1.
OVERVIEW.......................................................................................................................................... 1
2.
INSTALLATION................................................................................................................................... 4
2.1. VIDEO SIGNAL CONNECTIONS............................................................................................... 4
2.2. AES AUDIO CONNECTIONS (MODEL 7707VAT) .................................................................... 5
2.3. AES AUDIO CONNECTIONS (MODEL 7707VAT-U) ................................................................ 5
2.4. ANALOG AUDIO CONNECTIONS (MODEL 7707VAT-A4) ...................................................... 5
2.5. OPTICAL SIGNAL CONNECTIONS .......................................................................................... 5
2.6. CARE AND HANDLING OF OPTICAL FIBER........................................................................... 6
2.6.1. Safety .............................................................................................................................. 6
2.6.2. Assembly......................................................................................................................... 6
2.6.3. Labeling........................................................................................................................... 6
2.6.4. Handling and Connecting Fibers ..................................................................................... 7
3.
SPECIFICATIONS............................................................................................................................... 8
3.1. SERIAL VIDEO INPUT ............................................................................................................... 8
3.2. SERIAL VIDEO OUTPUT ........................................................................................................... 8
3.3. AES AUDIO INPUTS (MODEL 7707VAT AND 7707VAT-U)..................................................... 8
3.4. ANALOG AUDIO INPUTS (MODEL 7707VAT-A4 ONLY)......................................................... 9
3.5. OPTICAL OUTPUT..................................................................................................................... 9
3.6. SYSTEM PERFORMANCE ........................................................................................................ 9
3.7. ELECTRICAL ............................................................................................................................. 9
3.8. COMPLIANCE ............................................................................................................................ 9
3.9. PHYSICAL ................................................................................................................................ 10
4.
STATUS INDICATORS AND DISPLAYS ......................................................................................... 11
4.1. STATUS INDICATOR LEDS .................................................................................................... 11
4.2. DOT-MATRIX DISPLAY ........................................................................................................... 11
4.2.1. Using the Dot Matrix Display - Model 7707VAT and 7707VAT-U ................................. 11
4.2.2. Using the Dot Matrix Display - Model 7707VAT-A4...................................................... 12
7707VAT Digital Video and AES Audio Fiber Transmitter
TABLE OF CONTENTS
Revision 2.3
7700 MultiFrame Manual
Advertisement
Table of Contents
Related Manuals for evertz 7707VAT Series
Summary of Contents for evertz 7707VAT Series
-
Page 1: Table Of Contents
7700 MultiFrame Manual 7707VAT Digital Video and AES Audio Fiber Transmitter TABLE OF CONTENTS OVERVIEW............................1 INSTALLATION........................... 4 2.1. VIDEO SIGNAL CONNECTIONS....................4 2.2. AES AUDIO CONNECTIONS (MODEL 7707VAT) ..............5 2.3. AES AUDIO CONNECTIONS (MODEL 7707VAT-U) ..............5 2.4. ANALOG AUDIO CONNECTIONS (MODEL 7707VAT-A4) ............5 2.5. - Page 2 7700 MultiFrame Manual 7707VAT Digital Video and AES Audio Fiber Transmitter 4.2.3. Setting the Headphone Jack Channel (7707VAT-A4 only) ........... 12 4.2.4. Displaying the Equalization Strength................13 4.2.5. Displaying the Video Standard ..................13 4.2.6. Displaying the Audio Sample Rate (7707VAT and 7707VAT-U only) ......13 4.2.7.
- Page 3 Figure 1-1: 7707VAT and 7707VAT-U Block Diagram ..................2 Figure 1-2: 7707VAT-A4 Block Diagram .......................3 Figure 2-1: 7707VAT Series Rear Panels......................4 Figure 2-2: Reproduction of Laser Certification and Identification Label ..............7 Figure 7-1: Location of Jumpers and Card Edge Controls – 7707VAT and 7707VAT-U ........19 Figure 7-2: Location of Jumpers and Card Edge Controls –...
- Page 4 7700 MultiFrame Manual 7707VAT Digital Video and AES Audio Fiber Transmitter This page left intentionally blank Revision 2.3...
- Page 5 Feb 09 Information contained in this manual is believed to be accurate and reliable. However, Evertz assumes no responsibility for the use thereof nor for the rights of third parties, which may be affected in any way by the use thereof. Any representations in this document concerning performance of Evertz products are for informational use only and are not warranties of future performance, either expressed or implied.
- Page 6 7700 MultiFrame Manual 7707VAT Digital Video and AES Audio Fiber Transmitter WARNING Never look directly into an optical fiber. Non-reversible damage to the eye can occur in a matter of milliseconds. Do not hook up the 7707VAT DWDM cards and 7707VAR cards directly with a short fiber optic cable.
-
Page 7: Overview
DWDM DFB laser output, yyy – ITU channel number The 7707VAT series modules occupy one card slot and can be housed in either a 1RU frame, which will hold up to three modules, or a 3 RU frame, which will hold up to 15 modules. -
Page 8: Figure 1-1: 7707Vat And 7707Vat-U Block Diagram
7700 MultiFrame Manual 7707VAT Digital Video and AES Audio Fiber Transmitter Features: • Single card multiplexer for SDI Video and 2 AES Audio (7707VAT and 7707VAT-U) or 4 analog audio (7707VAT-A4) • Supports 270Mb/s on 525 or 625 line 4:2:2 component SDI or SDTi (SMPTE 305M) video signals •... -
Page 9: Figure 1-2: 7707Vat-A4 Block Diagram
7700 MultiFrame Manual 7707VAT Digital Video and AES Audio Fiber Transmitter VistaLINK ® Interface CONTROL/ LOCAL LOCAL INDICATION GLOBAL CONTROL INDICATION CLOCK SDI VIDEO OUTPUT CABLE SDI VIDEO RECLOCKER DRIVER INPUT OPTICAL FIBER AUDIO 1 INTERFACE TRANSMITTER OUTPUT ANALOG AUDIO 2 AUDIO AUDIO 3 INPUTS... -
Page 10: Installation
SC/PC, SC/PC with cover (shown), ST/PC or FC/PC optical connector. information on mounting the rear plate and inserting the module into the frame see the 7700FR chapter section 3. Figure 2-1: 7707VAT Series Rear Panels 2.1. VIDEO SIGNAL CONNECTIONS... -
Page 11: Aes Audio Connections (Model 7707Vat)
7700 MultiFrame Manual 7707VAT Digital Video and AES Audio Fiber Transmitter 2.2. AES AUDIO CONNECTIONS (MODEL 7707VAT) AES AUDIO IN: Balanced or unbalanced AES audio inputs for channel 1&2 (AES 1) and 3&4 (AES 2) of an audio group. Each input (+, -, GND) is on three of six pins on six pin terminal header. -
Page 12: Care And Handling Of Optical Fiber
Triangular band: black Symbol: black 2.6.2. Assembly Assembly or repair of the laser sub-module is done only at Evertz facility and performed only by qualified Evertz technical personnel. 2.6.3. Labeling Certification and Identification labels are combined into one label. As there is not enough room on the product to place the label it is reproduced here in the manuals. -
Page 13: Handling And Connecting Fibers
5 cm to avoid fiber-bending loss that will decrease the maximum attainable distance of the fiber cable. The Evertz fiber optic modules come with cable lockout devices, to prevent the user from damaging the fiber by installing a module into a slot in the frame that does not have a suitable I/O module. -
Page 14: Specifications
7700 MultiFrame Manual 7707VAT Digital Video and AES Audio Fiber Transmitter SPECIFICATIONS 3.1. SERIAL VIDEO INPUT Standards: SMPTE 259M-C, 525 or 625 line component, SMPTE 305M SDTi. Connector: 1 BNC input per IEC 61169-8 Annex A Equalization: Automatic to 300m @ 270 Mb/s with Belden 1694 or equivalent cable Return Loss: >... -
Page 15: Analog Audio Inputs (Model 7707Vat-A4 Only)
7700 MultiFrame Manual 7707VAT Digital Video and AES Audio Fiber Transmitter 3.4. ANALOG AUDIO INPUTS (MODEL 7707VAT-A4 ONLY) Number of Inputs: Type: Balanced analog audio Connector: 12 pin removal terminal block Input impedance: High Impedance (>20 KOhm) Freq. Response: +/-0.1 dB, 20Hz to 20 kHz THD 20Hz–20Khz: <... -
Page 16: Physical
7700 MultiFrame Manual 7707VAT Digital Video and AES Audio Fiber Transmitter EMI/RFI: Complies with FCC regulations for class A devices Complies with EU EMC directive 3.9. PHYSICAL 7700 or 7701 frame mounting: Number of slots: 1 7707VAT-10 Revision 2.3... -
Page 17: Status Indicators And Displays
STATUS INDICATORS AND DISPLAYS The 7707VAT series modules have 5 LED Status indicators and a 4 digit alphanumeric display on the front card edge to show operational status of the card at a glance. The card edge pushbutton is used to select various displays on the alphanumeric display. -
Page 18: Using The Dot Matrix Display - Model 7707Vat-A4
7700 MultiFrame Manual 7707VAT Digital Video and AES Audio Fiber Transmitter The following display messages on the 7707VAT indicate what is being displayed. The details of each of the displays are described in the sections 4.2.4 to 4.2.8. Input equalization strength. Video standard in use. -
Page 19: Displaying The Equalization Strength
Indicates that no valid input signal is present. LOS: 4.2.5. Displaying the Video Standard The 7707VAT series modules detect the Video standard of the input signal and display this on the four- digit card edge display. The following list describes possible displays and their meaning. VSTD... -
Page 20: Setting The Orientation Of The Led Display (7707Vat And 7707Vat-U Only)
7700 MultiFrame Manual 7707VAT Digital Video and AES Audio Fiber Transmitter 4.2.7. Setting the Orientation of the LED Display (7707VAT and 7707VAT-U only) The DISP display allows you to set a horizontal or vertical orientation for the card edge display messages. After one second the display will show a message indicating the current orientation of the display. -
Page 21: Card Edge Menu System (7707Vat-A4 Only)
7700 MultiFrame Manual 7707VAT Digital Video and AES Audio Fiber Transmitter CARD EDGE MENU SYSTEM (7707VAT-A4 ONLY) 5.1. NAVIGATING THE MENU SYSTEM When you are in control mode, the toggle switch and pushbutton are used to navigate through a menu system to set various parameters for the module. -
Page 22: Configuring Audio Presence Detection
7700 MultiFrame Manual 7707VAT Digital Video and AES Audio Fiber Transmitter 5.3.1. Configuring Audio Presence Detection The ADET sub menu contains 3 menu items (for each audio channel) relating to the Audio detection. The menu items for each channel are identical so for the sake of simplicity, only the menu items for A1 channel are shown. -
Page 23: Restoring The Factory Settings
7700 MultiFrame Manual 7707VAT Digital Video and AES Audio Fiber Transmitter 5.6. RESTORING THE FACTORY SETTINGS FRST The FRST control allows the user to restore the factory values (those underlined) for the module’s parameters described in sections 5.3 and 5.5. Page-17 Revision 2.3... -
Page 24: Card Edge Controls
7707VAT Digital Video and AES Audio Fiber Transmitter CARD EDGE CONTROLS The 7707VAT series modules are equipped with a three position, return to center, toggle switch which is used to select the various card-edge displays and menu items and is also used in conjunction with a momentary pushbutton to select some sub-items of the menu system. -
Page 25: Jumpers
7700 MultiFrame Manual 7707VAT Digital Video and AES Audio Fiber Transmitter JUMPERS TOGGLE SWITCH LOCAL FAULT VIDEO PRESENT MODULE OK AES 1 PRESENT AES 2 PRESENT DISPLAY PUSH BUTTON SELECT AES1 AES2 Figure 7-1: Location of Jumpers and Card Edge Controls – 7707VAT and 7707VAT-U TOGGLE SWITCH LOCAL FAULT AUDIO 1 PRESENT... -
Page 26: Selecting Whether Local Faults Will Be Monitored By The Global Frame Status
7700 MultiFrame Manual 7707VAT Digital Video and AES Audio Fiber Transmitter 7.1. SELECTING WHETHER LOCAL FAULTS WILL BE MONITORED BY THE GLOBAL FRAME STATUS The FRAME STATUS jumper J4 determines whether local faults (as shown by the Local Fault indicator) will be connected to the 7700FR frame's global status bus. -
Page 27: Selecting The Aes Input Configuration - Balanced Or Unbalanced (7707Vat And 7707Vat-U)
7700 MultiFrame Manual 7707VAT Digital Video and AES Audio Fiber Transmitter 7.4. SELECTING THE AES INPUT CONFIGURATION - BALANCED OR UNBALANCED (7707VAT and 7707VAT-U) The AES TERM jumpers J26 and J27 located near the rear of the module are used to configure whether AES inputs are balanced (110 ohm) or unbalanced (75 ohm). -
Page 28: Vistalink Remote Monitoring/Control
1. An SNMP manager, also known as a Network Management System (NMS), is a computer running special software that communicates with the devices in the network. Evertz VL-Fiber demo Manager graphical user interface (GUI), third party or custom manager software may be used to monitor and control Evertz VistaLINK enabled fiber optic products. -
Page 29: Vista Link ® Monitored Parameters
7700 MultiFrame Manual 7707VAT Digital Video and AES Audio Fiber Transmitter 8.2. LINK MONITORED PARAMETERS ISTA ® The following parameters can be remotely monitored through the VistaLINK interface. ® Parameter Description A range of values describing equalization strength at the SDI Cable Length Video input. -
Page 30: Vista Link ® Controlled Parameters
7700 MultiFrame Manual 7707VAT Digital Video and AES Audio Fiber Transmitter 8.3. LINK CONTROLLED PARAMETERS ISTA ® On the 7707VAT and 7707VAT-U there are currently no parameters that can be remotely controlled through the VistaLINK interface. ® On the 7707VAT-A4 the following parameters can be remotely controlled through the VistaLINK interface. -
Page 31: Vista Link ® Fault Status Parameters - Traps
7700 MultiFrame Manual 7707VAT Digital Video and AES Audio Fiber Transmitter 8.4. LINK FAULT STATUS PARAMETERS – TRAPS ISTA ® The following parameters can be remotely monitored through the VistaLINK interface as trap statuses in ® the Configuration View and traps in the Alarm View. Parameter Description Indicates whether AES 1 signal is present or not. -
Page 32: Table 8-5: 7707Vat-A4 Vistalink
7700 MultiFrame Manual 7707VAT Digital Video and AES Audio Fiber Transmitter Parameter Description Indicates if there’s valid video signal present at the input. Loss of valid video signal will trigger the “SDI Video Not Present” SDI Video Not Present trap in the VistaLINK Alarm View. Indicates there are EDH errors present in input video signal.
