Section E Hydraulics Section E
24 - 10 Hydraulic Pump 24 - 10
Dismantling (cont'd)
32 Remove the plate 81.
33 Push out the drive gear 76 and remove the side plate
79.
Note: Care must be taken not to lose the square ring 88
attached to the side plate 79 .
34 Remove the idle gear 77 .
35 Remove the side plate 78 .
9803/6020 Issue 1
