- Page 1 SOMATOM Instructions for Use – Uninterruptable power supply (UPS) Version 1...
- Page 3 SOMATOM Instructions for Use – Uninterruptable power supply (UPS) Version 1...
- Page 4 Legend Indicates a hint Is used to provide information on how to avoid operating errors or information emphasizing important details Indicates the solution of a problem Is used to provide troubleshooting information or answers to frequently asked questions Indicates a list item Indicates a prerequisite Is used for a condition that has to be fulfilled before starting a particular operation Indicates a one-step operation...
- Page 5 Indicates a hazardous situation which, if not avoided, could result in death or serious injury. WARNING consists of the following elements: ◾ Information about the nature of a hazardous situation ◾ Consequences of not avoiding a hazardous situation ◾ Methods of avoiding a hazardous situation SOMATOM | Version 1 Print No. HC-C2-X05.610.64.01.02...
- Page 6 Legend Uninterruptable power supply (UPS) | Instructions for Use Print No. HC-C2-X05.610.64.01.02...
-
Page 7: Table Of Contents
Safety information 3 Description UPS front panel 3.1.1 Buttons 3.1.2 Control panel 4 Operation Normal mode Battery mode Shutting down the UPS 5 Technical specifications Dimensions and weight Storage 6 Location of labels Index SOMATOM | Version 1 Print No. HC-C2-X05.610.64.01.02... - Page 8 Table of contents Uninterruptable power supply (UPS) | Instructions for Use Print No. HC-C2-X05.610.64.01.02...
-
Page 9: Introduction
SOMATOM Sensation ◾ SOMATOM Sensation 10 ◾ SOMATOM Sensation 16 ◾ SOMATOM Sensation 40 ◾ SOMATOM Sensation 64 ◾ SOMATOM Sensation Open ◾ SOMATOM Sensation Cardiac ◾ SOMATOM Perspective ◾ syngo CT Workplace SOMATOM | Version 1 Print No. HC-C2-X05.610.64.01.02... -
Page 10: Applicability
Introduction Applicability This document is valid only in conjunction with the Instructions for Use of the corresponding SOMATOM CT system. Uninterruptable power supply (UPS) | Instructions for Use Print No. HC-C2-X05.610.64.01.02... -
Page 11: Safety
◾ Read the safety instructions in the CT system documentation in addition to the following safety information. For more information, see the SOMATOM Instructions for Use. Safety information CAUTION Not observing the Instructions for Use of the system, system options and accessories! Injury of the patient. - Page 12 Safety WARNING Wrong handling of batteries! Electrical shock or burn from high short-circuit current. ◆ Observe proper precautions. ◆ Servicing should be performed by qualified service personnel knowledgeable of batteries and required precautions. ◆ Keep unauthorized personnel away from batteries. ...
-
Page 13: Description
Any measurements that are running on the computer are stopped. UPS front panel The UPS front panel provides buttons and a control panel. Useful information is displayed about the UPS, load status, events, measurements, and settings. SOMATOM | Version 1 Print No. HC-C2-X05.610.64.01.02... -
Page 14: Buttons
Description (1) Power On indicator (green) (2) Battery On indicator (yellow) (3) Alarm indicator (red) (4) On/Off button (5) Enter button (6) Down button (7) Up button (8) Escape button Buttons 3.1.1 The following table displays the buttons and their functions on the LCD. - Page 15 The following table displays the front panel items and status descriptions. Item Color Status Description green The UPS is operating normally. yellow The UPS is in battery mode. The UPS has an active alarm or fault. Contact your Siemens Serv- ice. SOMATOM | Version 1 Print No. HC-C2-X05.610.64.01.02...
-
Page 16: Control Panel
Description Control panel 3.1.2 (1) Operation status (2) Battery status (3) Efficiency and load group information (4) Load/equipment status By default, or after 5 minutes of inactivity, the LCD displays the screen saver. The backlight LCD automatically dims after 10 minutes of inactivity. - Page 17 End of The UPS is in bat- Shut down the equip- backup tery mode and ment. time the battery is run- ning low. 1 beep every 3 seconds SOMATOM | Version 1 Print No. HC-C2-X05.610.64.01.02...
- Page 18 Description Uninterruptable power supply (UPS) | Instructions for Use Print No. HC-C2-X05.610.64.01.02...
-
Page 19: Operation
At the end of the battery backup time, the UPS shuts down and the protected equipment is no longer supplied with power. Return of AC input power The UPS automatically restarts when power returns. SOMATOM | Version 1 Print No. HC-C2-X05.610.64.01.02... -
Page 20: Shutting Down The Ups
Operation After a discharge, the battery needs 8 hours for recharging. Shutting down the UPS To shut down the UPS: ◆ Press the Power button on the front panel for three seconds. The UPS starts to beep and shows the status “ UPS shutting OFF...”. The UPS then transfers to standby mode, and the power indicator turns off. -
Page 21: Technical Specifications
35.20 lb ±3 % Storage If the UPS must be stored prior to installation, storage needs to be in a dry place. The permitted storage temperature range is 0°C (32°F) to + 40°C (104°F). SOMATOM | Version 1 Print No. HC-C2-X05.610.64.01.02... - Page 22 Technical specifications Uninterruptable power supply (UPS) | Instructions for Use Print No. HC-C2-X05.610.64.01.02...
-
Page 23: Location Of Labels
California to cause cancer and reproductive harm. CAUTION: Risk of electrical shock, do not remove cover. No user serviceable parts inside. Refer servicing to qualified service personnel. SOMATOM | Version 1 Print No. HC-C2-X05.610.64.01.02... - Page 24 Location of labels UPS receives power from more than one source. Disconnection of the AC source and battery are required to de-energized this unit before service. Risk of explosion if battery is replaced by an incorrect type. Dispose of used batteries according to the instructions. This equipment is intended for connection to multiple voltages and frequencies.
-
Page 25: Index
19 buttons 14 compatible systems 9 control panel 16 front panel 13 location of labels 23 normal mode 19 operation 19 safety information 11 shutting down UPS 20 technical specifications 21 SOMATOM | Version 1 Print No. HC-C2-X05.610.64.01.02... - Page 26 This page has been intentionally left blank. Uninterruptable power supply (UPS) | Instructions for Use Print No. HC-C2-X05.610.64.01.02...
- Page 28 The original language of this document is English. Siemens Healthcare Legal Manufacturer Headquarters Siemens Healthcare GmbH Siemens Healthcare GmbH Henkestr. 127 Henkestr. 127 91052 Erlangen 91052 Erlangen Germany Germany Phone: +49 9131 84-0 siemens.com/healthcare Print No. HC-C2-X05.610.64.01.02 | © Siemens Healthcare GmbH, 2017 www.siemens.com/healthcare...
