- Page 1 Network Video Recorder Quick Installation Guide DS-4100-RM Series 2.0.0.4 Information in this document is subject to change without notice. © Copyright 2022, DIGIEVER Corporation. All rights reserved.
-
Page 2: Pre-Installation Notice
Quick Installation Guide Thank you for choosing DIGIEVER NVR Network Video Recorder. The following quick guide will lead you to complete the installation and configuration of the NVR. Please read the following description carefully. Pre-installation Notice Please make sure the following items are prepared for installing DIGIEVER NVR DS-4100-RM Series. - Page 3 For channels over 16: IDDR3 8G or above Graphics Adapter AGP or PCI-Express, minimum 1024 × 768, 16bit colors, 1G memory or above Note: It is highly recommended to use a graphics adaptor which provides higher than resolutions 1024 x 768 in order to experience the full benefits of the software.
-
Page 4: Package Contents
Package Contents NVR (Network Video Recorder) Power Cord Rack Mount Ears RJ45 Network Cable Screws for 2.5” HDD Screws for 3.5” HDD Product CD... -
Page 5: Hardware Description
Hardware Description Front View Rear View Power button and LED indicator Inspection button and LED indicator System status LED indicator Network LED indicator HDD1 HDD2 HDD3 HDD4 Inspection LED indicator for rear panel 10. Reset button 11. HDMI 1.4a output 12. -
Page 6: Hard Disk Installation
Hard Disk Installation Please follow the steps as illustrated below to install the hard disk: ① Press the button on the lower portion of the hard disk tray to release the latch. ② Using the latch, gently pull the disk tray out of the disk bay. ③... - Page 7 (2) 2.5-inch hard disks and SSD hard disks: Place the hard disk into the area of the disk tray outlined in red (see picture below). Make sure that the mounting holes on the bottom of the hard disk and disk tray are lined up. Secure the drive with four screws. ④...
- Page 8 Connection to DIGIEVERNVR Please insert the product CD-ROM on a PC to install EZ Search and S-NVR Decoder. Finally, you can start Quick Configuration on a web page. Install EZ Search for finding NVR in the network Install S-NVR Decoder ...
- Page 9 ③ Connect to NVR 1. Connect to DIGIEVER NVR After setting the EZ Search and S-NVR Decoder, user can connect to the monitoring page by the following two options: (1) EZ Search Once you click “Connect” or double click the selected NVR list,...
- Page 10 Obtain an IP address automatically (NVR Default) Obtain an available dynamic IP address assigned by a DHCP server. If this option is selected, DIGIEVER NVR will automatically obtain an available dynamic IP address from the DHCP server once it connects to the network.
-
Page 11: Quick Configuration
Once the five steps of Quick Configuration are complete, you can click “Start Liveview” to start monitoring. For further details of Quick Configuration, please refer to the user manual. When the live view is displayed, you have successfully installed the DIGIEVER NVR. Congratulations!
