- Page 1 MP 700 Series GPS Rugged Wireless Modem Vehicle Installation Guide 2130286 Rev 3.0...
- Page 3 Note: Some airlines may permit the use of cellular phones while the aircraft is on the ground and the door is open. Sierra Wireless modems may be used at this time. The driver or operator of any vehicle should not operate a computer or any other device connected to the Sierra Wireless modem while in control of a vehicle.
- Page 4 D453,733 D459,303 D496,642 D496,655 and other patents pending. Manufactured or sold by Sierra Wireless or its licensees under one or more patents licensed from InterDigital Group. Copyright © 2004 Sierra Wireless. All rights reserved. Trademarks “Heart of the Wireless Machine” is a registered trademarks of...
- Page 5 Other trademarks are the property of the respective owners. Contact Information Sales Desk: Phone: 1-604-232-1488 Hours: 8:00am to 5:00pm Pacific Time e-mail: sales@sierrawireless.com Post: Sierra Wireless 13811 Wireless Way, Richmond, BC Canada V6V 3A4 Fax: 1-604-231-1109 Web: www.sierrawireless.com Your comments and suggestions on improving this documen- tation are welcome and appreciated.
- Page 6 MP 700 Series GPS Vehicle Installation Guide 2130286...
-
Page 7: Table Of Contents
Table of Contents Introducing the MP 700 Series GPS Modem ......11 System Requirements ......... . 12 Supported Platforms . - Page 8 MP 700 Series GPS Vehicle Installation Guide Power Wiring ........... . . 23 The Power Connector .
- Page 9 Contents Canada (Industry Canada Approval) ....... . . 36 U.S.A. (FCC Approval) ..........36 Rev 3.0 Oct.04...
- Page 10 MP 700 Series GPS Vehicle Installation Guide 2130286...
-
Page 11: Introducing The Mp 700 Series Gps Modem
MP 700 Series GPS Modem • Package Contents • Warranty The Sierra Wireless MP 700 Series GPS modem provides a wireless network connection for portable computers installed in vehicles. The modem has a rugged design that withstands the vibration, shock, humidity, and extremes of temperature experienced in the normal operation of police, emergency, utility, and field service vehicles. -
Page 12: System Requirements
MP 700 Series GPS Vehicle Installation Guide System Requirements Supported Platforms The MP 700 Series GPS wireless modem connects to a personal Note: Do not connect the computer with either a serial cable or USB cable. Your MP 700 Series GPS to a USB... -
Page 13: Modem Accessories
<F1> pressing the key. Modem Accessories For information about accessories for the MP 700 Series GPS wireless modem—including cables and antennas—contact your account manager at your reseller or at Sierra Wireless. Warranty Sierra Wireless warrants the MP 700 Series GPS modem against all defects in materials and workmanship for a period of three (3) years from the date of purchase. - Page 14 MP 700 Series GPS Vehicle Installation Guide The sole responsibility of Sierra Wireless under this warranty is limited to either repair or, at the option of Sierra Wireless, replacement of the radio modem. There are no expressed or implied warranties, including those of fitness for a particular purpose or merchantability, which extend beyond the face hereof.
-
Page 15: Installing The Mp 700 Series Gps Modem In A Vehicle
Antenna MP 700 Note: The MP 700 Series GPS Figure 2-1: Basic diagram for the installation of the MP 700 Series GPS in a is designed for negative-ground vehicle equipped with a notebook PC and a combination antenna, using the car battery for power and ignition-sense wiring for power on/off. -
Page 16: Voice, Gps, And I/O Options
4-wire, 2.5 mm headset connector. GPS. If you plan to use the MP 700 Series GPS’s built-in GPS module, you must connect a GPS antenna and an antenna... -
Page 17: Connector Panel
RF antenna (4-wire, 2.5 mm) (female TNC) Figure 2-3: The connector panel of the MP 700 Series GPS modem. Indicator Panel The MP 700 Series GPS’s indicator panel includes four indicator lights and the SIM card slot, which is protected by a... -
Page 18: Reset Button
Figure 2-5: The modem reset button. Required Equipment To install the MP 700 Series GPS, you require the modem, the provided power harness (or existing MP200 Series power harness) and mounting template, and the screws and washers that come with the device. You also require: •... -
Page 19: Mounting The Modem
About This Template Mounting the Modem The MP 700 Series GPS can be mounted in the trunk of the Note: The MP 700 Series GPS vehicle, under the dashboard, or under a front or rear seat. modem, your computer, and any... -
Page 20: Grounding The Modem
Use the supplied mounting screws and washers to secure the MP 700 Series GPS through the holes along the edge of the case bottom. Figure 2-6: The bottom of the MP 700 Series GPS housing. Arrows indicate the mounting holes. Grounding the Modem...
