Delixi NAVIGATOR Series User Manual
Switching capacitor contactors
Hide thumbs
Also See for NAVIGATOR Series:
- User manual (16 pages) ,
- User manual (12 pages) ,
- User manual (11 pages)
Subscribe to Our Youtube Channel
Related Manuals for Delixi NAVIGATOR Series
Summary of Contents for Delixi NAVIGATOR Series
- Page 1 CDC19s Series NAVIGATOR Switching capacitor contactors Series User Manual Please carefully read this User Manual before installing and operating the product, and keep this manual properly for future reference...
- Page 2 CDC19s Series Switching Capacitor Contactor Safety Notice Please carefully read this instruction before the installation, operation, run, maintenance, and inspection, and follow the contents of the instruction to properly install and operate this product. Danger: ● Do not operate the contactor with your wet hands; ●...
- Page 3 About CDC19s Series Product ● Panel Introduction Remove this label before installing accessories The installation dimensions are same with those of CDC9 Fig. 1 Product Diagram Legends: 1 - Main circuit outlet terminal 2/T1, 4/T2, 6/T32 2 - Product model 3 - Main circuit inlet terminal 1/L1, 3/L2, 5/L3 5 –...
- Page 4 8 – Normally-closed auxiliary inlet terminal 31NC 9 – Pre-charged contact set 10 - Normally-open auxiliary outlet terminal 32NC 11 - Normally-open auxiliary outlet terminal 14NO 12 – Normally-closed auxiliary outlet terminal NC 22 13 – Coil outlet terminal A2 15 –...
- Page 5 Normal Operation, Installation, and Transport Conditions ● Normal Operation and Installation Conditions (1) The ambient air temperature is not higher than +40℃, and is not below -5℃; the average value within 24 hours does not exceed +35℃; (2) The altitude of the installation site does not exceed 2000m; (3) The relative humidity of the atmosphere does not exceed 50% at the maximum ambient temperature of +40℃, and a higher relative humidity is allowed lower temperatures, such as 90% at +20℃.
- Page 9 Table 3 Outline and installation dimensions Unit: mm Outline dimensions Installation dimensions Model Amax Bmax Cmax Dmax Emax Fmax Debugging and Operation ● Check whether the technical parameters of product comply with the operation requirements; ● Please separate the resistance wires between the phases after installation; ●...
-
Page 10: Maintenance And Service
●The recommended sectional area and tightening torque of the wire of the terminal block are listed in Table 5. Table 5 Recommended sectional area and tightening torque of the wire of the terminal block Product model CDC19s- CDC19s- CDC19s CDC19s- CDC19s- 32/43 95/115... - Page 11 Table 6 Common fault analysis and solution Fault Cause Solution The iron core cannot 1. The power supply voltage is too low or be pulled in or the fluctuates too much; 1. Incease the power voltage; suciton force 2. The power capacity of the operating circuit is 2.
- Page 12 Inspector: Check 06 DELIXI ELECTRIC LTD Production date: See label on inner box DELIXI ELECTRIC LTD Address: Delixi High-Tech Industrial Park, Liushi Town, Leqing City, Zhejiang P/C: 325604 Tel: (86-577) 6177 8888 Fax: (86-577) 6177 8000 Customer Service hotline: 400-826-8008 www.delixi-electric.com...
