Summary of Contents for Kabuto Japan IBUKI
- Page 1 Instruction Manual Manuel d’utilisation / Gebrauchsanweisung Manuale d’istruzioni Indice / Manual de instrucciones Handleiding / Bruksanvisning Instrukcja obsługi / Instruktionsmanual Εγχειρίδιο χρήσης / Manual de instruções Käyttöopas / 日本語...
-
Page 2: Table Of Contents
Instruction Manual / Table of Contents IBUKI Instruction Manual / Table of Contents ••••• P-1 Helmet Description ••••• P-2 I. For Safe and Comfortable Use Notes Before Use ••••• P-3 II. How to Use Functional Components 1 Fastening Chinstraps ••••• P-5 2 Open/Close Chin Cover •••••... -
Page 3: Helmet Description
Original Insert Lens (eccentric pins) Integrated Wake Stabilizer PATENTED The Wake Stabilizer , Kabuto’s unique system, PATENTED is developed by analyzing the results of wind tunnel experiments at several angles. This unique system controls the airflow around the helmet and reduces loads while riding. -
Page 4: Notes Before Use
NOTES BEFORE USE Thank you very much for purchasing a Kabuto helmet. This Instruction Manual describes proper handling, various functions and remove/replace each part of this helmet. Please read this Instruction Manual thoroughly prior to use. After reading this, keep the Manual for future reference. - Page 5 Do not paint or apply solvent Any paint, glue, adhesive stickers, etc. (or the use of detergents and solvents other than those prescribed) may not only reduce the original protective performance of the helmet considerably, but may also cause damage to the helmet that cannot be detected by the naked eye.
-
Page 6: How To Use Functional Components
II. How to Use Functional Components Fastening Chinstraps Buckle makes it easy to take on and off your helmet. Fastening WARNING! Be sure to fasten the buckle securely before riding. Insert into the buckle If the buckle is not fastened or not Unfastening fastened securely, your helmet Unfastening... -
Page 7: Open/Close Chin Cover
Open/Close Chin cover This helmet adopts the system to open and close the chin cover. [To Open the Chin Cover] Pushing the lock lever on the Chin Cover as shown in the figure, open the Chin Cover up as far as it goes. *Chin Cover only stops at fully opened or closing position. - Page 8 II. How to Use Functional Components CAUTION! •Please open the Chin Cover in a careful manner. Otherwise the attachment part and ratchet systems will break. •Lock system adopted for firm closing. Please be careful not to shut the cover on your fingers or anything when you close the Chin Cover.
-
Page 9: Open/Close Inner Sunshade
In case the open/close lever broke, for repair please contact by holding it directly with your hand, authorized Kabuto dealers for detailed information. (please otherwise the Inner Sunshade may refer page 28-30) Please understand there may be a case your be damaged. -
Page 10: Open/Close Ventilations
II. How to Use Functional Components Open/Close Ventilations Rear ventilation Head ventilation Ventilation System: The ventilation system effectively takes outer air in and pushes the inner humid air out by the air pressure from the front while riding. The ventilations are equipped with a shutter which prevents cold air and water drops from coming into your helmet. - Page 11 In case the ventilation is broken, either purchase the replacement and install it yourself, or have the authorized Kabuto dealer repair it. (please refer to page 28- 30) Be noted that the authorized Kabuto dealer decline the repair work in case they judge safety, function of the helmet cannot be retained by the repair work.
-
Page 12: Pinlock Original Insert Lens
II. How to Use Functional Components Pinlock Original Insert Lens ® Pinlock ® Original Insert Lens has international patent protection and is a registered brand name of Pinlock systems B.V. Further patents have been applied for. [Pinlock Original Insert Lens] ®... - Page 13 Section view Make sure the Pinlock ® Original Insert Lens to of shield: be fit inside the chase. Protective film Correct Wrong Silicon seal Shield *with no space Eccentric pins Silicon seal Shield Pinlock® Original Insert Lens Fig.5 3. Make sure if the overall silicon seal of the Pinlock Original Insert Lens is ®...
- Page 14 II. How to Use Functional Components CAUTION! •Flex the shield properly when fitting the Pinlock Original Insert Lens. Otherwise, ® eccentric pins may be damaged. •Clean the inside of the shield before applying the Pinlock Original Insert Lens. ® Pay attention not to touch the anti-fogging part of the silicon seal on the Pinlock ®...
-
Page 15: Maintenance -Exterior
III. Maintenance –Exterior– Remove/Replace Shield [To Remove] *This explanation indicates the left side when the helmet is worn. Pull down the lever to remove shield. Fig.1 Fig.2 1. Open the shield as far as it goes. 2. As pulling the lever on the ratchet downwards, pull out the shield downwards, so one side of the shield will be removed. - Page 16 III. Maintenance –Exterior– [To Install] * This explanation indicates the left side when the helmet is worn. 1. Inserting the upper projection into the upper space on the shield ratchet 2. push the part on the shield Fig.1 1. Inserting the upper projection into the upper space on the shield ratchet, push the part on the shield indicated on above figure, so on side of the shield will be installed.
-
Page 17: Remove/Replace Inner Sunshade
Remove/Replace Inner Sunshade [To remove Inner Sunshade] Stopper Close completely Inner Sunshade Fig.1 Fig.2 1. Close the Inner Sunshade 2. Pulling up the stopper at the completely. attachment of the Inner Sunshade, pull out the Inner Sunshade in the direction of arrow. Stopper Fig.3 3. - Page 18 III. Maintenance –Exterior– [To Insert the Inner Sunshade] 1. Confirm the lever is at the top and Inner Open/Close Lever Sunshade is closed completely. Lever is at the top completely 2. Push in the Inner Sunshade end to the attachment hole Attachment hole on the helmet until it knocks.
-
Page 19: Remove/Replace Shield Ratchets
Remove/Replace Shield Ratchets The “Shield Ratchet” is a part to control the function of open/close and detach/attach the shield. When the shield is completely removed in the procedure mentioned in 6 Remove/Replace Shield, the Shield Ratchet appears. [To Remove the Shield Ratchet] Shield Ratchet M4 hex wrench *This explanation indicates the left side... - Page 20 III. Maintenance –Exterior– [To Insert the Shield Ratchet] *This explanation indicates the left side when the helmet is worn. 1. Check the side of the Shield Ratchet (Fig.1) *Collar has marks. On the right side with mark ”R”, and left side with “L”. 2.
-
Page 21: Remove/Replace Chin Cover
Remove/Replace Chin Cover To maintain the Chin Cover, you can remove the Chin Cover. [To Remove Chin Cover] 1. Remove the shield. (Please check 6 Remove/Replace Shield) 2. Remove Shield Ratchets and Collars. (Please check 8 Remove/Replace Shield Ratchets) 3. Place the helmet on the stable place, then unlocking the Chin Cover by pushing the lock lever forward and pull forward the Chin Pushing the lock lever... - Page 22 III. Maintenance –Interior– Remove/Replace Chinstrap cover Chinstrap Covers are removable and washable. [To Detach] 1. Undo the snap at the end of each chinstrap. 2. Pull the chinstrap cover from the chinstrap to detach it. [To Attach] 1. In the reverse order of detaching (pay attention to the direction of the chinstrap cover), let the chinstrap go through from the upper portion of the chinstrap cover.
-
Page 23: Aa Remove/Replace Cheek Pads
Remove/Replace Cheek pads [To remove the cheek pads] Chinstrap Front hook Cheek pad Snaps Fig.1 Fig.2 1. Remove the Cheek pads from 2 2. Pull out the front hook of the Cheek snaps on the back of the pads, pads from the helmet. and pull out the Chinstrap from the Cheek pads. - Page 24 III. Maintenance –Interior– [To Install Cheek Pads] (engraved arrow mark Cheek Pad Direction indicates the pin position) Front Front Rear hook Left Right Interlining Interlining Where cheek touche Cheek pad Fig.1 1. Check the sides of the Cheek Pads. Hook the rear hook of Cheek Pad on the pin inside the helmet.
-
Page 25: As Remove/Replace Inner Pad
Remove/Replace Inner Pad [To Remove Inner pad] 2 Snaps Fig.1 Fig.2 1. Undo the snaps at the forehead 2. Undo the 2 snaps at the rear, then area by pulling them down. (Fig.1) the inner pad will be removed.(Fig.2) [To Install Inner pad] Snap Fig.1 Fig.2... -
Page 26: Note Exchangeable Inner Pad, Cheek Pads And Chinstrap Covers
III. Maintenance –Interior– Exchangeable Inner Pad, Cheek Pads and Chinstrap covers Note IBUKI interiors are exchangeable as shown in the table below. Fine fitting can be achieved by changing only cheek pads etc. IBUKI Inner pad Shell size Pad size (Thickness) Exchangeable Included in package XS (19mm) -
Page 27: Ad Remove/Replace Wind Shutter
Remove/Replace Wind Shutter The Wind Shutter is included in the package as the standard accessory. This accessory is intended to reduce the Wind Shutter introduction of wind from chin area while riding. It can be attached and detached as desired according to seasons and intended applications. -
Page 28: Af Remove/Replace Breath Guard-6
III. Maintenance –Interior– Remove/Replace Breath Guard-6 The Breath Guard-6 may be detached or attached according to your needs. [To Remove Breath Guard-6] Grip the Breath Guard-6 securely, and pull it upward to remove it. Breath Guard-6 [To Install Breath Guard-6] Breath Guard-6 As shown in the figure, set the each sleeve of the Breath Guard-6 into... -
Page 29: Inquiries • Parts List • Etc
When using a cleanser, use mild soap. (Do not use alkaline or similar detergent.) Contact for inquiries on the products and request for repair Contact an authorized dealer of Kabuto helmets about the products and request for repair. Request for repair •Contact the authorized Kabuto dealers for request of repair. -
Page 30: Ibuki Parts List And Table For Replacement
9-a (R) 9-a (L) 9-b (L) CAUTION! The following parts cannot be repaired to assure the performance of the helmet. •Helmet body (shell) •Shock absorbing liner •Chinstraps including Buckles Contact the authorized Kabuto dealers for detailed information on repairing. ENG-29... - Page 31 IBUKI Wind Shutter IBUKI Wind Shutter x 1 *The parte listed above are available from an authorized KABUTO dealer. *Parts with colour variations, specify your desired colour in placing an order. *The materials and specifications are subjected to change without notice for further improving the performance of the product.
