on the main frame tube down just enough to lift weight from the trailer tire.

  • Page 107: Blade Installation And Alignment

    Sawmill Alignment Blade Installation And Alignment Blade Installation And Alignment See Figure 5-1. Install a blade and apply the appropriate tension (See Section 2.4 Ten- sioning The Blade). Blade tension is adjusted with the tension handle shown. Blade Tensioner Gauge Blade Tensioner Handle Cant Control...
  • Page 108 Sawmill Alignment Blade Installation And Alignment See Figure 5-2. The blade wheels should be adjusted so that the gullet of 1 1/4" blades ride 1/8" (3 mm) out from the front edge of the wheels (±1/32 [.75 mm]). The gullet of 1 1/2"...

  • Page 109: Saw Head Slide Pad Adjustment

    Sawmill Alignment Saw Head Slide Pad Adjustment Saw Head Slide Pad Adjustment There are eight nylon pads positioned between the saw head frame and vertical mast. The spacing of the pads is factory set and rarely needs adjusting. To check the pad spac- ing, perform the following steps.
  • Page 110 Sawmill Alignment Saw Head Slide Pad Adjustment 3. Loosen the upper locking bolts and turn the adjusting bolt as necessary to provide the pad spacing described in Step 1. 4. Lower the saw head to the bottom of the vertical mast. Check the bottom set of four pads. There should be a small gap between one of the outer pads and the mast rail.

  • Page 111: Adjusting The Lower Track Rollers

    Sawmill Alignment Adjusting The Lower Track Rollers Adjusting The Lower Track Rollers Making these adjustments correctly will give you square cuts and accurate dimensions across the width of your boards. 1. Using the feed controls, move the saw carriage so that the blade is positioned over the front pivot end rail.
  • Page 112 Sawmill Alignment Adjusting The Lower Track Rollers 5. Remove the blade guides, or adjust them so that they do not touch the blade. 6. Open the adjustable blade guide arm to within 1/2" (15 mm) of full open. 7. Move the carriage back to the front pivot end rail. Raise the cutting head until the bottom of the blade is 17"...

  • Page 113: Adjusting Bed Rails To The Blade

    Sawmill Alignment Adjusting Bed Rails To The Blade Adjusting Bed Rails To The Blade 1. Move the saw head until the blade is centered over the clamp. 2. Raise the saw head until the blade measures 14 1/2" (360 mm) from the top of the clamp. Use a rule to determine the actual distance of the blade to the clamp.
  • Page 114 Sawmill Alignment Adjusting Bed Rails To The Blade See Figure 5-7. SM0134B 15" (375mm) to blade 15 1/32" (375mm) to blade Inner Height Adjustment Outer Height Adjustment Bolt FIG. 5-7 8. Loosen the jam nut and turn the outer adjustment bolt to adjust the height of the outer end of the pivot rail.
  • Page 115 Sawmill Alignment Adjusting Bed Rails To The Blade See Figure 5-8. Blade 15“ (375.0 mm) 15“ (375.0 mm) Bed Rail Clamping Bolt Clamping Bolt Adjustment Adjustment Bolt Bolt SM0064 FIG. 5-8 11. Loosen the bed rail clamping bolts and turn the adjustment bolts to move the bed rails to the blade if necessary.

  • Page 116: Blade Guide Arm Vertical Adjustment

    Sawmill Alignment Blade Guide Arm Vertical Adjustment Blade Guide Arm Vertical Adjustment 1. Move the saw head so that the blade guide arm is directly over a bed rail. 2. Adjust the blade guide arm out to within 1/2" (15 mm) of full open. 3.

  • Page 117: Blade Guide Arm Horizontal Adjustment

    Sawmill Alignment Blade Guide Arm Horizontal Adjustment Blade Guide Arm Horizontal Adjustment 1. Put the blade guide assembly back in the arm (if you took it out). Put the assembly back so that the flanged collar on the roller is about 1/8" (3.0 mm) from the back of the blade when the throat is 1/2"...
  • Page 118 Sawmill Alignment Blade Guide Arm Horizontal Adjustment See Figure 5-11. Adjustment Nuts Adjustment Nuts SM0066 FIG. 5-11 4. Adjusting the inside two rollers (furthest from the arm motor) inward will cause the flange to move toward the blade. 5. Adjusting the two inside rollers outward will cause the flange to move away from the blade.

  • Page 119: Aligning The Blade Guides

    Aligning The Blade Guides Aligning The Blade Guides Each Wood-Mizer sawmill has two blade guide assemblies that help the blade maintain a straight cut. The two blade guide assemblies are positioned on the saw head to guide the blade on each side of the material being cut.

  • Page 120: Blade Deflection

    Sawmill Alignment Blade Deflection 5.10 Blade Deflection Perform the following steps to achieve proper blade deflection with the blade guides. 1. Raise the carriage until the blade is 15" (375 mm) above a bed rail. Measure the actual distance with a tape from the top of the rail to the bottom of the blade. 2.

  • Page 121: Blade Guide Vertical Tilt Adjustment

    Sawmill Alignment Blade Guide Vertical Tilt Adjustment 5.11 Blade Guide Vertical Tilt Adjustment Check that the blade guide does not tilt the blade up or down. A Blade Guide Alignment Tool (BGAT) is provided to help you measure the vertical tilt of the blade. 1.
  • Page 122 Sawmill Alignment Blade Guide Vertical Tilt Adjustment See Figure 5-14. Loosen jam nuts and turn screws to tilt roller up or down SM0070 FIG. 5-14 8. Move the carriage forward so the back end of the tool is over the bed rail. 9.

  • Page 123: Blade Guide Spacing

    Sawmill Alignment Blade Guide Spacing 5.12 Blade Guide Spacing HINT: When adjusting blade guide spacing, loosen the top set screw and one side set screw only. This will insure horizontal and vertical tilt adjustments are maintained when the set screws are retightened. 1.

  • Page 124: Horizontal Tilt Adjustment

    Sawmill Alignment Horizontal Tilt Adjustment 5.13 Horizontal Tilt Adjustment 1. Finally, both blade guides must be tilted horizontally. Adjust the blade guide arm half way See Figure 5-16. Turn side set screws to adjust horizontal tilt ‘A’ ‘B’ SM0072 FIG. 5-16 2.

  • Page 125: Horizontal Adjustment Of Side Supports

    Sawmill Alignment Horizontal Adjustment Of Side Supports 5.14 Horizontal Adjustment Of Side Supports The side supports are used to clamp flats on a log to set the squareness of the next cut. The cut will only be as square as the supports. 1.

  • Page 126: Vertical Adjustment Of Side Supports

    Sawmill Alignment Vertical Adjustment Of Side Supports 5.15 Vertical Adjustment Of Side Supports 1. Place a flat board across the bed rails. 2. Swing a side support up so that it is vertical. 3. Pull back at the top of the support to eliminate slack as if a log were being clamped against it.

  • Page 127: Clamp Stop Adjustment

    Sawmill Alignment Clamp Stop Adjustment 5.16 Clamp Stop Adjustment 1. Once the side supports are aligned, pivot them down to their horizontal position. 2. Tie a string across the face of the side supports. See Figure 5-19. 3. Loosen the clamp stop bolts and adjust the clamp stop until it touches the string. FIG.

  • Page 128: Sight Gauge Adjustment

    Sawmill Alignment Sight Gauge Adjustment 5.17 Sight Gauge Adjustment NOTE: Sight gauge supplied on LT30HD through F8522, LT40HD through F8458 & LT40HD Super through F8522 only. After adjustments to the bed rails and blade guides are complete, adjust the sight gauge so that it accurately shows the position of the blade over the bed rails.

  • Page 129: Saw Head Tilt

    Sawmill Alignment Saw Head Tilt 5.18 Saw Head Tilt As the blade enters a wide log or cant, the outside of the saw head will drop down slightly. To compensate for the drop, use the lower track roller horizontal bolts to raise the outside of the saw head 1/16"...

  • Page 130: Blade Height Scale Adjustment

    Sawmill Alignment Blade Height Scale Adjustment 5.19 Blade Height Scale Adjustment After the entire sawmill has been aligned and all adjustments made, check that the blade height scale indicates the true distance from the blade to the bed rails. 1. Move the saw head so the blade is positioned 14 3/4" (375 mm) above the bed rails by actual measurement with a rule.
  • Page 131 INDEX clutch/brake lever operation 2-19 alignment blade guide 5-15 blade installation frame setup hydraulic lower track rollers components 1-16 main bed rails control operation 2-11 sawmill fluid level 3-13 slide pad adjustment hoses 1-17 schematic 1-15 troubleshooting problems battery troubleshooting problems leveling logs 2-15 belt...
  • Page 132 INDEX scale blade height adjustment 5-26 blade height operation 2-25 inch height 2-25 quarter inch 2-26 setup portable sawmill stationary sawmill side supports horizontal adjustment 5-21 vertical adjustment 5-22 switch power feed & up/down maintenance tensioner maintenance track maintenance troubleshooting electrical problems hydraulic problems power feed problems...

This manual is also suitable for:

Lt30hd superLt40hdLt40hd super

Table of Contents
