Netopia 3341-ENT Firmware User Manual page 230

7-38 Firmware User Guide
Multiple logical IP LAN support allows you to create additional IP routed LAN interfaces (ALANs). You can add,
edit, or delete Additional LANs similarly to Connection Profiles on the WAN connection. You then associate
physical or logical Ethernet-encapsulated interfaces, such as wired Ethernet ports, wireless SSIDs, and ATM
RFC 1483 bridged VCs, to these interfaces on platforms with more than one Ethernet-encapsulated interface.
The additional LAN IP routed interfaces duplicate all the same parameters that apply to the primary LAN
interface, such as DHCP servers, filtersets, multicast forwarding, and RIP. You can configure up to six ALANs.
To configure an ALAN, select Additional LANs from the IP Setup screen and press Return.
The Additional LAN Configuration screen appears.
Additional LAN Configuration
Add ALAN...
Select Add ALAN and press Return.
