- Page 1 Built-in Oven OV608MS Installation and Operating Manual...
-
Page 2: Table Of Contents
CONTENTS Important Notes -------------------------------------------------------------------------------------------------------------------Page 2 Technical Specification ------------------------------------------------------------------------------------------------------------Page 2 Installation Instructions ----------------------------------------------------------------------------------------------------------Page 3 About the Oven --------------------------------------------------------------------------------------------------------------------Page 5 Oven Timer / Clock ----------------------------------------------------------------------------------------------------------------Page 6 Setting Local Time -----------------------------------------------------------------------------------------------------------------Page 6 Manual Mode -----------------------------------------------------------------------------------------------------------------------Page 6 Program Cooking -------------------------------------------------------------------------------------------------------------------Page 6 Oven Cooking Function -----------------------------------------------------------------------------------------------------------Page 8 Cooking Time ----------------------------------------------------------------------------------------------------------------------Page 10 Cleaning and Maintenance ----------------------------------------------------------------------------------------------------Page 11 Warnings ---------------------------------------------------------------------------------------------------------------------------Page 13... -
Page 3: Important Notes
REGULATIONS. INSTALLATION IS TO BE DONE ONLY BY AN AUTHORISED ELECTRICIAN. WARNING! THIS APPLIANCE MUST BE EARTHED. IMPORTANT! AN ISOLATION SWITCH COMPLETE WITH A 15A PLUG SOCKET MUST BE INCORPORATED IN THE FIXED WIRING. Technical Specifications Product : OV608MS Voltage : (220 – 240) Vac Frequency : 50Hz Maximum Power... -
Page 4: Installation Instructions
Before connecting to the mains, make sure that: The electric meter, safety valve, feeding line and socket are adequate to withstand the maximum load required (refer to product data label for maximum load). The supply system earth tested to ensure its working properly. ... - Page 5 Secure the appliance to the cabinet frame using the screws provided. Insert it together with the plastic washers into the 2 holes that can be seen in the frame of the oven when the door is open and cap it with the silicone washes.
-
Page 6: About The Oven
About The Oven The OV608MS oven offers extra large capacity of 70L and 8 cooking functions. User can do cooking on up to 5 shelves at a time or cook in large quantity which the traditional ovens do not allow. -
Page 7: Oven Timer/Clock
Oven Timer/Clock Cooking In Progress Time Setting Indicator Alarm Auto Decrease Increase Function Selection To set the local time When the electrical power supply is first switched on, the digital display automatically show "12.30", a beep will sound once and "12" on the display will flash continuously. Set the local time before using the oven. - Page 8 At the same time, the symbols " A " " " lights up on the timer, timer begins to display local time and the oven starts cooking. " A " At the end of the cooking duration, the symbol on the timer starts flashing, the oven gives out an audible signal and the oven turns off automatically.
-
Page 9: Oven Cooking Function
When the set time has elapsed the oven gives out an audible signal. The signal will continue sounding for 1 minute. Press any button less than 3 seconds to stop it. Additional notes on the Oven Timer / Clock When setting time functions, keep pressing down on the "+"... - Page 10 Top + Bottom Heating Element + Fan – Provides even heating with the top and bottom element and the fan operating simultaneously. Food will be browned on top and heated from the bottom. Bottom Heating – Bottom heating element operates. It is perfect for baking pies and pizzas with crispy bases.
-
Page 11: Cooking Time
Cooking Time The table shows some examples for the adjustment of the thermostat and of the cooking time. *The cooking times can vary according to the type of food, its homogeneity and volume. *For the beef, veal, pork and turkey roasts, with bones or rolled, add about 20 minutes to the times shown in the table. -
Page 12: Cleaning And Maintenance
Cleaning and Maintenance CAUTION! PRIOR TO CLEANING OR MAINTAINANCE, ALWAYS DISCONNECT THE POWER SUPPLY. IMPORTANT! REGULARLY CHECK THE CONDITION OF THE SILICONE DOOR SEAL. CLEAN IF NECESSARY AND AVOID USING ABBRASIVE CLEANERS. SHOULD IT BE DAMAGED CONTACT THE AFTER SALES SERVICE CENTRE. 1) CLEANING OF STAINLESS STEEL In order to have your oven retains its new appearance;... - Page 13 • free the outer glass sheet from the door (Image B). You can now see the second glass sheet (Model OV608MS). Look for two black rubber clips located at the • top (Image C) and lift the slit in the rubber brackets to free and remove the second glass sheet (Image D).
-
Page 14: Warnings
WARNING! DO NOT USE HARSH OR ABRASIVE CLEARNERS, SHARP OBJECTS AND METAL SCRAPERS TO CLEAN THE OVEN DOOR GLASS AS THEY CAN SCRATCH THE SURFACE AND MAY RESULT IN THE GLASS SHATTERING. WARNING! DO NOT USE STEAM CLEANERS. 7) REPLACING THE OVEN BULB Once the oven has been electrically disconnected, unscrew the glass cover and pull out the halogen bulb. -
Page 15: Environment Care
FURTHER ADVICE The oven function and temperature knobs can be pushed in to prevent from accidentally being turned. To protect the surrounding furniture cabinets, after cooking is completed, the cooling fan may stay on until the oven has cooled down sufficiently. If you have had the oven on for hours at a time, this fan might stay on for up to 60 minutes after you turn off the oven.
