1.
OVERVIEW ..........................................................................................................................1
2.
INSTALLATION ...................................................................................................................4
2.1.
CARE AND HANDLING OF OPTICAL FIBER ...............................................................................5
2.1.1.
Safety .......................................................................................................................................5
2.1.2.
Assembly..................................................................................................................................5
2.1.3.
Labeling....................................................................................................................................5
2.1.4.
Handling and Connecting Fibers..............................................................................................6
3.
SPECIFICATIONS................................................................................................................7
3.1.
SERIAL VIDEO INPUT ...................................................................................................................7
3.2.
SERIAL VIDEO OUTPUTS.............................................................................................................7
3.3.
OPTICAL OUTPUT.........................................................................................................................7
3.4.
OPTICAL INPUT.............................................................................................................................8
3.5.
ELECTRICAL..................................................................................................................................8
3.6.
PHYSICAL ......................................................................................................................................8
3.7.
COMPLIANCE ................................................................................................................................8
4.
STATUS INDICATORS AND DISPLAYS.............................................................................9
4.1.
STATUS INDICATOR LEDS ..........................................................................................................9
4.2.
CARD EDGE DISPLAY ................................................................................................................10
4.2.1.
STAT Menu ............................................................................................................................11
4.2.1.1.
Displaying the Optical Link Data Standard .....................................................................11
4.2.1.2.
Displaying the Current Interval Counter..........................................................................11
4.2.1.3.
Displaying the Last Interval Counter ...............................................................................12
4.2.1.4.
Displaying the Errored Seconds Ratio ............................................................................13
4.2.1.5.
Displaying the Loss of Signal seconds in Line Layer......................................................13
4.2.1.6.
Displaying the Link Output Reference Clock Source ......................................................13
4.2.1.7.
Displaying the Link Input Status......................................................................................13
4.2.1.8.
Displaying the TDM Data Errors .....................................................................................13
4.2.1.9.
Displaying the Video Standard........................................................................................14
4.2.1.10.
Detecting the EDH Presence in a Compatible Signal .....................................................14
4.2.1.11.
Displaying the SDTI Status .............................................................................................14
4.2.1.12.
Ethernet Status and Speed.............................................................................................14
4.2.1.13.
Performance Monitoring and Error Reporting .................................................................14
4.2.2.
Control Menu..........................................................................................................................15
4.2.2.1.
Setting the Optical Link Standard ...................................................................................16
4.2.2.2.
Setting the Behavior of Laser When There is No Applied Video ....................................16
4.2.2.3.
Setting the Clock Source ................................................................................................16
4.2.2.4.
Clearing the Counters .....................................................................................................16
4.2.2.5.
Setting the Severe Errored Second Threshold ...............................................................17
7707VT-8-OC48 Eight Channel SDI + Ethernet SONET/SDH Fiber Transmitter
TABLE OF CONTENTS
Revision 1.4.2
7700 MultiFrame Manual
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for evertz 7707VT-8-OC48
Summary of Contents for evertz 7707VT-8-OC48
-
Page 1: Table Of Contents
7700 MultiFrame Manual 7707VT-8-OC48 Eight Channel SDI + Ethernet SONET/SDH Fiber Transmitter TABLE OF CONTENTS OVERVIEW ..........................1 INSTALLATION ........................4 2.1. CARE AND HANDLING OF OPTICAL FIBER ................5 2.1.1. Safety ............................5 2.1.2. Assembly..........................5 2.1.3. Labeling............................5 2.1.4. Handling and Connecting Fibers....................6 SPECIFICATIONS........................7 3.1. - Page 2 7700 MultiFrame Manual 7707VT-8-OC48 Eight Channel SDI + Ethernet SONET/SDH Fiber Transmitter 4.2.2.6. Activating or Deactivating EDH Processing ..............17 4.2.2.7. Signal BLOCK Configuration ..................17 4.2.2.8. Setting the Orientation of the Text on the Card Edge Display ........18 4.2.2.9. Monitoring a Specific Channel ..................18 JUMPERS..........................
- Page 3 March 2010 Information contained in this manual is believed to be accurate and reliable. However, Evertz assumes no responsibility for the use thereof nor for the rights of third parties, which may be effected in any way by the use thereof. Any representations in this document concerning performance of Evertz products are for informational use only and are not warranties of future performance, either express or implied.
- Page 4 The 7707VT-8-OC48 DWDM card produces +7dBm of power, which will damage the receiver if connected directly. Do not hook up 7707VT-8-OC48 cards that output more than -7dBm of power (see 7707VT-8-OC48 specifications for output power of various laser types). Do not hook up the 7707VR-8-H high sensitivity receiver cards directly with a short fiber optic cable.
-
Page 5: Overview
DWDM DFB laser output, yyy – ITU channel number The 7707VT-8-OC48 occupies two card slots in the 3 RU frame, which will hold up to 7 modules or one card slot in the 1RU frame, which will hold up to three modules. One 7707VT-8-OC48 module can also be installed in the S7701 stand-alone enclosure. - Page 6 7700 MultiFrame Manual 7707VT-8-OC48 Eight Channel SDI + Ethernet SONET/SDH Fiber Transmitter Features: • Transports signal over OC-48/STM-16 data rates (2.488Gb/s) • Single card TDM multiplexer for eight asynchronous SD-SDI, SDTi and DVB-ASI signals • Built-in Ethernet transceiver with one 10/100 Base-T port •...
-
Page 7: Figure 1-1: 7707Vt-8-Oc48 Block Diagram
7700 MultiFrame Manual 7707VT-8-OC48 Eight Channel SDI + Ethernet SONET/SDH Fiber Transmitter SDI/ASI/SDTi OUTPUT MONITOR VIDEO MONITOR STAGE SELECTOR OUTPUT INPUT STAGE INPUT STAGE INPUT STAGE INPUT STAGE OPTICAL FIBER 8 SDI/ASI/SDTi SONET/ TRANSMITTER OUTPUT INPUTS SDH TDM INPUT STAGE... -
Page 8: Installation
7707VT-8-OC48 Eight Channel SDI + Ethernet SONET/SDH Fiber Transmitter INSTALLATION The 7707VT-8-OC48 comes with a companion rear plate that has nine BNC connectors and one SC/PC (shown), ST/PC or FC/PC optical connector. For information on mounting the rear plate and inserting the module into the frame see section 3 of the 7700FR chapter. -
Page 9: Care And Handling Of Optical Fiber
Triangular band: black Symbol: black 2.1.2. Assembly Assembly or repair of the laser sub-module is done only at Evertz facility and performed only by qualified Evertz technical personnel. 2.1.3. Labeling The Certification and Identification labels are combined into one label, as there is not enough room on the product to place the label it is reproduced here in the manuals. -
Page 10: Handling And Connecting Fibers
5 cm to avoid fiber-bending loss that will decrease the maximum attainable distance of the fiber cable. The Evertz fiber optic modules come with cable lockout devices to prevent the user from damaging the fiber by installing a module into a slot in the frame that does not have a suitable I/O module. -
Page 11: Specifications
7700 MultiFrame Manual 7707VT-8-OC48 Eight Channel SDI + Ethernet SONET/SDH Fiber Transmitter SPECIFICATIONS 3.1. SERIAL VIDEO INPUT Standards: SMPTE 259M-C, SMPTE 305M(SDTi), DVB-ASI. Number of Inputs: 8 independent SDI,SDTi or DVB-ASI 270Mb/s signals Connector: 8 BNC input per IEC 60169-8 Amendment 2... -
Page 12: Optical Input
7700 MultiFrame Manual 7707VT-8-OC48 Eight Channel SDI + Ethernet SONET/SDH Fiber Transmitter 3.4. OPTICAL INPUT Number of Inputs: Standards: OC-48/STM-16 Connector: Female SC/PC, ST/PC or FC/PC Return Loss: > 25dB Wavelength: 1270nm to 1610nm Maximum Input Power: Standard: -1dBm High Sensitivity (-H):... -
Page 13: Status Indicators And Displays
This Green LED indicates good module health. It will be ON when a valid input signal is present, and the laser and board power are good. On the 7707VT-8-OC48 there are nine small LEDs on the front of the board that indicate the optical link status and the presence of video signals. -
Page 14: Card Edge Display
7700 MultiFrame Manual 7707VT-8-OC48 Eight Channel SDI + Ethernet SONET/SDH Fiber Transmitter 4.2. CARD EDGE DISPLAY Additional signal and status monitoring is provided via the 4-digit dot-matrix display located at the card- edge. The card edge toggle switch is used to select whether you are displaying status from the card (monitoring mode) or setting control parameters for the card (control mode). -
Page 15: Stat Menu
7700 MultiFrame Manual 7707VT-8-OC48 Eight Channel SDI + Ethernet SONET/SDH Fiber Transmitter 4.2.1. STAT Menu When in monitoring mode, the toggle switch determines what data is being displayed on the alphanumeric display. Each time the toggle switch is pressed up/down, the display advances to the next/previous option. -
Page 16: Displaying The Last Interval Counter
7700 MultiFrame Manual 7707VT-8-OC48 Eight Channel SDI + Ethernet SONET/SDH Fiber Transmitter STAT/FIBR/CIC Current 24 hour interval elapsed TIME Current 15 minute interval elapsed time time Current 15 minute interval, errored Current 24 hour interval, errored seconds line seconds line... -
Page 17: Displaying The Errored Seconds Ratio
7700 MultiFrame Manual 7707VT-8-OC48 Eight Channel SDI + Ethernet SONET/SDH Fiber Transmitter 4.2.1.4. Displaying the Errored Seconds Ratio STAT Displays the Errored Seconds Ratio in Percentage for Section, FIBR Line, and Path layers from 0.0 to 100 % SECT LINE PATH 4.2.1.5. -
Page 18: Displaying The Video Standard
7700 MultiFrame Manual 7707VT-8-OC48 Eight Channel SDI + Ethernet SONET/SDH Fiber Transmitter 4.2.1.9. Displaying the Video Standard STAT Displays the video standard present at the input. VID1-VID8 N270: SMPTE 259M-C, 270 Mb/s 4:2:2 Component 525 line, 4:3 or SMPTE 305M... -
Page 19: Control Menu
SEFS (Severe Errored Seconds – Frame) shows the number of seconds during which H or more Frame errors were detected. H can be set by the user in the CTRL/SETH/SEFS menu. 4.2.2. Control Menu The Control menu enables the user to control and set different parameters on 7707VT-8-OC48 cards. Level 1 Level 2... -
Page 20: Setting The Optical Link Standard
Setting the Behavior of Laser When There is No Applied Video On the 7707VT-8-OC48, the LASR menu item allows the user to set the behavior of the laser transmitter when there is no video signal applied to the coaxial video inputs. -
Page 21: Setting The Severe Errored Second Threshold
7700 MultiFrame Manual 7707VT-8-OC48 Eight Channel SDI + Ethernet SONET/SDH Fiber Transmitter CTRL Clear Error Ratios. FIBR CESR 4.2.2.5. Setting the Severe Errored Second Threshold CTRL SESS = Severe Errored Seconds – Section SESL = Severe Errored Seconds – Line FIBR SESP = Severe Errored Seconds –... -
Page 22: Setting The Orientation Of The Text On The Card Edge Display
Setting the Orientation of the Text on the Card Edge Display On the 7707VT-8-OC48 card, the DISP display allows the user to set a horizontal or vertical orientation for the card edge display messages. After one second the display will show a message indicating the current orientation of the display. -
Page 23: Jumpers
7700 MultiFrame Manual 7707VT-8-OC48 Eight Channel SDI + Ethernet SONET/SDH Fiber Transmitter JUMPERS Several jumpers, located at the front of the module are used to preset various operating modes. Figure 5-1 shows the locations of the jumpers on the board. -
Page 24: Configuring The Module For Firmware Upgrades
7707VT-8-OC48 Eight Channel SDI + Ethernet SONET/SDH Fiber Transmitter 5.2. CONFIGURING THE MODULE FOR FIRMWARE UPGRADES The 7707VT-8-OC48 card can be configured for firmware upgrades using the UPGRADE jumpers or with the serial port ‘u’ command as described below. 5.2.1. Using the Upgrade Jumper UPGRADE: The UPGRADE jumper is used when firmware upgrades are being done to the module. -
Page 25: Vistalink ® Remote Monitoring/Control
(GUI), third party or custom manager software may be used to monitor and control Evertz VistaLINK enabled fiber optic products. ® 2. Managed devices (such as 7707VT-8-OC48 and 7707VR-8-OC48 cards), each with a unique address (OID), communicate with the NMS through an SNMP Agent. Evertz VistaLINK enabled 7700 series ®... -
Page 26: Vistalink Controlled Parameters
7700 MultiFrame Manual 7707VT-8-OC48 Eight Channel SDI + Ethernet SONET/SDH Fiber Transmitter 6.3. VISTALINK CONTROLLED PARAMETERS ® The following parameters can be remotely controlled through the VistaLINK interface. ® Parameter Description Enables recalculated EDH packets to be inserted into video EDH Insert 1 to 8 stream, with updated error flags.
