- Page 2 Warranty BLACK NOISE warrants the contents of this kit to be free of defects in materials or workmanship and to be conform with the specifications at the time of shipment for a period of two years from the date of purchase.
- Page 3 DR II DR II Build instructions Build instructions Place the jack connectors Place the faceplate Place the jack connectors on the PCB. Place the faceplate. To make sure of the Make sure to place the connector orientation with the PCB, look at the modified during the previous step at power connector.
- Page 4 DR II DR II Build instructions Build instructions Clean your module Solder the jack connectors turn the PCB over and solder the jack Clean the PCB of flux and solder residue connectors. Make sure the connectors using Isopropyl alcohol. are flush against the PCB before soldering them.
