Parameters
IP Address
Port
User Name
Password
3) Click OK.
Step 3 Click Start Cluster.
For a cluster of only 2 devices, you must set the arbitration IP address. For details. See
"8.9.1.3 Configuring Arbitration IP".
Step 4 Set cluster IP address.
Cluster IP is a virtual IP that is used to access and manage the main devices and sub devices
in the cluster. After logging in with the virtual IP, when the main device fails and the
system is switched to the sub device, you can still view live video.
1) Click Cluster Setting.
2) Select the Enable checkbox, and then set the other parameters as required.
3) Click OK.

8.9.1.2 Viewing Details

Click that corresponds to a main or sub device to view device event logs including event time,
name and details.
Description
Enter the IP address of the main device or sub device.
When adding the first sub device, you need not enter the IP
address, because the first sub device is the current device by
default.
37777 by default.
Username and password of the device, which are also used to log
in to the web interface or PCAPP.
Figure 8-122 Set cluster IP
321
User's Manual
