- Page 1 Eaton UPS Accessories System Parallel Module Installation and Operation Manual...
- Page 3 SPM. Please read all instructions before operating the equipment and save this manual for future reference. ©2014 Eaton Corporation All Rights Reserved The contents of this manual are the copyright of the publisher and may not be reproduced (even extracts) unless permission granted.
-
Page 4: Table Of Contents
Table of Contents InTrodUCTIon . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Installation Features . - Page 5 Eaton System Parallel Module and UPS(93E as example)........
- Page 6 list of Tables Table 3-1. SPM Cabinet Weights ..............Table 3-2.
-
Page 7: Introduction
Chapter 1 Introduction The Eaton® System Parallel Module (SPM) provides means to isolate each parallel connected UPS module output (for UPS module maintenance) and bypass switchgear to isolate the complete system for maintenance. The SPM is housed in a single free-standing cabinet with safety shields behind the doors for hazardous voltage protection. -
Page 8: Model Configurations
Line-up-and-match SPM cabinets are installed adjacent to the UPS. The recommended installation location is on the right side of the UPS cabinet. figure 1-2 . Eaton System Parallel module and UPS(93E as example) 1 .2 model Configurations The following model configurations are available. -
Page 9: Symbols, Controls, And Indicators
1 .6 for more Information Refer to the Eaton 93E UPS (80-200 kVA, 380/400/415V) Installation and Operation Manual or 93PM UPS (50-200kW, 380/400/415V) Installation and Operation Manual for the following additional information: • UPS, optional components, and accessory installation instructions, including site preparation, planning for installation, and wiring and safety information. -
Page 10: Safety Warnings
Chapter 2 Safety Warnings IMPORTANT SAFETY INSTRUCTIONS SAVE THESE INSTRUCTIONS This manual contains important instructions that should be followed during installation and maintenance of the SPM. Read all instructions before operating the equipment and save this manual for future reference. The SPM are designed for industrial or computer room applications with UPS, and contains safety shields behind the door and front panels. -
Page 11: Installation Plan And Unpacking
Similar with the UPS, the SPM installation site should meet the environmental parameters outlined in this manual. If the UPS is to be operated at an altitude higher than 1000m (3300 ft.), contact an Eaton service representative for important information about high altitude operation. The operating environment must meet the weight, clearance, and environmental requirements specified. -
Page 12: 3 .2 .1 Environmental And Installation Considerations
Table 3-1 . SPm Cabinet Weights Weight kg (lb) model Shipping Installed Point loading Eaton 1+1 120kVA SPM Eaton 2+1 120kVA SPM 348(767) 270(595) 33.8 (77.4)/wheel (total 8 wheels) Eaton 3+1 120kVA SPM Eaton 1+1 200kVA SPM Eaton 2+1 200kVA SPM 363.5(801) -
Page 13: Figure 3-1. Spm Cabinet Dimensions(Front, Right And Rear Views)
Cable Entry Hole(Rear) Front View Right View Rear View figure 3-1 . SPm Cabinet dimensions(front, right and rear Views) Dimensions are in millimetres [inches] Cable Entry Hole(Bottom) Cable Entry Hole(Top) Top View Bottom View figure 3-2 . SPm Cabinet dimensions (Top and Bottom Views) Dimensions are in millimetres [inches] System Parallel Module... - Page 14 Wire sizes are based on using the specified breakers. • Refer to the appropriate Eaton 93E 80-200kVA and 93PM 50-200 kW UPS Installation and Operation manual listed in corresponding paragraph for UPS cabinet conduit and terminal specifications and locations.
-
Page 15: Spm Wiring Preparation
1-M16-Bolt-Mounting 210(23.71) M16 Hex 1-M16-Bolt-Mounting 210(23.71) M16 Hex 1-M16-Bolt-Mounting 210(23.71) M16 Hex 1-M16-Bolt-Mounting 210(23.71) M16 Hex The SPM to Load Eaton 1+1 120kVA SPM 1-M16-Bolt-Mounting 210(23.71) M16 Hex 1-M16-Bolt-Mounting 210(23.71) M16 Hex 1-M16-Bolt-Mounting 210(23.71) M16 Hex 1-M16-Bolt-Mounting 210(23.71) M16 Hex... - Page 16 210(23.71) M16 Hex 1-M16-Bolt-Mounting 210(23.71) M16 Hex 1-M16-Bolt-Mounting 210(23.71) M16 Hex 1-M16-Bolt-Mounting 210(23.71) M16 Hex The SPM to Load Eaton 1+1 200kVA SPM 1-M16-Bolt-Mounting 210(23.71) M16 Hex 1-M16-Bolt-Mounting 210(23.71) M16 Hex 1-M16-Bolt-Mounting 210(23.71) M16 Hex 1-M16-Bolt-Mounting 210(23.71) M16 Hex The UPS to SPM MOB 1-M16-Bolt-Mounting 210(23.71)
-
Page 17: Inspecting And Unpacking The Spm
Carefully inspect the outer packaging for evidence of damage during transit. CAUTION Do not install a damaged cabinet. Report any damages to the carrier and contact an Eaton service representative immediately. NOTE For the following step, verify that the forklift or pallet jack is rated to handle the weight of the cabinets (see Table 3-1 for cabinet weight). -
Page 18: Breaker Location
Inspect the contents for any evidence of physical damage, and compare each item with the Bill of Lading. If damage has occurred or shortages are evident, contact an Eaton service representative immediately to determine the extent of the damage and its impact on further installation. -
Page 19: Installation
Chapter 4 Installation 4 .1 Preliminary Installation Information WARNING Wires enter/out can from the bottom, top and rear holes of cabinet. Refer to the following while installing the SPM: • To review the SPM manual, Chapter 3 of this manual for cabinet dimensions, equipment weight, wiring and installation notes. -
Page 20: Figure 4-1. Removing The Front Shipping Bracket
Slowly roll the cabinet toward the front of the pallet. Continue rolling the cabinet down the ramp until the cabinet is clear of the ramp (see Figure 4-4). Roll the cabinet to the final installation location. If installing the cabinet permanently, retain the shipping brackets and hardware; otherwise, recycle the pallet, ramp, and shipping brackets in a responsible manner. -
Page 21: External Power Cables Connecting
Refer figure 4-6 to install the signal wires. The wire code is minimum 22AWG. Please refer to the appropriate Eaton 93E80-200kVA and 93PM 50-200kW UPS installation and operation manual listed in corresponding paragraph for pull chain and building alarm connections. -
Page 22: Figure 4-5. Power Terminal Locations
To Utility Connections N To Utility Connections L2 To Utility Connections L2 To Utility Connections N To Ground To Utility Connections L1 To Utility Connections L3 To Utility Connections L3 To Utility Connections L1 To UPS1 Output N To UPS1 Output L1 To UPS1 Output L2 To UPS1 Output L3 To UPS2 Output N... -
Page 23: Figure 4-6. Power And Signal Terminal Locations
UPS4 COM To UPS4 Interface CN7- UPS4 NC To UPS4 Interface CN7+ UPS3 COM To UPS3 Interface CN7- UPS3 NC To UPS3 Interface CN7+ UPS2 COM To UPS2 Interface CN7- UPS2 NC To UPS2 Interface CN7+ UPS1 COM To UPS1 Interface CN7- UPS1 NC To UPS1 Interface CN7+ MBS4 -... -
Page 24: Initial Startup
Make a copy of the Installation Checklist before filling it out, and retain the original. After the installation is complete, an Eaton Customer Service Engineer must verify the operation of the UPS system and commission it to support the critical load. The service representative cannot perform any installation tasks other than verifying software and operating setup parameters. - Page 25 notes System Parallel Module...
-
Page 26: Onelines And Schematics
Chapter 5 onelines and Schematics 5 .1 Schematics Figure 5-1 show the SPM schematics. figure 5-1 . SPm Schematics System Parallel Module... -
Page 27: Maintenance
6 .3 maintenance Training A basic training course, available from Eaton Corporation, gives you a competent working knowledge of the UPS system operation and teaches you how to perform first level corrective maintenance. For more information about training and other services, contact the Help Desk .see paragraph 1.7 . -
Page 28: Product Specifications
Chapter 7 Product Specifications This section provides the following specifications: • Model Numbers • Environmental and safety specifications 7 .1 Specifications The following sections detail the SPM specifications and the environmental and safety specifications for the SPM. Environmental and Safety Specifications. specifications 7 .1 .1 Electrical Units... - Page 32 614-01728-00...
