Auxiliary Function - RGBlink RMS 2380U User Manual

Waveform: OFF/Brightness Waveform/Component Waveform, RGB Waveform, RGB Superimposed Waveform
Waveform Color: white, green, yellow
WFM Single Line: ON/OFF
WFM Line Count:
Adjust the waveform with specific lines when displaying single-line waveform. (Only available under single-line
waveform, and the range of line number depends on the current signal format.)
Vertical Height:
Display height of single-line waveform, choose from 128-lines, 256-lines and 512-line.
Vector Scope: ON/OFF
The color and saturation of the image are represented by waveform in a vector oscilloscope. The higher the saturation,
the more stretched the waveform.
Vector Color: white or green
Histogram:
Choose from：OFF,Brightness Histogram, RGB Histogram, RGB Superposition Histogram.
BG Transparency: Dark, low and high
Scopes Position: low, medium and high

2.1.6 Auxiliary Function

To monitor, analyze and adjust video signals.
Auxiliary Function:
4K HDR Monitor
Color Management
Scopes
Auxiliary Function
Display
Marker
Multi Screen
Audio
UMD
System
WFM Single Line
WFM Line Count
Vertical Height
Vector Scope
Vector Color
Histogram
BG Transparency
Scopes Position
User Manual
18
