QuickSTART
This document provides a brief introduction to the Avant-E Evaluation Board.
Mini USB
FTDI Chip
FMC1
Connector
Avant FPGA
DIP Switch
I/O
Extended
Area

Check Kit Contents

1
The Avant-E Evaluation Board Kit contains the following items:
Avant-E Evaluation Board
12 V AC/DC Adapter and International Plug Adapters
USB Cable for Programming vis PC (USB-A to Mini-B)
Quick Start Guide
Lattice Radiant software download information
Using the Avant-E Evaluation Board
2
The Avant-E Evaluation Board as shipped supports Master-SPI based configuration.
The external SPI Flash Configuration Memory is pre-loaded with a LED blinking
demonstration program.
SPI
8-Segment
Flash
Push Buttons
FMC2 Connector
Avant-E Evaluation Board
PMOD
LEDs
Connectors
Power
LEDs
LPDDR4
Memory
Main Power
Switch
12 V DC
Power
Jack
