1
Product model and technical
specifications

Product model

The H3C S9820-64H switch is a high-density intelligent 100G switch developed for data center and
high-end campus networks, providing powerful hardware forwarding capacity and abundant data
center features.
The switch provides the following ports and removable components:
• 100G QSFP28 ports.
• Two 1G management Ethernet ports (one fiber port and one copper port).
• Removable fan trays in redundancy mode. By using different fan trays, you can change the
airflow direction of the chassis to adapt to ventilation needs.
• Removable power supplies in redundancy mode.
NOTE:
The S9820-64H switch model is available with multiple product codes. To identify the product code
of your switch, use the product barcode on its rear panel. The S9820-64H switch model is available
with the LS-9820-64H or LS-9820-64H-H1 product code. If the switch is referred to as the
S9820-64H switch, the information applies to the S9820-64H switch with either of the codes. If the
switch is referred to as the S9820-64H (LS-9820-64H) or LS-9820-64H switch, the information
applies only to the S9820-64H switch with the LS-9820-64H product code.

Technical specifications

Table1-1 Technical specifications
Item
Product code
Dimensions (H × W × D)
Weight
Console port
Management Ethernet port
USB port
QSFP28 port
Fan tray slot
Power supply slot
Minimum power consumption
S9820-64H
• LS-9820-64H
• LS-9820-64H-H1
88.1 × 440 × 540 mm (3.47 × 17.32 × 21.26 in)
≤ 27 kg (59.52 lb) (including three fan trays and four power
supplies, excluding transceiver modules and cables)
• 1 × mini USB console port
• 1 × serial console port
• 1 × 10/100/1000BASE-T copper port
• 1 × SFP port
1
64
3
4
• Dual AC inputs: 336 W
1-2
