AirPrime MC7455
Hardware Integration Guide
4118013
Rev 1
Proprietary and Confidential
Contents subject to change

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AirPrime MC7455 and is the answer not in the manual?

Questions and answers

Related Manuals for Sierra Wireless AirPrime MC7455

Summary of Contents for Sierra Wireless AirPrime MC7455

  • Page 1 AirPrime MC7455 Hardware Integration Guide 4118013 Rev 1 Proprietary and Confidential Contents subject to change...
  • Page 3 Notice totally lost. Although significant delays or losses of data are rare when wireless devices such as the Sierra Wireless modem are used in a normal manner with a well-constructed network, the Sierra Wireless modem should not be used in...
  • Page 4 This product may contain technology developed by or for Sierra Wireless Inc. ® This product includes technology licensed from QUALCOMM This product is manufactured or sold by Sierra Wireless Inc. or its affiliates under one or more patents licensed from InterDigital Group and MMP Portfolio Licensing.

  • Page 5: Table Of Contents

    Contents Introduction ........... . .7 Accessories .
  • Page 6 Hardware Integration Guide Proprietary and Confidential - Contents subject to change 4118013...

  • Page 7: Introduction

    1: Introduction The Sierra Wireless MC7455 PCI Express Mini Card is a compact, lightweight, wireless LTE- and UMTS-based modem that provides LTE, UMTS, and GNSS connectivity for M2M applications, notebook, ultrabook and tablet computers over several radio frequency bands. Accessories A hardware development kit is available for AirPrime MC-series modules.
  • Page 8 Hardware Integration Guide Proprietary and Confidential - Contents subject to change 4118013...

  • Page 9: Power

    For detailed pinout and voltage / current requirements of this module, see the AirPrime MC7455 Product Technical Specification. Module Power States The module has five power states, as described in Table 2-1.
  • Page 10 Hardware Integration Guide Table 2-1: Module power states (Continued) State Details •     Sleep Normal state of module between calls or data connections • Module cycles between wake (polling the network) and sleep, at network provider- determined interval. •...

  • Page 11: Rf Specifications

    3: RF Specifications The MC7455 operates on the frequency bands listed below. Table 3-1: LTE Frequency Band Support Band Frequency (Tx) Frequency (Rx) Band 1 1920–1980 MHz 2110–2170 MHz Band 2 1850–1910 MHz 1930–1990 MHz Band 3 1710–1785 1805–1880 MHz Band 4 1710–1755 2110–2155 MHz...

  • Page 12: Rf Connections

    Hardware Integration Guide Table 3-3: GNSS Frequency Band Support Band Frequencies Narrow-band GPS, Galileo Rx: 1575.42 MHz Wide-band GPS + GLONASS Rx: 1560–1606 MHz Narrow-band BeiDou Rx: 1561.098 MHz Narrow-band GLONASS Rx: 1601.72 MHz RF Connections When attaching antennas to the module: •...

  • Page 13: Ground Connection

    RF Specifications • If both UMTS and CDMA modules will be installed in the same platform, you may want to develop separate antennas for maximum performance. Determining the Antenna’s Location When deciding where to put the antennas: • Antenna location may affect RF performance. Although the module is shielded to prevent interference in most applications, the placement of the antenna is still very important —...

  • Page 14: Interference From Other Wireless Devices

    Hardware Integration Guide RF desense can be addressed through a combination of mitigation techniques (Methods to Mitigate Decreased Rx Performance on page 15) and radiated sensitivity measurement (Radiated Sensitivity Measurement on page 15). Note: The MC7455 is based on ZIF (Zero Intermediate Frequency) technologies. When performing EMC (Electromagnetic Compatibility) tests, there are no IF (Intermediate Frequency) components from the module to consider.

  • Page 15: Methods To Mitigate Decreased Rx Performance

    To determine the extent of any receiver performance desensitization due to self- generated noise in the host device, over-the-air (OTA) or radiated testing is required. This testing can be performed by Sierra Wireless or you can use your own OTA test chamber for in-house testing.
  • Page 16 Hardware Integration Guide Proprietary and Confidential - Contents subject to change 4118013...

  • Page 17: Regulatory Compliance And Industry Certifications

    (i.e., have errors) or be totally lost. Although significant delays or losses of data are rare when wireless devices such as the Sierra Wireless module are used in a normal manner with a well- constructed network, the Sierra Wireless module should not be used...

  • Page 18: Safety And Hazards

    Hardware Integration Guide Safety and Hazards Do not operate your MC7455 module: • In areas where blasting is in progress • Where explosive atmospheres may be present including refuelling points, fuel depots, and chemical plants • Near medical equipment, life support equipment, or any equipment which may be susceptible to any form of radio interference.
  • Page 19 Regulatory Compliance and Industry Certifications Table 4-1: Antenna Gain Specifications Device Technology Band Frequency Maximum antenna (MHz) gain (dBi) MC7455 Mini Card 1850–1910 1710–1755 824–849 2500–2570 699–716 777–787 1850–1915 814–849 2305–2315 2496–2690 UMTS 1850–1910 1710–1755 824–849 3. The MC7455 module may transmit simultaneously with other collocated radio transmitters within a host device, provided the following conditions are met: ·...
  • Page 20 Hardware Integration Guide 4. A label must be affixed to the outside of the end product into which the MC7455 module is incorporated, with a statement similar to the following: · This device contains FCC ID: N7NMC7455 Contains transmitter module IC: 2417C-MC7455 where 2417C-MC7455 is the module’s certification number.

  • Page 21: Acronyms

    5: Acronyms Table 5-1: Acronyms and Definitions Acronym or term Definition 3GPP 3rd Generation Partnership Project BeiDou BeiDou Navigation Satellite System A Chinese system that uses a series of satellites in geostationary and middle earth orbits to provide navigational data. Bit Error Rate —...
  • Page 22 Hardware Integration Guide Table 5-1: Acronyms and Definitions (Continued) Acronym or term Definition Hertz = 1 cycle / second Industry Canada Intermediate Frequency Interim Standard. After receiving industry consensus, the TIA forwards the standard to ANSI for approval. Long Term Evolution—a high-performance air interface for cellular mobile communication systems.

  • Page 23: Index

    Index accessories, 7 gain acronyms and definitions, 21– 22 maximum, 18 antenna grounding connection considerations, 12 connection considerations, 13 custom, design, 12 diversity antenna, disabling, 13 limit, matching coaxial connections, 12 location, considerations, 13 impedance matching, considerations, 12 module–antenna, 13 maximum cable loss, 12 industry...
  • Page 24 Hardware Integration Guide antenna cable loss, maximum, 12 antenna connection, considerations, 12 sensitivity connectors, required, 7 radiated measurement, overview, 15 desense shielding device-generated, 14 module, compliance, 12 harmonic energy, filtering, 15 reducing RF desense, 15 mitigation suggestions, 15 shielding suggestions, 15 connector, required, 7 interference...
