Screen Mode, Key Lock, Audio Source, Volume.
Color Information
Show Color Preset Mode, Color Temp, Color Gamut, Gamma (EOTF), HDR Auto Setting, Backlight, Input Range,
Contrast, Brightness, Chroma, Aperture.
Scopes & Auxiliary Information
Show Waveform, Histogram, Vector Scope , False Color, Zebra, Test Signal, SDI Eye Diagram, Blue Only/Mono ,
Screen Saver.
SDI Info
Show SDI Input, Payload ID, Video Standard, Sampling, Picture Rate, Scanning Mode, Bit Depth, Link Assignment,
Colorimetry, Transfer Type.
Hardware Information
Show Hardware Version, Software Version, FPGA Version, Serial Number, Model Name, IP address, Subnet Mask,
Gateway and Port Number.

2.1.2 User Preset

User Preset: Preset function keys and GPI, and store, load and restore the preset values.
F Button Preset
Five modes with different functions, which are corresponding to the F1-F5 shortcut keys on the front panel. Users can
also modify the five preset modes.
4K HDR Monitor
Status Display
User Preset
Color Management
Scopes
Auxiliary Function
Display
Marker
Multi Screen
Audio
UMD
System
F Button Preset
F1 Button
F2 Button
F3 Button
F4 Button
F5 Button
GPI Preset
GPI1
GPI2
GPI3
GPI4
GPI5
All Data Load
All Data Save
