Eaton Tripp Lite SmartOnline TAA Series
Rack / Tower Advanced Users Guide
SU1500RTXLCD2UTAA
SU2200RTXLCD2UTAA
SU3000RTXLCD2UTAA
BP48RT2UTAA
BP72RT2UTAA
p/n: DPD-T2TL2206
Revision 01

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Tripp Lite TAA Series and is the answer not in the manual?

Questions and answers

Related Manuals for Eaton Tripp Lite TAA Series

Summary of Contents for Eaton Tripp Lite TAA Series

  • Page 1 Eaton Tripp Lite SmartOnline TAA Series Rack / Tower Advanced Users Guide SU1500RTXLCD2UTAA SU2200RTXLCD2UTAA SU3000RTXLCD2UTAA BP48RT2UTAA BP72RT2UTAA p/n: DPD-T2TL2206 Revision 01...
  • Page 2 Internet. Eaton Corporation 8609 Six Forks Road, Raleigh, NC 27615, USA Telephone: 800-356-5794 ©Copyright 2022 Eaton, Raleigh, NC, USA. All rights reserved. No part of this document may be reproduced in any way without the express written approval of Eaton.

  • Page 3: Special Symbols

    Phillips and Pozidriv are registered trademarks of Phillips Screw Company. batteries and the required precautions. ECopyright 2008–2010 Eaton Corporation, Raleigh, NC, USA. All rights reserved. No part of this document may be reproduced in any way without the express written approval of Eaton Corporation.
  • Page 4 During the replacement of the Battery Module, it is imperative to use the same type and number of element as the original Battery Module provided with the UPS to maintain an identical level of performance and safety. If there are any questions, don’t hesitate to contact your local Eaton representative.

  • Page 5: Table Of Contents

    5 5 U U P P S S M M a a i i n n t t e e n n a a n n c c e e ....................................................... . 3 3 1 1 5.1 Equipment Care ............................31 5.2 Storing the Equipment ..........................31 Eaton Tripp Lite Series SmartOnline TAA UPS User Guide DPD-T2TL2206—Rev 01...
  • Page 6 7 7 S S p p e e c c i i f f i i c c a a t t i i o o n n s s ......................................................... . 4 4 0 0 7.1 Model Specifications ..........................40 Eaton Tripp Lite Series SmartOnline TAA UPS User Guide DPD-T2TL2206—Rev 01...

  • Page 7: Introduction

    Before installing your UPS, please read the booklet presenting the safety instructions. Then follow the indications in this manual. To discover the entire range of products and the options available for the Tripp Lite by Eaton SmartOnline UPS range visit our web site at Tripp Lite.com...
  • Page 8 With the Tripp Lite by Eaton SmartOnline power system, you can safely eliminate the effects of power disturbances and guard the integrity of your equipment. Providing outstanding performance and reliability, the Tripp Lite by Eaton SmartOnline power system unique benefits include: •...

  • Page 9: Standard Installations

    59.5 / 27 17.7 x 17.3 x 3.4 / 450 x 440 x 86.5 BP72RT2UTAA 86.4 / 39.2 23.8 x 17.3 x 3.4 / 605 x 440 x 86.5 Eaton Tripp Lite Series SmartOnline TAA UPS User Guide DPD-T2TL2206—Rev 01...

  • Page 10: Rear Panels

    10 USB communication port 11 Connector for ROO (Remote On/Off) control and RPO (Remote Power Off) SU3000RTXLCD2UTAA (*) Primary and Grouped outlets ) are protected by 20A circuit breakers. Eaton Tripp Lite Series SmartOnline TAA UPS User Guide DPD-T2TL2206—Rev 01...
  • Page 11 Description Part number BP48RT2UTAA Extended Battery Module BP72RT2UTAA RK2PC SmartOnline 2– Post Rack Kit LXE Communication Card Network Card EBMCBL48 2m cable 48V EBM EBMCBL72 2m cable 72V EBM Eaton Tripp Lite Series SmartOnline TAA UPS User Guide DPD-T2TL2206—Rev 01...

  • Page 12: 2 I I N N S S T T A A L L L L A A T T I I O O N

    Elements supplied depending on the USB communication cable version or optional: LXE communication card (optional, Safety instructions standard on Network Bundle models) Quick start Mounting kit for 19-inch enclosures Eaton Tripp Lite Series SmartOnline TAA UPS User Guide DPD-T2TL2206—Rev 01...

  • Page 13: Connecting The Internal Battery

    Always keep 150 mm of free space behind the UPS rear panel. Figure 5. Internal Battery Connection Remove the center cover of the front panel. Push left cover toward to right direction. Open the left side of the front panel. Eaton Tripp Lite Series SmartOnline TAA UPS User Guide DPD-T2TL2206—Rev 01...

  • Page 14: Ups Tower Installation

    If installing additional cabinets, place them next to the UPS in their final location. Figure 6. UPS Tower Install • Adjustment of the orientation of the LCD panel and of the logo. Eaton Tripp Lite Series SmartOnline TAA UPS User Guide DPD-T2TL2206—Rev 01...

  • Page 15: Ups Rack Installation

    2 2 . . 3 3 . . 2 2 U U P P S S R R a a c c k k I I n n s s t t a a l l l l a a t t i i o o n n • Rack mounting of UPS, EBM, and accessory modules. Follow steps 1 to 4 for module mounting on the rails. Eaton Tripp Lite Series SmartOnline TAA UPS User Guide DPD-T2TL2206—Rev 01...

  • Page 16: Smartonline External Battery Pack Installation

    The external battery pack is heavy, wear safety shoes. Handling of the external battery pack will require at least two people for installation. To rack mount the external battery pack follow the steps below: Eaton Tripp Lite Series SmartOnline TAA UPS User Guide DPD-T2TL2206—Rev 01...

  • Page 17: Extended Battery Pack Rackmount Connections

    Plug the external battery pack power cable(s) into the external battery connector(s) and repeat until all external battery packs are connected. Up to 4 external battery packs may be connected to the UPS. See Figure 10 Eaton Tripp Lite Series SmartOnline TAA UPS User Guide DPD-T2TL2206—Rev 01...

  • Page 18: Ups And Extended Battery Pack Tower Installation

    Tip If you ordered other UPS accessories, refer to specific user manuals to check the tower installation with the UPS. Figure 11. UPS and Extended Battery Pack Tower Installation Eaton Tripp Lite Series SmartOnline TAA UPS User Guide DPD-T2TL2206—Rev 01...

  • Page 19: Extended Battery Pack Tower Connections

    Connect the battery detection cable(s) to the connector of the UPS and of the external battery pack(s). Figure 12. Tower Mount External Battery Pack Connections BP48RT2UTAA BP72RT2UTAA Eaton Tripp Lite Series SmartOnline TAA UPS User Guide DPD-T2TL2206—Rev 01...

  • Page 20: Control Panel

    High Efficiency mode or on battery Green mode. The UPS is on Battery mode. Orange The UPS is on Bypass mode. Orange The UPS has an active alarm or fault. Eaton Tripp Lite Series SmartOnline TAA UPS User Guide DPD-T2TL2206—Rev 01...

  • Page 21: Lcd Description

    BATTERY MODE A utility failure has occurred and the UPS is on Battery mode. The UPS is powering the equipment with the battery power. RUNTIME:104MIN Prepare your equipment for shutdown. Eaton Tripp Lite Series SmartOnline TAA UPS User Guide DPD-T2TL2206—Rev 01...

  • Page 22: Ups Home Menu

    The BATTERY voltage screen tracks the Displays the UPS mode , battery voltage charge level of your connected battery BATT:50.2V 100% and battery charge percentage. bank in terms of voltage and charge percentage. Eaton Tripp Lite Series SmartOnline TAA UPS User Guide DPD-T2TL2206—Rev 01...

  • Page 23: Display Functions

    RESET KWH USED is used to reset the RESET KWH USED power used. FACTORY SETT command is used to FACTORY SETT restore factory settings. Eaton Tripp Lite Series SmartOnline TAA UPS User Guide DPD-T2TL2206—Rev 01...
  • Page 24 Select input signal function for INPUT COM SETTINGS INPUT DB9-4 DB9-4. Select output signal function for OUTPUT OUTPUT RELAY RELAY. Select output signal function for OUTPUT OUTPUT DB9-1 DB9-1. Eaton Tripp Lite Series SmartOnline TAA UPS User Guide DPD-T2TL2206—Rev 01...

  • Page 25: User Settings

    UPS fault, Event log data and settings are in all supported LOCAL SETTINGS languages. AUDIBLE ALARM ENABLED* (Default) Enables or disables the [ENABLED] [DISABLED ON audible alarm. BAT] [ALWAYS DISABLED] Eaton Tripp Lite Series SmartOnline TAA UPS User Guide DPD-T2TL2206—Rev 01...
  • Page 26 BATTERY SETTINGS percentage battery charge is reached. BATT LOW LEVEL 0%* (Default) [0%]..[100%] The alarm triggers when the set percentage of battery charge is reached. Eaton Tripp Lite Series SmartOnline TAA UPS User Guide DPD-T2TL2206—Rev 01...
  • Page 27 BATTERY] [LOW BATTERY] actuate Output signal parameters through external [BATTERY FAULT] [BYPASS] [UPS OK] [LOAD PROTECTED] contact connector or RS232. [LOAD POWERED] [GENERAL ALARM] [BAT CHARGING] [OVLD PREALARM] [BAT DISCONN] Eaton Tripp Lite Series SmartOnline TAA UPS User Guide DPD-T2TL2206—Rev 01...

  • Page 28: Communication Ports

    Available Any connectivity card Available Any connectivity card Available Available Connect the RS232 ⑰ or USB ⑱ communication cable to the serial or USB port on the computer equipment. Eaton Tripp Lite Series SmartOnline TAA UPS User Guide DPD-T2TL2206—Rev 01...

  • Page 29: Remote Control Functions

    R R e e m m o o t t e e C C o o n n t t r r o o l l F F u u n n c c t t i i o o n n s s Programmable Signal Inputs The Tripp Lite by Eaton SmartOnlineUPS incorporates 3 programmable signal inputs: one Remote Power Off (RPO) input terminal, one Remote On/Off (ROO) input terminal, one RS-232 input (pin-4). Signal inputs can be configured see (3.5 User...
  • Page 30 When contact changes from closed to open, the UPS is switched-off (or stays Off). • On/Off control via button has priority over the remote control. Comments Connector type Terminal, 14 AWG maximum wires External breaker specification 60 V DC/30V AC 20mA max Eaton Tripp Lite Series SmartOnline TAA UPS User Guide DPD-T2TL2206—Rev 01...

  • Page 31: Normally Closed

    Programmable Signal Outputs The Tripp Lite by Eaton SmartOnlineUPS incorporates 4 programmable signal outputs: one relay output, three optocouplers outputs (pin- 1/7/8). Signal outputs can be configured (see COM SETTING->OUTPUT RELAY,...

  • Page 32: Connectivity Cards

    Common Connectivity Cards Connectivity cards allow the UPS to communicate in a variety of networking environments and with different types of devices. The Tripp Lite by Eaton SmartOnlineUPS models have one available communication bay for the following connectivity cards: •...

  • Page 33: Tripp Lite By Eaton Poweralert Software Suite

    C C y y b b e e r r s s e e c c u u r r i i t t y y Tripp Lite by Eaton is committed to minimizing the Cybersecurity risk in its products and deploys cybersecurity best practices and latest cybersecurity technologies in its products and solutions, making them more secure, reliable and competitive for our customers.

  • Page 34: Start-Up And Normal Operation

    O O p p e e r r a a t t i i n n g g M M o o d d e e s s The Tripp Lite by Eaton SmartOnline UPS front panel indicates the status through the front panel indicators, see section .

  • Page 35: Return Of Ac Power

    10 ms when utility fails. Transfers to High Efficiency mode will be active after 5 minutes of Bypass voltage monitoring: if Bypass quality is not in tolerance, then the UPS will remain in Online mode. Eaton recommends to use the HE mode only to protect IT equipment. To set the High Efficiency mode: From the “UPS Home Menu“...

  • Page 36: Configuring The Battery Settings

    The log retains 50 events with the most recent event listed as the first event. Press the ESC button twice to exit back to the “3.3 UPS Home Menu“ menu. Eaton Tripp Lite Series SmartOnline TAA UPS User Guide DPD-T2TL2206—Rev 01...

  • Page 37: Equipment Care

    W W h h e e n n t t o o R R e e p p l l a a c c e e B B a a t t t t e e r r i i e e s s Tripp Lite by Eaton UPS batteries have an expected life span of 3-5 years. You should take proactive steps to ensure you replace your batteries for optimal operation and reliability.

  • Page 38: Replacing Batteries

    Push left cover toward to right direction. Open the battery door. Disconnect the battery connectors. A ribbon cable connects the LCD control panel to the UPS. Do not pull on the cable or disconnect it. Eaton Tripp Lite Series SmartOnline TAA UPS User Guide DPD-T2TL2206—Rev 01...
  • Page 39 The front panel displays "Battery test in progress" and the percentage of the test completed. NOTE The UPS load percentage must be greater than 10% in order to run a battery test. Eaton Tripp Lite Series SmartOnline TAA UPS User Guide DPD-T2TL2206—Rev 01...

  • Page 40: Recycling The Used Equipment

    Eaton, Powerware, and BladeUPS are registered trademarks of Eaton Corporation or its subsidiaries and affiliates. Phillips and Pozidriv are registered trademarks of Phillips Screw Company. ECopyright 2008–2010 Eaton Corporation, Raleigh, NC, USA. All rights reserved. No part of this document may be reproduced in any way without the express written approval of Eaton Corporation.
  • Page 41 The UPS does not provide the expected The batteries need charging or service. Apply utility power for 48 hours to charge backup time. the batteries. If the condition persists, contact your service representative. Eaton Tripp Lite Series SmartOnline TAA UPS User Guide DPD-T2TL2206—Rev 01...

  • Page 42: Typical Alarms And Faults

    DC BUS- TOO HIGH /PSDR damaged /CNTL damaged Overload/improper load type/PSDR/CNTL damaged DC BUS+ TOO LOW Overload/improper load type/PSDR/CNTL damaged DC BUS- TOO LOW Overload/improper load type/PSDR/CNTL damaged DC BUS UNBALANCE Eaton Tripp Lite Series SmartOnline TAA UPS User Guide DPD-T2TL2206—Rev 01...
  • Page 43 AMB. TEMP. ALARM the ventilation is blocked Frequency out of range Check AC Freq AC FREQ NOT OK Voltage out of range AC VOLT NOT OK Check AC Volt Eaton Tripp Lite Series SmartOnline TAA UPS User Guide DPD-T2TL2206—Rev 01...
  • Page 44 Check overload pre-alarm setting and OVLD PREALARM 102%(default), settable from load HMI. Output power overload, Max Please check the load capacity POWER OVERLOAD (P,S) > L2 (L2 = 102%) Eaton Tripp Lite Series SmartOnline TAA UPS User Guide DPD-T2TL2206—Rev 01...

  • Page 45: Silencing The Alarm

    S S e e r r v v i i c c e e a a n n d d S S u u p p p p o o r r t t If you have any questions or problems with the UPS, call the Eaton technical support helpdesk at 800–356–...

  • Page 46: Model Specifications

    59.5 / 27 17.7 x 17.3 x 3.4 / 450 x 440 x 86.5 BP72RT2UTAA 86.4 / 39.2 23.8 x 17.3 x 3.4 / 605 x 440 x 86.5 Eaton Tripp Lite Series SmartOnline TAA UPS User Guide DPD-T2TL2206—Rev 01...
  • Page 47 PF=0.9 120V 25.0A 3000VA/2700W PF=0.9 125V 24.0A 3000VA/2700W PF=0.9 Nominal frequency 50/60Hz auto-sensing Frequency range 50Hz : 40-60Hz before transfer to battery 60Hz : 40-70Hz before transfer to battery Eaton Tripp Lite Series SmartOnline TAA UPS User Guide DPD-T2TL2206—Rev 01...
  • Page 48 Harmonic Distortion < 3% THDV on linear load < 5% THDV on non-linear load Transfer Time Online Mode: 0ms High Efficiency mode: 10ms maximum (due to loss of utility) Eaton Tripp Lite Series SmartOnline TAA UPS User Guide DPD-T2TL2206—Rev 01...
  • Page 49 This UPS can be used in and supplied to load TN/TT/IT power system for HV models, TN power system for LV models. UPS enclosure IP rating IP20 0 to 40°C (32 to 104°F) with batteries Storage Temperatures -25 to 55°C (-13 to 130°F) without batteries Eaton Tripp Lite Series SmartOnline TAA UPS User Guide DPD-T2TL2206—Rev 01...
  • Page 50 3 EBM 4 EBM 137.0 132.0 128.0 123.0 Table 23. SU3000RTXLCD2UTAA Battery Runtimes 1200 1600 1800 2000 2100 2200 2300 2400 2500 2600 2650 2700 Load in Watts Internal Eaton Tripp Lite Series SmartOnline TAA UPS User Guide DPD-T2TL2206—Rev 01...
  • Page 51 Table 23. SU3000RTXLCD2UTAA Battery Runtimes (Continued) 1 EBM 25.3 24.1 23.6 23.0 2 EBM 46.9 44.6 43.6 42.6 3 EBM 70.0 67.0 65.5 63.9 4 EBM 95.0 90.0 88.0 86.3 Eaton Tripp Lite Series SmartOnline TAA UPS User Guide DPD-T2TL2206—Rev 01...
  • Page 52 DPD-T2TL220601 DPD-T2TL2206 01...
