- Page 1 Operating Instructions (Original instructions) Microwave Oven Household Use Only N N-SM33NW Model No. NN-ST34NB NN-SM33NW NN-ST34NB...
-
Page 3: Table Of Contents
Questions and answers ..........28 Care of your oven ............29 Specifications ............... 30 Thank you for purchasing a Panasonic appliance. Important Safety Instructions: Before operating this oven, please read these instructions and precautions carefully and keep for future reference. -
Page 4: Important Safety Instructions
(including OVEN REQUIRES children) with reduced physical, SERVICING, call your local sensory or mental capabilities, Panasonic engineer (Customer or lack of experience and Support). It is hazardous for knowledge unless they have anyone other than a competent... - Page 5 Operation Voltage 8. When the oven is not being used, do not store any objects The voltage has to be the same as other than oven accessories specified on the label on the oven. If a inside the oven in case it is higher voltage than specified is used, accidentally turned on.
- Page 6 Important safety instructions 4. Do not place this oven near an If you accidentally remove the electric or gas cooker range. roller ring, place the roller ring gently into the hole in the centre 5. The feet should not be of the oven and locate it on the removed.
- Page 7 Short cooking time Foods low in moisture As microwave cooking time is Take care when heating foods low much shorter than other cooking in moisture, e.g. bread items, methods, it is essential that chocolate, popcorn, biscuits and recommended cooking time is not pastries.
- Page 8 Important safety instructions Lids Liquids Always remove the lids of jars and Microwave heating of beverages containers and takeaway food can result in delayed eruptive containers before you microwave boiling, therefore care should be the food. If the lid remains, then taken when handling the container.
-
Page 9: General Guidelines
General guidelines STANDING TIME MOISTURE CONTENT Dense foods e.g. meat, jacket potatoes Many fresh foods e.g. vegetables and and cakes, require standing time fruit, vary in their moisture content (inside or outside of the oven) after throughout the season. For this reason cooking, to allow heat to finish cooking time may have to be adjusted. - Page 10 General guidelines CLING FILM ARRANGING Cling film helps keep the food moist Individual foods e.g. chicken portions and the trapped steam assists in or chops, should be placed on a dish speeding up cooking time. Pierce so that the thicker parts are towards before cooking to allow excess steam the outside.
-
Page 11: Containers To Use
Containers to use Choosing the correct container is a very important factor in deciding the success or failure of your cooking. OVEN GLASS Glass that is heat resistant e.g. Pyrex , is ideal, and can be ® used. Do not use glass which may crack due to the heat from the food. - Page 12 Containers to use PLASTIC Many plastic containers are designed for microwave use. Only use containers if they are designed for microwave use. Do not use Melamine as it will scorch. Do not use plastic for cooking foods high in sugar or fat or foods that require long cooking time e.g.
-
Page 13: Parts Of Your Oven
7. Power supply cord and there is no risk of microwave 8. Plug 9. Glass tray exposure. For NN-SM33NW, cooking resumes as soon as the 10. Roller ring door is closed. For NN-ST34NB, 11. Menu label (NN-ST34NB only) cooking resumes after the door is closed and Start/Set is pressed. -
Page 14: Nn-Sm33Nw
NN-SM33NW Control panel 1 Cooking mode select dial 2 Defrost power 3 Microwave power 4 Time/weight select dial • Your control panel may have differences in appearance, but the words on the pads and functionality will be the same. -
Page 15: Microwave Cooking And Defrosting
NN-SM33NW Microwave cooking and defrosting The glass tray must always be in position when using the oven. Turn the dial to select Turn the dial to set the cooking time for the desired power level. microwave cooking, or to set the weight of food for defrosting. -
Page 16: Nn-St34Nb
NN-ST34NB Control panel 1 Display window 2 Micro Power pad 3 Auto Defrost pad 4 Auto Menu pad 5 Time pads 6 Timer/Clock pad 7 Quick 30 pad 8 Up/Down pads 9 Stop/Reset pad Before Cooking One press clears your instructions. During Cooking One press temporarily stops the cooking process. -
Page 17: Setting The Clock
NN-ST34NB Setting the clock When the oven is plugged in for the first time, “88.88” appears in display. Press Timer/Clock Press Up/Down Press Start/Set. Press Up/Down twice. to set hours. to set minutes. A colon starts to blink. Press Start/Set. The colon stops blinking. -
Page 18: Microwave Cooking And Defrosting
NN-ST34NB Microwave cooking and defrosting The glass tray must always be in position when using the oven. Press Micro Power Set the cooking time. Press Start/Set. to select the desired Refer to “Setting the cook The time counts down power level. time/timer time”... - Page 19 „ Setting the cook time/timer time When you set the cook time or the timer time, use following keys according to your needs. Press each Time pad repeatedly according Press Quick 30 to set cooking time to the time value you want to set. in 30 seconds increments.
-
Page 20: Multi-Stage Cooking
NN-ST34NB Multi-stage cooking This feature allows you to programme up to 3 stages of cooking continuously. Example: To continually set High power for 2 minutes, Medium power for 3 minutes and Low power for 2 minutes. Press twice. Press Micro Set the cooking time*. -
Page 21: Quick 30 Feature
NN-ST34NB Quick 30 feature This feature allows you to set cooking time in 30 seconds increments up to 5 minutes at High power. Press Quick 30 until Press Start/Set. the desired cooking The time counts time appears in the down in the display. -
Page 22: Using The Timer
NN-ST34NB Using the timer This feature operates as a KITCHEN TIMER or allows you to programme the STANDING TIME/DELAY START. Kitchen timer Example: To count 5 minutes. Press 5 times. Press Timer/ Set the desired time*. Press Start/Set. Clock. (up to 99 minutes 50 seconds) The time counts down without the oven operating. - Page 23 Delay start Example: To start cooking at Medium power for 3 minutes after 5 minutes of standing time. Press 5 times. Press Timer/ Set the desired delay time*. Clock. (up to 99 minutes 50 seconds) Press 3 times. Press Micro Power Set the desired cooking Press Start/Set.
-
Page 24: Auto Programmes
NN-ST34NB Auto programmes With this feature you can defrost/reheat/cook food according to the weight. Select the category and set the weight of the food. The weight is programmed in kilograms for AUTO DEFROST and in grams for AUTO MENU. The oven determines MICROWAVE power level and cooking time automatically. -
Page 25: Auto Menu
6. Shielding prevents food from cooking. It is essential when defrosting chicken and joints of meat. The outside thaws out first, so protect wings/breast and fat with smooth pieces of aluminium foil secured with cocktail sticks. 7. Allow standing time so that the centre of the food thaws out (minimum of 1 hour for joints of meat and whole chicken). - Page 26 NN-ST34NB Auto programmes Programme Instructions Serving: 1 serv./2 serv. (250 g/serving) For reheating a pre-cooked fried rice. It must be pre-cooked. Fried rice should be at room temperature or refrigerator temperature approx. +5 °C. 2. Reheat Fried Rice Reheat in container as purchased. Covering film with a sharp knife once in the centre and 4 times around the edge.
- Page 27 Programme Instructions Weight: 100/200/300/400 g For cooking all types of leaf, green and soft varieties, including broccoli, squash, cauliflower, cabbage, asparagus, beans, celery, zucchini, spinach, capsicum or a mixture of 6. Vegetables these. Cut all vegetables into the same size pieces. Place vegetables in a suitable size microwave safe casserole.
- Page 28 NN-ST34NB Auto programmes Programme Instructions Weight: 200/400/600/800 g For cooking chicken pieces such as wings, drumsticks, thighs, half breasts etc. Pierce the chicken pieces well with 9. Chicken fork before cooking. Place prepared chicken pieces in a suitable size microwave safe dish. Add 1-5 tbsp oil if desired.
-
Page 29: Cooking And Reheating Guidelines
Cooking and reheating guidelines Most foods reheat very quickly in your oven by HIGH power. Meals can be brought back to serving temperature in just minutes. Always check food is piping hot and return to oven if necessary. As a general rule, always cover wet foods, e.g. soups, casseroles and plated meals. Do not cover dry foods e.g. -
Page 30: Questions And Answers
Questions and answers Q: Why won’t my oven turn on? Q: Can I use a conventional oven A: When the oven does not turn on, thermometer in the oven? check the following: A: The metal in some thermometers 1. Is the oven plugged in securely? may cause arcing in your oven and Remove the plug from the outlet, should not be used in a microwave... -
Page 31: Care Of Your Oven
Care of your oven 7. It is occasionally necessary to 1. The oven should be unplugged before cleaning. remove the glass tray for cleaning. Wash the tray in warm soapy water 2. Clean the inside of the oven, door or in a dishwasher. seals and door seal areas regularly. -
Page 32: Specifications
Specifications Power Source 220 V 60 Hz 230-240 V 50 Hz Power Consumption 5.9 A 1330 W 5.5 A 1330 W Output 900 W (IEC-60705) Outside Dimensions 469 (W) × 380 (D) × 280 (H) mm Oven Cavity Dimensions 329 (W) × 326 (D) × 236 (H) mm Overall Cavity Volume 25 L Glass Tray Diameter... - Page 34 Importer: Panasonic Marketing Middle East & Africa FZE Jebel Ali Dubai United Arab Emirates Panasonic Corporation 1006 Kadoma Osaka Japan Website: https://www.panasonic.com F0422-0 © Panasonic Corporation 2022 Printed in P.R.C.
