- Page 1 Rejestratory (przetworniki) różnicy ciśnień do clean room (ModBus RTU) HD50CR-AS - http://acse.pl English Operating manual Low pressure transmitter / data logger HD50CR-AS www.deltaohm.com Keep for future reference.
-
Page 2: Table Of Contents
ALARMS ........................ 8 STATISTICAL FUNCTIONS ................... 10 CALIBRATION ..................... 11 MENU ........................12 MODBUS ......................17 TECHNICAL CHARACTERISTICS ................23 10 INSTRUMENT STORAGE ..................26 11 SAFETY INSTRUCTIONS ..................26 12 PROBES AND ACCESSORIES ORDERING CODES ..........27 HD50CR-AS V1.1... -
Page 3: Introduction
1 INTRODUCTION HD50CR-AS is a relative or differential low pressure transmitter and data logger de- signed for wall flush-mounting. Measuring range ±100 Pa. A silicon piezoresistive sensor with high accuracy and temperature compensation is used, which allows excellent linearity, repeatability and stability over the time. The auto-zeroing feature allows stable measurements over the time without the need to recalibrate. -
Page 4: Description
Displays the statistical functions (MIN, MAX, AVG). In menu, decreases the displayed value or move to the previous parameter. Enters the menu. In menu, confirms the displayed value. Cancel the operation or goes back to the previous level. HD50CR-AS V1.1... -
Page 5: Installation
The connections on the upper part of the housing are as follows: RS485 port Pressure input (+) Pressure input (-) RS485 24 V ac/dc OUT 1 OUT 2 OUT 3 POWER Power supply Analog output 1 24 Vac (L=Line, N=Neutral) or 24 Vdc Analog output 2 Analog output 3 HD50CR-AS V1.1... - Page 6 220 Ω Shield Shield RS485 connection Connect any combined temperature and relative humidity probe to the 8-pole M12 connector on the bottom of the housing. Pt100 Pinout of the external side of the male M12 connector of the transmitter HD50CR-AS V1.1...
-
Page 7: Configuration
• Via the HD35AP-S application software, connecting the instrument to the PC via USB. • Via the Modbus-RTU protocol and the RS485 connection (see chapter 8). The HD35AP-S application software is downloadable from Delta OHM website For the use of the application software, see the corresponding instructions. HD50CR-AS... -
Page 8: Alarms
Enabling the Buzzer Latch option, the buzzer continues to sound even after the alarm condition has ceased. In the event of an alarm in progress with the buzzer active, the buzzer can be silenced for a configurable time. Once the set time has elapsed, the buzzer will resume sounding HD50CR-AS V1.1... - Page 9 Silencing Silencing time elapsed The following example shows the silencing of the buzzer with Latch option enabled. Upper threshold 60 °C 59 °C Hysteresis Hysteresis 11 °C 10 °C Lower threshold Delay BUZZER Silencing Silencing Silencing time elapsed HD50CR-AS V1.1...
-
Page 10: Statistical Functions
By pressing FUNC/ once more, the instrument asks if the calculation of the statisti- cal values is to be reset (FUNC CLR). Select YES or nO using / keys, then confirm with the MENU/↵ key. HD50CR-AS V1.1... -
Page 11: Calibration
If the probe is ordered with the instrument, the probe is already factory calibrated. If the probe is ordered later, the calibration must be performed by the user via the Fb00 menu. HD50CR-AS V1.1... -
Page 12: Menu
F500 (UNIT MEAS MENU): units of measurement F600 (LOG MENU): logging settings F700 (AN OUT MENU): setting of the analog outputs F800 (MODBUS MENU): Modbus settings F900 (CLK MENU): clock settings FA00 (PSW MENU): password settings Fb00 (CAL MENU): calibration settings HD50CR-AS V1.1... - Page 13 F408: period, in seconds, of the beep emitted by the buzzer {1…3600, default=2} F409: duration, in seconds, of the beep emitted by the buzzer {0.1…20, default=1.0} F410: alarm of the quantity of index 1 F411: lower alarm threshold F412: lower alarm threshold enabling {On/OFF, default=On} HD50CR-AS V1.1...
- Page 14 F604: measurements acquisition interval {default=1 s}. If a value higher than the logging interval is set, the measurements will be detected with interval equal to the logging interval. F605: deletion of all stored measurements from the instrument memory {YES/nO} HD50CR-AS V1.1...
- Page 15 F804: waiting of 3.5 characters after transmission with Modbus protocol {nO=violate protocol and go in receiving mode right after transmission / YES=respect pro- tocol and wait 3.5 characters after transmission, default=nO} F805: enabling of the password for changing the configuration via Modbus {On/OFF, default=OFF} HD50CR-AS V1.1...
- Page 16 Fb07: interval, in minutes, of the differential pressure auto-calibration at zero {5…360, default=60} Fb08: differential pressure second calibration point (in Pa) Fb09: reset of the differential pressure second calibration point Fb10: type of calibration used {FACT=factory / USEr=user, default=FACT} HD50CR-AS V1.1...
-
Page 17: Modbus
MODBUS The device general information can be read through the function code 0x2B/0x0E: • Manufacturer (Delta OHM) • Model • Firmware version The complete list of MODBUS registers is shown below. If you try to read a register that is not present, the instrument returns the fixed value 32767. The list of the available registers can be downloaded in the PC using the function "... - Page 18 Enabling of the buzzer “Latch” function for the quantity #3: 0= disabled, 1=enabled Enabling of the buzzer “Latch” function for the quantity #4: 0= disabled, 1=enabled Enabling of the buzzer “Latch” function for the quantity #5: 0= disabled, 1=enabled HD50CR-AS V1.1...
- Page 19 Month of last measurement. 10002 Day of last measurement. 10003 Hour of last measurement. 10004 Minutes of last measurement. 10005 Seconds of last measurement. Password level for the current connection: 10013 0=no password, 1=user level, 2= administrator level HD50CR-AS V1.1...
- Page 20 10052 Example: if 1=Temp., 2=RH, 3=Td, 4=Diff.Press., 5=AH, 6=Tw, the reg- ister is set to 0000 0000 0001 0010, only the relative humidity (RH) and the absolute humidity (AH) will be displayed alternatively. 10064 Modbus address HD50CR-AS V1.1...
- Page 21 20000 User code with ASCII codification of the quantity #1. a 20011 da 20012 User code with ASCII codification of the quantity #2. a 20023 da 20024 User code with ASCII codification of the quantity #3. a 20035 HD50CR-AS V1.1...
- Page 22 Differential pressure alarm delay time in seconds. Alarm hysteresis for with 4-wire Pt100 sensor of the T/RH TEMPERATURE 30174 combined probe in the set measurement unit (x100). Alarm delay time for temperature with 4-wire Pt100 sensor of the T/RH 30175 combined probe in seconds. HD50CR-AS V1.1...
-
Page 23: Technical Characteristics
± (2 + 1.5% of the measure)% @ T=remaining range Sensor operating -20…+80 °C temperature Response time < 20 s (air speed = 2 m/s, without filter) Temperature drift ±2% in all the operating temperature range Stability 1%/year HD50CR-AS V1.1... - Page 24 Electrical connections Screw terminal block (max. 1.5 mm / AWG16 cables) Operating temperature -10…+50 °C Storage temperature -10…+70 °C Housing material Stainless steel (AISI 316 front panel) Weight 640 g approx. Installation Flush-mount Protection degree IP 65 (front panel, with protective cap on USB connector) HD50CR-AS V1.1...
- Page 25 Dimensions (mm): MENU FUNC Ø3 (x4) HD50CR-AS V1.1...
-
Page 26: Instrument Storage
The user of the instrument must make sure that the following regulations and direc- tives related to the handling of hazardous materials are fulfilled: European directives on safety and health at work. • National regulations on safety and health at work. • Accident prevention regulations. • HD50CR-AS V1.1... -
Page 27: Probes And Accessories Ordering Codes
Saturated solution to check Relative Humidity probes at 11 % RH, includes ring adapter for 14 mm diameter probes, thread M12×1. DELTA OHM metrology laboratories LAT N° 124 are ISO/IEC 17025 accredited by ACCREDIA for Temperature, Humidity, Pressure, Photometry / Radiometry, Acous- tics and Air Velocity. - Page 28 OTES HD50CR-AS V1.1...
- Page 29 OTES HD50CR-AS V1.1...
- Page 30 OTES HD50CR-AS V1.1...
- Page 32 | sales@deltaohm.com WARRANTY Delta OHM is required to respond to the "factory warranty" only in those cases provided by Legislative Decree 6 September 2005 - n. 206. Each instrument is sold after rigorous inspections; if any manufacturing defect is found, it is necessary to contact the distributor where the instrument was purchased from.
