Item # *******
Model # SK16944
USE AND CARE GUIDE
**********
Questions, problems, missing parts? Before returning to the store,
call Home Decorators Collection Customer Service.
8 a.m. – 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday
1-800-986-3460
HOMEDEPOT.COM/HOMEDECORATORS
THANK YOU
We appreciate the trust and confidence you have placed in Home Decorators Collection through the purchase of this **********. We strive to
continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home
improvement needs. Thank you for choosing Home Decorators Collection!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SK16944 and is the answer not in the manual?

Questions and answers

Related Manuals for Home Decorators Collection SK16944

Summary of Contents for Home Decorators Collection SK16944

  • Page 1 THANK YOU We appreciate the trust and confidence you have placed in Home Decorators Collection through the purchase of this **********. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home...

  • Page 2: Table Of Contents

    Table of Contents     Table of Contents ............2 Pre-assembly (continued) ..........4   Safety Information ............2 Package Contents ..............4   Warranty ................. 2   Assembly Note .................5   3 Year Warranty ...............2   Touble Shooting ...............5   What is Covered ...............2  ...

  • Page 3: Pre-Assembly

    Pre-assembly PLANNING ASSEMBLY Keep children and pets away from build area. Make sure your area is large enough to unpack, sort and assemble the unit. TOOLS REQUIRED Large head Small head Phillips Phillips screwdriver screwdriver HARDWARE INCLUDED NOTE: Hardware not shown to actual size. Part Description Quantity...

  • Page 4: Pre-Assembly (Continued)

    Pre-assembly (continued) PACKAGE CONTENTS Part Description Quantity Part Description Quantity Hutch top panel Base left side panel Hutch left side panel Base right side panel Hutch right side panel Drawer front panel Hutch adjustable shelf Drawer left side panel Buffet top panel Drawer right side panel Hutch left door Drawer back panel...

  • Page 5: Assembly Note

    Pre-assembly (continued) ASSEMBLY NOTE Upon opening, thoroughly clean all wood surfaces to remove dust and dirt that may have settled onto the finish during shipment. In order to prevent damage during assembly, Please assemble this item with at least two people. NOTE: Turn the cam-bolt screws until they are tight, the shoulder should be against the surface of the part.

  • Page 6: Assembly

    Assembly Attaching the base partition to the base fixed panel □ a) Join partition (H) to panel (I) with dowel (AA). □ b) Tighten panel (I) with screw (EE).
  • Page 7 Assembly (continued) Attaching the base right side panel □ □ a) Install bolt (BB) into panel (M). c) Join panels (I) and (K) to the panel (M) with dowel (AA). □ □ b) Insert lock (CC) into panels (I) and (K). d) Tighten bolt (BB) with lock (CC) in the pre-drilled holes.
  • Page 8 Assembly (continued) Attaching the base left side panel □ □ a) Install bolt (BB) into panel (L). c) Join panel (L) to the assembled body with dowel (AA). □ □ b) Insert lock (CC) into panels (I) and (K). d) Tighten bolt (BB) with lock (CC) in the pre-drilled holes.
  • Page 9 Assembly (continued) Attaching the base top panel □ □ a) Install bolt (BB) into panel (E). c) Join panel (E) to the assembled body with dowel (AA). □ d) Tighten bolt (BB) with lock (CC) in the pre-drilled holes. □ b) Insert dowel (AA) and lock (CC) into panels (L), (M) and partition (H).
  • Page 10 Assembly (continued) Attaching the hutch side panel to the hutch top panel □ □ a) Install bolt (BB) into panel (A). c) Join panel (A) to the panels (B) and (C) with dowel (AA). □ □ b) Insert lock (CC) into panels (B) and (C). d) Tighten bolt (BB) with lock (CC) in the pre-drilled holes.
  • Page 11 Assembly (continued) Attaching the hutch □ □ a) Install dowel (AA) and bolt (BB) into panel (E). c) Join panels (B) and (C) to the assembled body with dowel (AA). □ d) Tighten bolt (BB) with lock (CC) in the pre-drilled holes. □...
  • Page 12 Assembly (continued) Attaching the magnet □ Attach magnet (GG) to panel (E) with screw (LL) as shown.
  • Page 13 Assembly (continued) Attaching the back panel □ a) Install wire plug (KK) into panel (S) as shown. □ b) Tighten panels (S) and (T) to the assembled body with screws (LL) as shown. HOMEDEPOT.COM/HOMEDECORATORS Please contact 1-800-986-3460 for further assistance.
  • Page 14 Assembly (continued) Assembling the hutch shelf □ Slide panel (U) into the grooves on panels (B) and (C). NOTE: The panel (U) you can choose to install, can also choose not to install.
  • Page 15 Assembly (continued) Assembling the base adjustable shelf □ Insert shelf supports (JJ) in desired positions and place shelves (D) and (J) on the support. HOMEDEPOT.COM/HOMEDECORATORS Please contact 1-800-986-3460 for further assistance.
  • Page 16 Assembly (continued) Attaching the door □ a) Attach left door (F) and right door (G) to the assembled body with screw (MM) as shown. NOTE: Metal plate needs to be to the bottom □ b) Attach handle (HH) to door (F) and door (G) with the bolt (II). NOTE: A helper who can hold the door in position makes the door installation easier.
  • Page 17 Assembly (continued) Assembling the drawer □ □ a) Install dowel (AA) and bolt (BB) into panel (N). d) Tighten bolt (BB) with lock (CC) in the pre-drilled holes. Slide panel (R) into the grooves on panels (O) and (P). □ b) Insert lock (CC) into panels (O) and (P).
  • Page 18 Assembly (continued) Inserting the drawer □ Insert the drawer into the assembled body as shown. NOTE: Make sure the slide piece is at the front end of the glide when installing the drawer into the body. NOTE: When removing the drawer, tip-up the safety release tab to remove the drawer from the body.
  • Page 19 Assembly (continued) Finalizing the assembly □ Install the anti-tipping hardware as shown. HOMEDEPOT.COM/HOMEDECORATORS Please contact 1-800-986-3460 for further assistance.
  • Page 20 Questions, problems, missing parts? Before returning to the store, call Home Decorators Collection Customer Service. 8 a.m. – 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday 1-800-986-3460 HOMEDEPOT.COM/HOMEDECORATORS Retain this manual for future use.
