- Page 1 HDG3000B series Arbitrary waveform signal generator Quick Guide 2022.05...
- Page 2 Hantek certified HDG3000B series arbitrary waveform signal generators to meet China's national industry standards and has passed the CE certification. Contact us If you have any questions when using the products of Qingdao Hantek Electronics Co., LTD., you can obtain service and support through the following ways: Email: service@hantek.com, support@hantek.com...
-
Page 3: Safety Requirements
Do not touch exposed connectors and components after power is switched on. ⚫ Do not operate if the product is suspected to be faulty. If you suspect that the product has been damaged, please ask qualified maintenance personnel to check it. Copyright © Qingdao Hantek Electronics Co., LTD HDG3000B Quick Guide... -
Page 4: Safety Terms And Symbols
Indicates that you may cause damage to this product or other properties if you do Safety terms on the product: Warning: Indicates a potential hazard to you if you do not perform this operation. Safety symbols on the product: HDG3000B Quick Guide Copyright © Qingdao Hantek Electronics Co., LTD... -
Page 5: Measurement Category
≤+104℉(≤+40°C): relative humidity≤90% 106℉~122℉ (+41° C ~50° C): relative humidity≤60% Warning: To avoid the danger of short circuit or electric shock, do not operate the instrument in a humid environment. Altitude Copyright © Qingdao Hantek Electronics Co., LTD HDG3000B Quick Guide... -
Page 6: Maintenance And Cleaning
Do not make the LCD exposed to direct sunlight for a long time when placing the oscilloscope. Cleaning: Regularly check the oscilloscope and probe according to the requirements of the operating conditions, please follow the following steps to clean the outer surface of the HDG3000B Quick Guide Copyright © Qingdao Hantek Electronics Co., LTD... -
Page 7: Environmental Precautions
Copyright © Qingdao Hantek Electronics Co., LTD HDG3000B Quick Guide... -
Page 8: Document Overview
Document overview Document overview This document is used to guide the user to quickly understand the front and back panels, user interfaces, and basic operation methods of the HDG3000B series signal generators. Tip: The latest version of this manual can be downloaded at (http://www.hantek.com). - Page 9 Model Number of channels Maximum frequency CH1/CH2 sampling rate HDG3012B 15MHz 300MS/s HDG3022B 25MHz 300MS/s HDG3042B 40MHz 300MS/s HDG3062B 60MHz 300MS/s HDG3082B 80MHz 300MS/s HDG3102B 100MHz 300MS/s Table 2.2 Model Copyright © Qingdao Hantek Electronics Co., LTD HDG3000B Quick Guide...
-
Page 10: General Checking
Check the machine If you find the instrument is damaged, not working properly, or unable to pass the performance test, please contact the dealer responsible for this business. HDG3000B Quick Guide Copyright © Qingdao Hantek Electronics Co., LTD... -
Page 11: Product Introduction
Product introduction Product introduction HDG3000B series which have function generator, arbitrary waveform generator, pulse generator, harmonic generator, analog/digital modulator, counter and other functions all in one, is an economic, high performance, multifunctional dual channel function/arbitrary wave generator. Front panel introduction Figure 4.1 Front panel... -
Page 12: Rear Panel Introduction
4 10 MHz input/output terminal (10 MHz In/ 8 AC power jack Out) User interface introduction Figure 4.3 User interface 1 Selected channel 4 Channel configuration 2 Channel parameters 5 Menu 3 Waveform HDG3000B Quick Guide Copyright © Qingdao Hantek Electronics Co., LTD... -
Page 13: Preparation Before Use
To avoid electronic shock, make sure the instrument is properly grounded. Adjust the handle To adjust the handle, hold the handle on both sides of the instrument and pull outward, then rotate the handle. Copyright © Qingdao Hantek Electronics Co., LTD HDG3000B Quick Guide... -
Page 14: Set The System Language
Press [Utility] > Language to select the desired Language. When you select "Chinese" or "English", the menu, help information, prompt message and interface will be displayed in Chinese or English respectively. HDG3000B Quick Guide Copyright © Qingdao Hantek Electronics Co., LTD... -
Page 15: Use The Built-In Help System
If there is an index for another topic in the content view, the user can turn the knob select a different index, press the knob to access the corresponding topic. Press [?] again to exit. Copyright © Qingdao Hantek Electronics Co., LTD HDG3000B Quick Guide... -
Page 16: Parameter Setting Method
When inputting parameters, the arrow keys are used to move the cursor to select the currently edited bit. When editing the file name, the arrow keys are used to move the cursor position. HDG3000B Quick Guide Copyright © Qingdao Hantek Electronics Co., LTD... - Page 17 ⚫ When performing Store and Invoke function, the knob can be used to select where files are saved or select files that need to be read. Copyright © Qingdao Hantek Electronics Co., LTD HDG3000B Quick Guide...
-
Page 18: Remote Control
= 2175637 & lc = chi&cc = CN&nid = - 11143.0.00 & id = 2175637 Of course, you can download the package from the official website of Hantek. Double click on the application to start the installation. Follow the installation prompts step by step, and the installation process may take a few minutes. - Page 19 "Connected" prompt in the bottom left status bar. Computer side user interface Double click the software program icon on your desktop and you can see the user interface as follows: Copyright © Qingdao Hantek Electronics Co., LTD HDG3000B Quick Guide...
- Page 20 Remote control 1 Menu bar 4 Connection status 2 Toolbar 5 Control bar 3 Waveform HDG3000B Quick Guide Copyright © Qingdao Hantek Electronics Co., LTD...
- Page 21 View information and installation of the optional items For more information about this product, please refer to the relevant manual (you can http://www.hantek.com download it on Hantek's official website ( ⚫ HDG3000B User Manual: Provide the function introduction and operation method, remote control method, possible faults and handling methods during use, performance indicators and order information.
- Page 22 Addr: #35 Building, No. 780 Baoyuan Road, High-tech Zone, Qingdao, Shandong, China 266114 Switchboard: 400-036-7077 Email: service@hantek.com Tel: (0086)532-55678770 & 55678772 & 55678773 Zip code: 266114 Website: www.hantek.com Qingdao Hantek Electronics Co., LTD...
