MAIN COMPONENTS
Fig.1
Ref. Description
1. Mixer shower body
2. Elbow complete with 'O' rings
3. Retaining nut with olive and pipe trim
4. Mounting plate
5. Blanking plug
6. Outlet connector
All dimensions listed in this fitting book regarding the product and installation are approximate.
*
All kits are for illustration purposes only and are not supplied unless otherwise stated.
Thermostatic mixer shower
5
1
4
6
1
3
2
