System - RGBlink RMS 2380U User Manual

Position can be set from top or bottom.
UMD Size
Set UMD size to be large or small.
UMD Transparency
Choose from：OFF,Low,High
Display Type: Source ID,UMD
UMD Standard: OFF,TSL V3.1,TSL V4.0,TSL V5.0
UMD ID: 0~127 (Default: 0)
Baud Rate: 38400,8,e,1 ; 115200,8,e,1
Source Name: Set name of UMD source

2.1.12 System

System: Settings of Key Lock, Language, Menu Transparency and more.
Key Lock: OFF/Full Lock
Full Lock: All function keys are locked and cannot be used. Users need to enter the menu to select OFF for reuse.
Language: English/Simplified Chinese
Menu Timer: 5s, 10s, 30s, 60s (OSD disappears after the corresponding time.)
Menu Position:
Choose from: Top Left, Top Right, Middle, Left, Right
4K HDR Monitor
Status Display
User Preset
Color Management
Scopes
Auxiliary Function
Display
Marker
Multi Screen
Audio
UMD
System
Key Lock
Language
Menu Timer
Menu Position
Menu Transparency
Source Display
Key LED
Factory Reset
User Manual
24
