- Page 1 866.332.2403 (TOLL FREE) (707) 640.29.05 (Option 4) Direct Line for the Design Department; 7am – 7pm Pacific Time, Monday-Saturday ASSEMBLY INSTRUCTIONS FOR THE LUNA WOOD BENCH...
- Page 2 Insert the carriage bolts into the holes and lightly tap with a hammer until the square neck fit in the wood piece and the bolt head must flush with the wood piece. Finally, place the washer and the nut and carefully tighten it using a ratchet with the necessary socket or a wrench. P| 1 LUNA WOOD BENCH www.ForeverRedwood.com...
- Page 3 Place the washers in their lag bolts. After that, insert the lag bolts into the holes and carefully tighten it using a ratchet with the necessary socket. Use the washers only for the Wood Pieces. To install the deck screws. Insert the deck screws into the holes and carefully tighten it using a drill. P| 2 LUNA WOOD BENCH www.ForeverRedwood.com...
- Page 4 Note: Part numbers in the Content of Boxes Table are for reference only. These do not match to the numbers marked on the parts sent. HARDWARE LIST Description Drawing 5/16´´ x 3 ½´´ bolts 5/16´´ x 4 ½´´ bolts Note: Dimensions of your hardware will vary depending on size. P| 3 LUNA WOOD BENCH www.ForeverRedwood.com...
- Page 5 DESCRIPTION Legs Seat Backrest Supports Diagonal support Note: Part numbers in the Drawing are for reference only. These do not match to the numbers marked on the parts sent. P| 4 LUNA WOOD BENCH www.ForeverRedwood.com...
- Page 6 Step 2: Attach the backrest (3) to the legs with 5/16´´ x 3 ½´´ bolts (BL1) with washer and nuts to attach. Each part has a series of numbers that indicate where to attach the part with the corresponding number. P| 5 LUNA WOOD BENCH www.ForeverRedwood.com...
- Page 7 Step 4: Finally, use 5/16´´ x 4 ½´´ bolts (BL2) with washer and nuts to attach the diagonal supports (5) to the seat and to the legs. Each part has a series of numbers that indicate where to attach the part with the corresponding number. P| 6 LUNA WOOD BENCH www.ForeverRedwood.com...
- Page 8 This completes the Bench assembly. Hope you enjoy your set for many decades. If you ever have a problem or a question, don't hesitate to call us (866 332 2403) or email us. We are here to support you. P| 7 LUNA WOOD BENCH www.ForeverRedwood.com...
