Page 1 DIGITAL VIDEO RECORDER User’s Manual V1.3.0...
Page 2: Cybersecurity Recommendations
Cybersecurity Recommendations Mandatory actions to be taken towards cybersecurity 1. Change Passwords and Use Strong Passwords: The number one reason systems get “hacked” is due to having weak or default passwords. It is recommended to change default passwords immediately and choose a strong password whenever possible.
Page 3 In the event that your social media, bank, email, etc. account is compromised, you would not want someone collecting those passwords and trying them out on your video surveillance system. Using a different username and password for your security system will make it more difficult for someone to guess their way into your system.
Page 4: Regulatory Information
Regulatory Information The regulatory information herein might vary according to the model you purchased. Some information is only applicable for the country or region where the product is sold. FCC Information CAUTION Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
Page 5: Foreword
Foreword General This user’s manual (hereinafter referred to be "the Manual") introduces the functions and operations of the DVR devices (hereinafter referred to be "the Device"). Models Series Models XVR Cooper DH-XVR1B04/DH-XVR1B04H/DH-XVR1B08/DH-XVR1B08H/DH-XVR1B16/D series H-XVR1B16H DH-XVR4104C-X/DH-XVR4108C-X/DH-XVR4116HS-X/DH-XVR4104HS-X/ XVR4 series DH-XVR4108HS-X/DH-XVR4104HS-X1/DH-XVR4108HS-X1/DH-XVR4104C- X1/DH-XVR4108C-X1/DH-XVR4216AN-X/DH-XVR4232AN-X DH-XVR5108C-X/DH-XVR5104C-4KL-X/DH-XVR5104C-X/DH-XVR5108H-X/ DH-XVR5116H-X/DH-XVR5104H-4KL-X/DH-XVR5108H-4KL-X/ DH-XVR5116H-4KL-X/DH-XVR5108HE-X/DH-XVR5116HE-X/ DH-XVR5108HS-X/DH-XVR5116HS-X/DH-XVR5104HS-4KL-X/...
Page 6 Signal Words Meaning Indicates a potential risk which, if not avoided, could result in property damage, data loss, lower performance, or unpredictable result. Provides methods to help you solve a problem or save you time. Provides additional information as the emphasis and supplement to the text.
Page 7 Version Revision Content Release Time V1.0.0 First Release. February 27, 2018 V1.0.1 Add eight models. March 27, 2018 1. Add four models. 2. Add following sections:  Regulatory Information  Privacy Protection Notice  Using Reset Button on the Mainboard ...
Page 8 Version Revision Content Release Time Update safety baseline functions. 1. Matching language automatically during initialization; changing GMT time zone to UTC time zone; matching PAL and NTSC automatically; 2. Password on the local login interface is displayed with plaintext; 3. Reboot is not required after service port number is changed;...
Page 9  There still might be deviation in technical data, functions and operations description, or errors in print. If there is any doubt or dispute, please refer to our final explanation.  Upgrade the reader software or try other mainstream reader software if the Manual (in PDF format) cannot be opened.
Page 10: Important Safeguards And Warnings
Important Safeguards and Warnings This Chapter describes the contents covering proper handling of the Device, hazard prevention, and prevention of property damage. Read these contents carefully before using the Device, comply with them when using, and keep it well for future reference. Operation Requirement ...
Page 11: Table Of Contents
Table of Contents Cybersecurity Recommendations ......................I Regulatory Information ........................... III Foreword ..............................IV Important Safeguards and Warnings ....................IX 1 Introduction ............................1 1.1 Overview ............................1 1.2 Functions ............................1 2 Getting Started ............................3 2.1 Checking the Components......................3 2.2 Installing HDD ..........................
Page 12 3.1.3 DH-XVR5108H-X/DH-XVR5116H-X/DH-XVR5104H-4KL-X/DH-XVR5108H-4KL-X/DH-XVR511 6H-4KL-X/DH-XVR5108HE-X/DH-XVR5116HE-X/DH-XVR4116HS-X/DH-XVR5108HS-X/DH-X VR5116HS-X/DH-XVR5104HS-4KL-X/DH-XVR5108HS-4KL-X/ DH-XVR5104HS-X/DH-XVR4104HS-X/DH-XVR4108HS-X/DH-XVR5104H-X/DH-XVR5104HE -X/DH-XVR5108H-4KL-X-8P/ DH-XVR5104HS-X1/DH-XVR4104HS-X1/DH-XVR4108HS-X1/ DH-XVR5104H-X1/DH-XVR5104HE-X1 ................... 12 3.1.4 DH-XVR7104HE-4KL-X/DH-XVR7108HE-4KL-X/DH-XVR7116HE-4KL-X/DH-XVR7108HE-4K- X ..............................12 3.1.5 DH-XVR4216AN-X/DH-XVR4232AN-X/DH-XVR5216AN-X/DH-XVR5232AN-X/DH-XVR5208A N-4KL-X/DH-XVR5216AN-4KL-X/DH-XVR5216A-X/DH-XVR5208AN-4KL-X-8P/DH-XVR5216 AN-4KL-X-16P ........................... 13 3.1.6 DH-XVR7208A-4KL-X/DH-XVR7216A-4KL-X/DH-XVR7208A-4K-X ....... 13 3.1.7 DH-XVR7416L-4KL-X ....................... 14 3.1.8 DH-XVR7816S-4KL-X/DH-XVR7816S-4KL-X-LP ............14 3.1.9 DH-XVR5432L-X/DH-XVR5408L-X/DH-XVR5416L-X ............. 15 3.1.10 DH-XVR5832S-X/DH-XVR5808S-X/DH-XVR5816S-X ..........15 3.1.11 DH-XVR1B04/DH-XVR1B04H/DH-XVR1B08/DH-XVR1B08H/DH-XVR1B16/DH-XVR1B16H 16 3.2 Rear Panel ..........................
Page 13 3.2.13 DH-XVR1B08H/DH-XVR1B16/DH-XVR1B16H ............. 32 3.3 Remote Control Operations ......................33 3.4 Mouse Operations ........................34 4 Connecting Basics ..........................36 4.1 Typical Connection Diagram ....................... 36 4.2 Connecting to Video and Audio Input and Output ..............38 4.2.1 Video Input ........................38 4.2.2 Video Output ........................
Page 14 5.7 Configuring Record Settings ..................... 128 5.7.1 Enabling Record Control ....................129 5.7.2 Configuring Recorded Video Storage Schedule ............130 5.8 Configuring Snapshot Settings ....................130 5.8.1 Configuring Snapshot Trigger ..................130 5.8.2 Configuring Snapshot Storage Schedule ............... 134 5.8.3 Backing up Snapshots to FTP ..................134 5.9 Playing Back Video ........................
Page 15 5.18 Storage Management ......................268 5.18.1 Configuring Basic Settings ................... 268 5.18.2 Configuring the Recording and Snapshot Schedule ............ 269 5.18.3 Configuring HDD Manager ................... 269 5.18.4 Configuring Record ....................... 270 5.18.5 Configuring Advance Settings ..................270 5.18.6 Configuring Quota......................272 5.18.7 Configuring HDD Detecting Settings ................
Page 16 Appendix 7 Earthing ..........................334 Appendix 7.1 What Is the Surge ..................... 334 Appendix 7.2 The Earthing Modes ....................335 Appendix 7.3 Thunder Proof Ground Method in the Monitor System ..........336 Appendix 7.4 The Shortcut Way to Check the Electric System by Digital Multimeter ....337 Appendix 8 RJ45-RS-232 Connection Cable Definition ..............
Page 17: Introduction
Introduction Overview The Device is an excellent digital monitor product for security industry. The embedded LINUX OS assures the stable operation. The H.265 and G.711 technologies assure the high quality image and low bit stream. The frame-by-frame play function displays more details for analysis, and provides the functions such as record, playback, and monitor and assures the synchronization for audio and video.
Page 18 Integrate coaxial cameras with diverse array of sensors such as temperature, humidity and wireless alarm devices. Storage Management  Special data format to guarantee data security and avoid the risk of modifying data viciously.  Support digital watermark. Compression Format Support multiple-channel audio and video signal.
Page 19: Getting Started
Getting Started Checking the Components The actual appearance, component, or quantity might be different depending on the model you purchased. When you receive the Device, please check against the following checking list. If any of the items are missing or damaged, contact the local retailer or after-sales engineer immediately. Sequence Checking items Requirement...
Page 20: Dh-Xvr5108C-X/Dh-Xvr5104C-4Kl-X/Dh-Xvr5104C-X
2.2.1 DH-XVR5108C-X/DH-XVR5104C-4KL-X/DH-XVR5104C-X/ DH-XVR4104C-X/DH-XVR4108C-X/DH-XVR5104C-X1/ DH-XVR4104C-X1/DH-XVR4108C-X1 1. Remove the screws to take 2. Fix the screws on the HDD 3. Match the screws with off the cover. but do not fasten them. the holes on the DVR to place the HDD. 4. Turn the DVR upside down 5.
Page 21: Dh-Xvr7108E-4Kl-B-X
2.2.2 DH-XVR7104E-4KL-X/DH-XVR7108E-4KL-X/DH-XVR7104E- 4KL-B-X/ DH-XVR7108E-4KL-B-X 2.2.2.1 Installing Battery The battery is only provided with some models. 1. Pull the battery cable through the hole. 2. Connect to the cable into the port. 2.2.2.2 Installing HDD Skip step 6 if the battery is not equipped with the model you purchased. 1.
Page 22: X1/Dh-Xvr4104Hs-X1/ Dh-Xvr4108Hs-X1/Dh-Xvr5104H-X1/Dh-Xvr5104He-X1
7. Use the HDD cable and 8. Install the bracket back and 9. Put back the cover and power cable to connect then fasten the screws. fasten the screws. HDD and mainboard. 2.2.3 DH-XVR4116HS-X/DH-XVR5108HS-X/DH-XVR5116HS-X/DH -XVR5104HS-4KL-X/DH-XVR5108HS-4KL-X/ DH-XVR5108H-X/DH-XVR5116H-X/DH-XVR5104H-4KL-X/DH-XVR 5108H-4KL-X/DH-XVR5116H-4KL-X/DH-XVR5108HE-X/DH-XVR51 16HE-X/DH-XVR7104HE-4KL-X/DH-XVR7108HE-4KL-X/DH-XVR7 116HE-4KL-X/DH-XVR7108HE-4K-X/DH-XVR5104HS-X/ DH-XVR4104HS-X/DH-XVR5104H-X/DH-XVR5104HE-X/DH-XVR4 108HS-X/DH-XVR5104HS-X1/DH-XVR4104HS-X1/ DH-XVR4108HS-X1/DH-XVR5104H-X1/DH-XVR5104HE-X1 1.
Page 23: An-4Kl-X-16P
screws of the HDD with the HDD and mainboard. holes on the back of the device, and then fix the screws. 2.2.4 DH-XVR4216AN-X/DH-XVR4232AN-X/DH-XVR5216AN-X/D H-XVR5232AN-X/DH-XVR5208AN-4KL-X/DH-XVR5216AN-4KL-X/ DH-XVR5216A-X/DH-XVR7208A-4KL-X/DH-XVR7216A-4KL-X/DH- XVR7208A-4K-X/DH-XVR5108H-4KL-X-8P/DH-XVR5208AN-4KL-X -8P/DH-XVR5216AN-4KL-X-16P 1. Remove the screws on 2. Fix the screws onto the 3. Put the HDD into the the cover.
Page 24: Dh-Xvr7416L-4Kl-X/Dh-Xvr5432L-X
2.2.5 DH-XVR7416L-4KL-X/DH-XVR5432L-X 1. Remove the screws on 2. Use the screws to fix the 3. Connect one end of HDD cover. HDD onto the bracket. cable to the HDD. 4. Connect the other end of 5. Use the power cable to 6.
Page 25: Dh-Xvr1B04/Dh-Xvr1B04H/Dh-Xvr1B08/Dh-Xvr1B08H
mainboard. mainboard. 2.2.7 DH-XVR1B04/DH-XVR1B04H/DH-XVR1B08/DH-XVR1B08H/ DH-XVR1B16/DH-XVR1B16H 1. Remove the screws on 2. Connect the HDD cable 3. Align the screws of the the cover. and power cable to HDD, HDD with the holes on and fasten the screws in the back of the device. HDD.
Page 26: The Grand Tour
The Grand Tour This chapter introduces various components of the Device, remote control and mouse operations. Front Panel 3.1.1 DH-XVR5108C-X/DH-XVR5104C-4KL-X/DH-XVR5104C-X/ DH-XVR4104C-X/DH-XVR4108C-X/DH-XVR5104C-X1/ DH-XVR4104C-X1/DH-XVR4108C-X1 Figure 3-1 Icon Name Function The indicator is off when the HDD is running normally.  HDD status indicator The indicator glows blue when the HDD is in ...
Page 27: Dh-Xvr7108E-4Kl-B-X
3.1.2 DH-XVR7104E-4KL-X/DH-XVR7108E-4KL-X/DH-XVR7104E- 4KL-B-X/ DH-XVR7108E-4KL-B-X Figure 3-2 Button/Icon Function Turns on/off the DVR. The indicator glows blue when the DVR is Power turned on. HDD status The indicator glows blue when the HDD is in malfunction. indicator Network status The indicator glows blue when the network connection is indicator abnormal.
Page 28: Dh-Xvr5104H-X1/Dh-Xvr5104He-X1
3.1.3 DH-XVR5108H-X/DH-XVR5116H-X/DH-XVR5104H-4KL-X/D H-XVR5108H-4KL-X/DH-XVR5116H-4KL-X/DH-XVR5108HE-X/DH- XVR5116HE-X/DH-XVR4116HS-X/DH-XVR5108HS-X/DH-XVR511 6HS-X/DH-XVR5104HS-4KL-X/DH-XVR5108HS-4KL-X/ DH-XVR5104HS-X/DH-XVR4104HS-X/DH-XVR4108HS-X/DH-XVR 5104H-X/DH-XVR5104HE-X/DH-XVR5108H-4KL-X-8P/ DH-XVR5104HS-X1/DH-XVR4104HS-X1/DH-XVR4108HS-X1/ DH-XVR5104H-X1/DH-XVR5104HE-X1 Figure 3-3 Port Name Function Glows blue when HDD status is abnormal. Glows blue when network status is abnormal. POWER Glows blue when the power is connected properly. Connects to peripheral devices such as USB storage device, USB port keyboard, and mouse.
Page 29: Dh-Xvr4216An-X/Dh-Xvr4232An-X/Dh-Xvr5216An-X/Dh-Xvr5232An-X/Dh-Xvr5208A N-4Kl-X/Dh-Xvr5216An-4Kl-X/Dh-Xvr5216A-X/Dh-Xvr5208An-4Kl-X-8P/Dh-Xvr5216 An-4Kl-X-16P
Port Name Function Connects to peripheral devices such as USB storage device, USB port keyboard and mouse. Table 3-4 3.1.5 DH-XVR4216AN-X/DH-XVR4232AN-X/DH-XVR5216AN-X/D H-XVR5232AN-X/DH-XVR5208AN-4KL-X/DH-XVR5216AN-4KL-X/ DH-XVR5216A-X/DH-XVR5208AN-4KL-X-8P/DH-XVR5216AN-4KL -X-16P Figure 3-5 Port Name Function Status indicator light Glows blue when the device is working properly. Glows blue when HDD status is abnormal.
Page 30: Dh-Xvr7416L-4Kl-X
Port Name Function Status indicator light Glows blue when the device is working properly. Connects to the external devices such as keyboard, mouse, USB port and USB storage device. Table 3-6 3.1.7 DH-XVR7416L-4KL-X Figure 3-7 Port Name Function IR receiver Receives infrared signal from remote control.
Page 31: Dh-Xvr5432L-X/Dh-Xvr5408L-X/Dh-Xvr5416L-X
3.1.9 DH-XVR5432L-X/DH-XVR5408L-X/DH-XVR5416L-X Figure 3-9 Port Name Function Status indicator light Glows blue when the device is working properly. Glows blue when HDD status is abnormal. Glows blue when network status is abnormal. POWER Glows blue when the power is connected properly. Connects to peripheral devices such as USB storage USB port device, keyboard, and mouse.
Page 32: Dh-Xvr1B04/Dh-Xvr1B04H/Dh-Xvr1B08/Dh-Xvr1B08H/Dh-Xvr1B16/Dh-Xvr1B16H
3.1.11 DH-XVR1B04/DH-XVR1B04H/DH-XVR1B08/DH-XVR1B08H /DH-XVR1B16/DH-XVR1B16H Rear Panel 3.2.1 DH-XVR5108C-X/DH-XVR5104C-4KL-X/DH-XVR5104C-X/ DH-XVR4104C-X/DH-XVR4108C-X/DH-XVR5104C-X1/ DH-XVR4104C-X1/DH-XVR4108C-X1 Figure 3-11 Port Name Function Video input port Connects to analog camera to input video signal. Connects to external devices such as USB storage device, USB port keyboard and mouse. Outputs analog video data to the connected display with VGA VGA port port.
Page 33: Dh-Xvr7108E-4Kl-B-X
3.2.2 DH-XVR7104E-4KL-X/DH-XVR7108E-4KL-X/DH-XVR7104E- 4KL-B-X/ DH-XVR7108E-4KL-B-X Figure 3-12 Figure 3-13 Port Name Function Video input port Connects to analog camera to input video signal. Receives audio signal output from the devices such as Audio input port microphone. Outputs audio signal to the devices such as the sound box. Audio output port RS-485 Connects to the control devices such as speed dome PTZ.
Page 34: Dh-Xvr4104Hs-X1/Dh-Xvr4108Hs-X1
Port Name Function Power input port Inputs12V DC power. Power output port Outputs 12V DC power. Ground Ground terminal. Table 3-12 3.2.3 DH-XVR4116HS-X/DH-XVR5108HS-X/DH-XVR5116HS-X/DH -XVR5104HS-4KL-X/DH-XVR5108HS-4KL-X/DH-XVR5104HS-X/ DH-XVR4104HS-X/DH-XVR4108HS-X/DH-XVR5104HS-X1/ DH-XVR4104HS-X1/DH-XVR4108HS-X1 Figure 3-14 Port Name Function Video input port Connects to analog camera to input video signal. Receives audio signal output from the devices such as Audio input port microphone.
Page 35: Xvr5104H-X1/Dh-Xvr5104He-X1
Table 3-13 3.2.4 DH-XVR5108H-X/DH-XVR5116H-X/DH-XVR5104H-4KL-X/D H-XVR5108H-4KL-X/DH-XVR5116H-4KL-X/DH-XVR5108HE-X/DH- XVR5116HE-X/DH-XVR7104HE-4KL-X/DH-XVR7108HE-4KL-X/DH -XVR7116HE-4KL-X/DH-XVR7108HE-4K-X/DH-XVR5104H-X/DH-X VR5104HE-X/DH-XVR5104H-X1/DH-XVR5104HE-X1 Figure 3-15 Port Name Function Four groups of alarm input ports (Group 1: port 1 to port 4; Group 2: port 5 to port 8; Group 3: port 9 to port 12; Group 4: port 13 to port 16).
Page 36: Dh-Xvr4216An-X/Dh-Xvr4232An-X/Dh-Xvr5216An-X/Dh-Xvr5232An-X/Dh-Xvr5208A N-4Kl-X/Dh-Xvr5216An-4Kl-X/Dh-Xvr5216A-X/Dh-Xvr7208A-4Kl-X/Dh-Xvr7216A-4K L-X/Dh-Xvr7208A-4K-X
Port Name Function Audio output port Outputs audio signal to the devices such as the sound box. High definition audio and video signal output port. The port outputs the uncompressed high definition video and HDMI port multi-channel audio data to the connected display with HDMI port.
Page 37 Port Name Function Four groups of alarm input ports (Group 1: port 1 to port 4; Group 2: port 5 to port 8; Group 3: port 9 to port 12; Group 4: port 13 to port 16). These ports receive the signal from the external alarm source.
Page 38: Dh-Xvr5108H-4Kl-X-8P/Dh-Xvr5208An-4Kl-X-8P/Dh-Xvr5216An-4Kl-X-16P
3.2.6 DH-XVR5108H-4KL-X-8P/DH-XVR5208AN-4KL-X-8P/DH-XV R5216AN-4KL-X-16P Figure 3-17 Port Name Function Video input port Connects to analog camera to input video signal. Video output port Connects to video output devices such as TV. Receives audio signal output from the devices such as Audio input port microphone.
Page 39: Dh-Xvr7416L-4Kl-X/Dh-Xvr5432L-X/Dh-Xvr5416L-X
3.2.7 DH-XVR7416L-4KL-X/DH-XVR5432L-X/DH-XVR5416L-X Figure 3-18 Port Name Function Ground terminal. Power input port Inputs power. Power button Turns on/off the DVR. Receives audio signal output from the devices such as Audio input port microphone. Audio input port Tow-way talk input port which receives analog audio signal (MIC IN) output from the devices such as microphone and pickup.
Page 40: Dh-Xvr5808S-X
Port Name Function Connects to the control devices such as speed dome PTZ. RS-485 RS-485_A port is connected by the cable A and RS-485_B is communication port connected to the cable B. Four-wire Four-wire full-duplex 485 port. T+ and T- is the output wire; R+ full-duplex RS-485 and R- is the input wire.
Page 41 Port Name Function Power button Turns on/off the Device. Power input port Inputs power. Receives the analog audio signal output from the devices such Audio input port as microphone. Audio input port Tow-way talk input port which receives the analog audio signal (MIC IN) output from the devices such as microphone, pickup.
Page 42: Dh-Xvr5408L-X
Port Name Function Outputs analog video signal. It can connect to the monitor to view VGA video output analog video. RS-232 debug It is for general COM debug to configure IP address or transfer COM. transparent COM data. High definition audio and video signal output port. It outputs the same video source as VGA.
Page 43 Port Name Function Four groups of alarm output ports (Group 1: port 1 to port 4;  Group 2: port 5 to port 8; Group 3: port 9 to port 12; Group 4: port 13 to port 16). These ports receive the signal from the Alarm input port external alarm source.
Page 44: Dh-Xvr7816S-4Kl-X/Dh-Xvr5832S-X/Dh-Xvr5816S-X
Table 3-19 3.2.10 DH-XVR7816S-4KL-X/DH-XVR5832S-X/DH-XVR5816S-X Figure 3-21 Port Name Function Ground. Power input port Inputs power. Power button Turns on/off the Device. Receives the analog audio signal output from the devices such Audio input port as microphone. Audio input port Tow-way talk input port which receives the analog audio signal (MIC IN) output from the devices such as microphone, pickup.
Page 45: Dh-Xvr7816S-4Kl-X-Lp
Port Name Function RS-485 You can connect to the control devices such as speed dome communication PTZ. RS-485_A port is connected by the cable A and RS-485_B port is connected to the cable B. Four-wire full-duplex Four-wire full-duplex 485 port. T+ and T- is the output wire; R+ RS-485 port (T+, and R- is the input wire.
Page 46 Port Name Function Outputs the analog audio signal to the devices such as the sound Audio output port box. Video output port Connect to video output devices such as TV. Audio input port Tow-way talk input port which receives the analog audio signal (MIC IN) output from the devices such as microphone, pickup.
Page 47: Dh-Xvr1B04/Dh-Xvr1B04H/Dh-Xvr1B08/Dh-Xvr1B08H
Port Name Function Power button Turns on/off the Device. Power input port Inputs power. Loop out Outputs the video signal of the corresponding video input port. Video input port Connect to analog camera to input video signal. Network port Connects to Ethernet port. Connects to the external devices such as keyboard, mouse, and USB port USB storage device.
Page 48: Dh-Xvr1B08H/Dh-Xvr1B16/Dh-Xvr1B16H
Port Name Function Connects to the external devices such as keyboard, mouse, and USB port USB storage device. Network port Connects to Ethernet port. Power input port Inputs power. Ground. Table 3-22 3.2.13 DH-XVR1B08H/DH-XVR1B16/DH-XVR1B16H Figure 3-24 Port Name Function Video input port Connect to analog camera to input video signal.
Page 49: Remote Control Operations
Remote Control Operations Please note the remote control is not our standard accessory and might not be included in the accessary bag. It is supplied dependent on the model you purchased. Figure 3-25 Name Function Power button Press this button to boot up or shut down the device. Press this button to input device serial number, so that you can Address control the Device.
Page 50: Mouse Operations
Name Function Go back to previous menu or cancel current operation (close front Esc. interface or control). Start or stop record manually.  In record interface, use the direction buttons to select the  Record channel that you want to record. ...
Page 51 Operation Function In text box, click the corresponding button on the panel to enter a numeral or English character (small/capitalized). In English input mode: Click to enter a backspace and click  to delete the previous character. In numeral input mode: Click to clear and click to delete the ...
Page 52: Connecting Basics
Connecting Basics This chapter introduces the typical connection diagrams and ports connections. Typical Connection Diagram The following figure is for reference only. The actual product shall govern. Figure 4-1 Connecting Basics 36...
Page 53 Figure 4-2 Connecting Basics 37...
Page 54: Connecting To Video And Audio Input And Output
Connecting to Video and Audio Input and Output 4.2.1 Video Input The video input interface is BNC. The input video format includes: PAL/NTSC BNC (1.0V 75Ω). The video signal should comply with your national standards. The input video signal shall have high SNR, low distortion; low interference, natural color, and suitable lightness.
Page 55: Audio Input
4.2.3 Audio Input This series of products audio input port adopt BNC port. Due to high impedance of audio input, please use active sound pick-up. Audio transmission is similar to video transmission. Try to avoid interference, dry joint, loose contact and it shall be away from high tension current. 4.2.4 Audio Output The audio output signal parameter is usually over 200mv 1KΩ...
Page 56: Introducing Alarm Port
Make sure the front-end device has soundly earthed Improper grounding might result in chip damage. 4.3.1 Introducing Alarm Port The alarm input ports are dependent on the model you purchased. Figure 4-3 Icon Description 1，2，3，4，5，6， ALARM 1 to ALARM 16. The alarm becomes active in low voltage. 7，8，9，10，11，...
Page 57: Alarm Output
 Connect the NC port of the alarm sensor to the DVR alarm input (ALARM).  Use the same ground with that of DVR if you use external power to the alarm device. Figure 4-4 4.3.3 Alarm Output  Provide external power to external alarm device. ...
Page 58: Connecting To Rs-485 Port
Connecting to RS-485 Port Step 1 Connect the RS-485 cable of the PTZ camera to the RS-485 port on the Device. Ensure the match of A and B interfaces. Step 2 Connect the video out cable of the PTZ camera to the video input port on the Device. Step 3 Turn on the PTZ camera.
Page 59: Local Configurations
Local Configurations Read the following notes prior to using the Device. The interfaces in the Manual are used for introducing the operations and only for reference.  The actual interface might be different dependent on the model you purchased. If there is inconsistency between the Manual and the actual product, the actual product shall govern.
Page 60 To secure the Device, it is strongly recommended for you to properly keep the password for admin and modify it regularly. Step 1 Turn on the Device. The Location, Language and Video Standard interface is displayed. See Figure 5-1. Figure 5-1 Step 2 Select your location from the drop-down list, then language and video standard will match your location automatically.
Page 61 Figure 5-2 Step 4 Tick the check box that I have read and agree to all terms, and then click Next. The System Zone and System Time interface is displayed. See Figure 5-3. Figure 5-3 Step 5 Select system zone, configure system time, and then click Next. The Enter Password interface is displayed.
Page 62 Parameter Description User By default, the user is admin. In the Password box, enter the password for admin. Password The new password can be set from 8 characters through 32 characters and contains at least two types from number, letter and Confirm Password special characters (excluding"'", """, ";", ":"...
Page 63 Figure 5-6 Step 9 Configure the protection parameters for password. For details, see Table 5-2. After configuration, if you forget the password for admin user, you can reset the password through the reserved email address or security questions. For details about resetting the password, see "5.1.3 Resetting Password."...
Page 64: Resetting Password
5.1.3 Resetting Password You can reset the password by the following methods when you forget the password for admin account.  If the password reset function is enabled, you can use mobile phone to scan the QR code to reset the password. For details, see "5.1.3.2 Resetting Password on Local Interface." If the password reset function is disabled, there are two situations: ...
Page 65 5.1.3.2 Resetting Password on Local Interface Step 1 Enter the login interface.  If you have configured unlock pattern, the unlock pattern login interface is displayed. See Figure 5-8. Click Forgot Pattern, the password login interface is displayed. See Figure 5-9. If you did not configure unlock pattern, the password login interface is displayed.
Page 66 Step 2 Click If you have set the reserved email address, the Prompt message interface is  displayed. See Figure 5-10.  If you did not set the reserved email address, the email entering interface is displayed. See Figure 5-11. Enter the email address, and then click Next, the Prompt message interface is displayed.
Page 67 The Reset Password interface is displayed. See Figure 5-12. After clicking OK, the system will collect your information for password reset, and the information includes but not limited to email address, MAC address, and device serial number. Read the prompt carefully before clicking OK. Figure 5-12 Step 4 Reset the password.
Page 68 Figure 5-13 Step 5 Click Next. The new password resetting interface is displayed. See Figure 5-14. Figure 5-14 Step 6 In the New Password box, enter the new password and enter it again in the Confirm Password box. Step 7 Click Save.
Page 69 A pop-up message is displayed asking if you want to sync the password with the remote devices, see Figure 5-15. Click Cancel, the resetting is finished.   Click OK, the Sync Info interface is displayed. See Figure 5-15. Figure 5-15 This message appears only when there are digital channels instead of only analog channels.
Page 70: Setting Up With The Startup Wizard
5.1.3.3 Using Reset Button on the Mainboard You can always use the reset button on the mainboard to reset the Device to the factory default. Not all models are provided with reset button. Step 1 Disconnect the Device from power source, and then remove the cover panel. For details about removing the cover panel, see "2.2 Installing HDD."...
Page 71 Figure 5-18  If you select the Auto-check for updates check box, the system will notify you automatically when updates are available. After the auto-check function is enabled, to notify you to update timely, the system will  collect the information such as IP address, device name, firmware version, and device serial number.
Page 72 Figure 5-19 Step 2 Configure the general settings parameters. See Table 5-3. Parameter Description Device Name In the Device Name box, enter the Device name. Device No. In the Device No. box, enter a number for the Device. Language In the Language list, select a language for the Device system. In the Video Standard list, select PAL or NTSC according to your actual Video Standard situation.
Page 73 5.1.4.3 Configuring Date and Time Settings You can configure the system time, choose the time zone, set the daylight saving time, and enable the NTP server. You can also configure date and time settings by selecting Main Menu > SYSTEM > GENERAL >...
Page 74 Parameter Description In the Time Format list, select 12-HOUR or 24-HOUR for the time Time Format display style. Enable the Daylight Saving Time function. Click Week or click Date. Start Time Configure the start time and end time for the DST. End Time Enable the NTP function to sync the Device time with the NTP server.
Page 75 Figure 5-21 Step 2 Configure the settings for network parameters. See Table 5-5. Parameter Description Multi-address: Two Ethernet ports work separately through either  of which you can request the Device to provide the services such as HTTP and RTSP. You need to configure a default Ethernet port (usually the Ethernet port 1 by default) to request the services from the device end such as DHCP, Email and FTP.
Page 76 Parameter Description In the Ethernet Card list, select an Ethernet port as a default port. Default Ethernet Port This setting is available only when the Multi-address is selected in the Net Mode list. In the IP Version list, you can select IPv4 or IPv6. Both versions are IP Version supported for access.
Page 77 Step 1 After you have configured the network settings, on the NETWORK interface, click Next. The P2P interface is displayed. See Figure 5-22. Figure 5-22 Step 2 Enable the P2P function. After the P2P function is enabled and connected to the Internet, the system will collects your information for remote access, and the information includes but not limited to email address, MAC address, and device serial number.
Page 78 Figure 5-23 To use this function, take adding device into Cell Phone Client as an example. Adding Device into Cell Phone Client Step 1 Use your cell phone to scan the QR code under Cell Phone Client to download the application.
Page 79  If the Device has not been initialized, Tap Device Initialization to perform initializing by following the onscreen instructions.  If the Device has been initialized, you can start adding it directly. Tap Add Device. The Add Device interface is displayed. See Figure 5-25. You can add wireless device or wired device.
Page 80 Figure 5-26 Enter a name for the DVR, the username and password, scan the QR code under Device SN. Tap Start Live Preview. The Device is added and displayed on the live view interface of the cell phone. See Figure 5-27. Figure 5-27 Local Configurations 64...
Page 81 5.1.4.6 Configuring Encode Settings You can configure the settings of main stream and sub stream for the Device. You can also configure encode settings by selecting Main Menu > CAMERA > ENCODE > Encode. Step 1 After you have configured the P2P settings, on the P2P interface, click Next. The Encode interface is displayed.
Page 82 Parameter Description Configure the frames per second for the video. The higher the value is, the clearer and smoother the image will become. Frame rate changes along with the resolution. Frame Rate Generally, in PAL format, you can select the value from 1 through 25; (FPS) in NTSC format, you can select the value from 1 through 30.
Page 83 Figure 5-29 Step 2 Configure the settings for the snapshot parameters. See Table 5-7. Parameter Description In the Manual Snap list, select how many snapshots you want to take Manual Snap each time. In the Channel list, select the channel that you want to configure the Channel settings for.
Page 84 Step 1 After you have configured the encode settings, on the SNAPSHOT interface, click Next. The BASIC interface is displayed. See Figure 5-30. Figure 5-30 Step 2 Configure the basic storage settings parameters. See Table 5-8. Parameter Description Configure the settings for the situation when all the read/write discs are full, and there are no more free discs.
Page 85 Figure 5-31 Step 2 Configure the record settings parameters. See Table 5-9. Parameter Description Channel In the Channel list, select a channel to record the video. In the Pre-record list, enter the amount of time that you want to start Pre-record the recording in advance.
Page 86 Parameter Description Define a period during which the configured recording setting is active. Period The system only activates the alarm in the defined period. Copy Click Copy to copy the settings to other channels. Table 5-9 Step 3 Define the video recording period by drawing or editing. By default, it is active all the time.
Page 87  Select the check box of event type, and then click to clear the defined period.  When selecting MD&Alarm, the MD and Alarm check boxes will be cleared respectively.  Define the period by editing. Take Sunday as an example. Click The Period interface is displayed.
Page 88 Step 1 After you have configured the video recording settings, on the Record interface, click Next. The SNAPSHOT interface is displayed. See Figure 5-35. Figure 5-35 Step 2 Configure the snapshot settings parameters. See Table 5-10. Parameter Description Channel In the Channel list, select a channel to take a snapshot. Select the check box of the event type which includes General, MD, Event type Alarm, MD&Alarm, Intel, and POS.
Page 89: Live View
Figure 5-36 Live View After you logged in the Device, the live view is displayed. See Figure 5-37. The number of channels displayed depends on your model. Figure 5-37 Also, you can click on the top right of the main interface to enter the live view screen. See Figure 5-38.
Page 90: Live View Screen
Figure 5-38 5.2.1 Live View Screen You can view the live video from the connected cameras through each channel on the screen. By default, the system time, channel name and channel number are displayed on each  channel window. This setting can be configured by selecting Main Menu > CAMERA > OVERLAY.
Page 91: Live View Control Bar
5.2.2 Live View Control Bar The live view control bar provides you access to perform the operations such as playback, zoom, real-time backup, manual snapshot, voice talk, adding remote devices, and streams switch. When you move the pointer to the top middle position of a channel window, the live view control bar is displayed.
Page 92 Function Function Function Instant Play Manual Snap Siren Digital Zoom Mute Audio Talk Real-time White Light Camera Registration Backup Table 5-12 5.2.2.1 Instant Playback You can play back the previous five minutes to sixty minutes of the recorded video. By clicking , the instant playback interface is displayed.
Page 93 5.2.2.2 Digital Zoom You can enlarge a specific area of the image to view the details by either of the following two ways. Click , the icon switches to . Hold down the left mouse button to select the area ...
Page 94: Navigation Bar
5.2.2.7 Siren (Supported on camera with siren function) Click to manually control the camera to generate alarm sound. 5.2.2.8 Bidirectional Talk (Digital channel only) You can perform the voice interaction between the Device and the remote device to improve efficiency of emergency. This function is supported only when the remotely connected IPC device supports bidirectional talk.
Page 95: Shortcut Menu
Icon Function Go to the previous screen. Go to the next screen. Enable tour function. The icon switches to Open the PTZ control panel. For details, see "5.4 Controlling PTZ Cameras." Open the Color Setting interface. For details, see "5.2.5 Color Setting."...
Page 96 Figure 5-43 Function Description Main Menu Open Main Menu interface. Open the PLAYBACK interface where you can search and play Search back record files. Open the PTZ interface. Configure the live view screen as a single-channel layout or View Layout multi-channel layout.
Page 97: Color Setting
Function Description Point to the channel window and right-click on it to open the shortcut menu, and then click Auto Focus. Auto Focus Not all cameras support this function. Open the COLOR interface where you can adjust the video image Color Setting color.
Page 98 Parameter Description Adjust the sharpness of image edge. The bigger the value is, the Sharpness more obvious the image edge, and the noise is also greater. The value ranges from 1 to 15. The default value is 1. Adjust the hue of image. The value ranges from 0 to 100. The default value is 50.
Page 99: Live View Display
Parameter Description You can customize four color modes. Click Customized. The Customized Color interface is displayed. In the Color Mode list, select Customized 1, for example. Then configure the settings for sharpness, hue, brightness, Customized contrast and saturation. If you select All, the configuration will applies to all four customized color modes.
Page 100 Parameter Description Out Port Indicates the main screen port. Select the Time Display check box, the current system time Time Display displays in each channel window in live view screen. To hide the time, clear the check box. Select the Channel Title check box, the channel name, channel number and recording status display in each channel Channel Title window in live view screen.
Page 101 Parameter Description port and HDMI port is 1280×720. Some of the resolution options might not be supported on the HDMI port. The main menu does not display on the extra screen. If you do not enable the extra screen function, both the VGA port and HDMI port display the same image.
Page 102 Figure 5-48 Step 3 Adjust the position of channels if needed. In the channel list, for example, in the channel 9 list, you can select 10, and then the channel 9 and channel 10 exchange positions. Step 4 Click Apply to complete the settings. The live view screen displays the same layout as configured in this section.
Page 103 Figure 5-49 Step 2 Configure the settings for the zero-channel parameters. See Table 5-17. Parameter Description Enable Enable zero-channel function. In the Compression list, select the video compression standard Compression according to the device capability. The default is H.265. In the Resolution list, select the video resolution. The default is Resolution 704×576 (D1).
Page 104: Configuring Tour Settings
You can adjust the border margins in top, bottom, left and right directions as well as the brightness of the monitor connected to the Video out port of the Device. Step 1 Select Main Menu > DISPLAY > TV ADJUST. The TV ADJUST interface is displayed.
Page 105 Figure 5-51 Figure 5-52 Step 2 Configure the settings for the tour parameters for both Main Screen and Extra Screen. See Table 5-18. Local Configurations 89...
Page 106 Parameter Description Enable Enable tour function. Enter the amount of time that you want each channel group displays Interval (Sec.) on the screen. The value ranges from 5 seconds to 120 seconds, and the default value is 5 seconds. Video Detect, Select the View 1 or View 8 for Motion Detect tour and Alarm Tour Alarm (system alarm events).
Page 107: Entering Main Menu
Step 2 Select the channels that you want to group for tour. See Figure 5-54. If you want to select more than one channel, in the Window Split list, do not select View 1. Figure 5-54 Step 3 Click OK to complete the settings. Modifying a Channel Group Double-click on a channel group, the Modify Channel Group interface is displayed.
Page 108 Figure 5-56 Description Icon Includes six function tiles: VIDEO, ALARM, SMART DETECTION, POS, IoT, and BACKUP. Click each tile to open the configuration interface of the tile. VIDEO: Search for and play back the recorded video saved on the  Device.
Page 109: Controlling Ptz Cameras
Description Icon When you point to , the current user account is displayed. Click , select Logout, Reboot, or Shutdown according to your actual situation. Displays Cell Phone Client and Device SN QR Code.  Cell Phone Client: Use your mobile phone to scan the QR code to add the device into the Cell Phone Client, and then you can start accessing the Device from your cell phone.
Page 110 Figure 5-57 Step 2 Configure the settings for the PTZ connection parameters. See Table 5-20. Parameter Description In the Channel list, select the channel that you want to connect the PTZ Channel camera to.  Local: Connect through RS-485 port or coaxial cable. PTZ Type Remote: Connect through network by adding IP address of PTZ ...
Page 111: Working With Ptz Control Panel
Step 3 Click Apply to save the settings. Click Copy to copy the settings to other channels. 5.4.2 Working with PTZ Control Panel PTZ control panel performs the operations such as directing camera in eight directions, adjusting zoom, focus and iris settings, and quick positioning. Basic PTZ Control Panel Right-click on the live view screen and then select PTZ.
Page 112 Parameter Description Fast positioning button. Positioning: Click to enter the fast positioning screen, and  then click anywhere on the live view screen, the PTZ will turn to this point and move it to the middle of the screen. Zooming: On the fast positioning screen, drag to draw a square on ...
Page 113: Configuring Ptz Functions
Click the AUX Config icon to open Autoscan the PTZ functions settings interface. Click the Enter Menu icon to open AUX Switch the MENU OPERATION interface. Table 5-22 5.4.3 Configuring PTZ Functions 5.4.3.1 Configuring Presets Step 1 On the Expanded PTZ Control Panel, click The Preset interface is displayed.
Page 114 Figure 5-61 Step 3 In the Patrol No. box, enter the value for the tour route. Step 4 In the Preset box, enter the preset value. Step 5 Click Add Preset. A preset will be added for this tour.  You can repeat adding more presets.
Page 115: Calling Ptz Functions
5.4.3.4 Configuring AutoScan Step 1 On the Expanded PTZ Control Panel, click The PTZ interface is displayed. Step 2 Click the Border tab. The Border interface is displayed. See Figure 5-63. Figure 5-63 Step 3 Click the direction arrows to position the left and right borders. 5.4.4 Calling PTZ Functions After you have configured the PTZ settings, you can call the PTZ functions for monitoring from the Expanded PTZ Control Panel.
Page 116 5.4.4.2 Calling Tours Step 1 On the Expanded PTZ Control Panel, in the No. box, enter the value of the tour that you want to call. Step 2 Click to call the tour. Step 3 Click again to stop calling the tour. 5.4.4.3 Calling Patterns Step 1 On the Expanded PTZ Control Panel, in the No.
Page 117: Calling Osd Menu
Figure 5-65 5.4.5 Calling OSD Menu For the coaxial camera, you can call the OSD menu through the Expanded PTZ Control Panel. See Figure 5-64. Step 1 On the Expanded PTZ Control Panel, click The MENU OPERATION interface is displayed. See Figure 5-66. Figure 5-66 Step 2 Click Enter.
Page 118: Configuring Camera Settings
Configuring Camera Settings 5.5.1 Configuring Image Settings You can configure the image settings such as saturation, contrast, brightness, sharpness for each connected camera. Step 1 Select Main Menu > CAMERA > IMAGE. The IMAGE interface is displayed. See Figure 5-68 for analog channel and Figure 5-69 for digital channel.
Page 119 Figure 5-69 Step 2 Configure the settings for the image parameters. See Table 5-23. On the digital channel interface, click More Setting to display more parameters. Parameter Description Channel In the Channel list, select the channel that you want to configure. In the Cable Type list, select the cable type that the camera uses.
Page 120 Parameter Description Adjusts the image contrast. The bigger the value is, the more obvious the contrast between the light area and dark area will become. You can adjust this value when the contrast is not obvious. However, if the value is too big, the dark area is likely to become darker and the light Contrast area over exposed.
Page 121: Configuring Encode Settings
Parameter Description Configure the white balance to adjust the general hue of the image. The default setting is Auto. Auto: Automatically apply white balance to different colors to  Scene Mode make the image color display normally. Sunny: Apply the threshold value to sunny environment. ...
Page 122 Figure 5-70 Step 2 Configure the settings for the main/sub streams parameters. See Table 5-24. Parameter Description In the Channel list, select the channel that you want to configure the Channel settings for. Enable the smart codec function. This function can reduce the video Smart Codec bit stream for non-important recorded video to maximize the storage space.
Page 123 Parameter Description Configure the frames per second for the video. The higher the value, the clearer and smoother the image will become. Frame rate changes along with the resolution. Frame Rate Generally, in PAL format, you can select the value from 1 through 25; (FPS) in NTSC format, you can select the value from 1 through 30.
Page 124 Figure 5-71 Step 2 Configure the settings for the snapshot parameters. See Table 5-25. Parameter Description In the Manual Snap list, select how many snapshots you want to take Manual Snap each time. In the Channel list, select the channel that you want to configure the Channel settings for.
Page 125: Configuring Overlay Settings
Click Copy to copy the settings to other channels. 5.5.2.3 Encode Enhancement Only some series products support encode enhancement.  Enabling or disabling this function will take effect after the device is rebooted.  This function is disabled by default. After it is enabled, when main stream resolution is 4K, the frame rate can be 10 fps.
Page 126: Configuring Covered Area Settings
Figure 5-73 Step 2 Configure the settings for the text overlay parameters. See Table 5-26. Parameter Description In the Channel list, select the channel that you want to configure the Channel settings for. Select the Time Display check box to display the system time on Time Display each channel window in the live view screen.
Page 127: Configuring Channel Type
Figure 5-74 Step 2 Configure the settings for the covered area parameters. See Table 5-27. Parameter Description In the Channel list, select the channel that you want to configure the Channel settings for.  Preview: Select the Preview check box to apply the configured covered block to the selected channel window in the live view Preview screen.
Page 128: Upgrading Coaxial Camera
The CHANNEL TYPE interface is displayed. See Figure 5-75. Figure 5-75 Step 2 Configure the channels. Analog Channel: Select the transmission medium such as CVI, CVBS, and then  follow the onscreen instructions to complete the settings. IP Channel: You can enable the IP channels by disabling the corresponding analog ...
Page 129: Configuring Remote Devices
Figure 5-76 Step 2 Click Browse. The Browse interface is displayed. Step 3 Select the upgrade file and then click OK. The COAXIAL UPGRADE interface is displayed. You need to insert the USB storage device that contains the upgrading files. Step 4 Select the check box of the channel that you want to upgrade.
Page 130 Figure 5-77 Parameter Description Enable the Uninitialized function, the uninitialized devices out of the Uninitialized searched devices are displayed in the searched device list. Select the uninitialized device from the uninitialized device list, and Initialize the click Initialize to start initializing device. In the Show Filter list, select the remote device type that you want to display in the searched device list.
Page 131 Parameter Description Add the device by manually configuring settings such as IP address, Manual Add channel selection. For details, see "5.6.1.3 Adding Remote Devices Manually." Added Device Displays the added devices. You can edit and delete the device, and List view the device information.
Page 132 Figure 5-79 Step 3 Select the uninitialized device that you want to initialize. Step 4 Click Initialize. The Enter Password interface is displayed. See Figure 5-80. Figure 5-80 Step 5 Configure the password and email information. If you select the Using current device password and email info check box, the remote device automatically uses the current password and email information, so you do not need to set the password and email address again and can go to Step 6.
Page 133 Figure 5-81 Configure the settings for the password setting parameters. See Table 5-29. Parameter Description User The default is admin. The new password can be set from 8 characters through 32 Password characters and contains at least two types from number, letter and special characters (excluding"'", """, ";", ":"...
Page 134 The NETWORK interface is displayed. See Figure 5-83. Figure 5-83 Step 7 Configure the IP address.  Select the DHCP check box, you do not need to enter the IP address information, because the system will allocate one IP address to the remote device. ...
Page 135 Figure 5-84 Step 9 Click Finished to complete the settings. 5.6.1.2 Adding Remote Devices Automatically Step 1 On the Registration interface, click Device Search The searched devices are displayed. See Figure 5-85. Figure 5-85 Local Configurations 119...
Page 136 Step 2 Select the check box of the device. Step 3 Click Add. The device is added into the Added Device area.  You can also double-click the device to add it into the Added Device area.  You can add devices in batches. 5.6.1.3 Adding Remote Devices Manually Step 1 On the Registration interface, click Manual Add.
Page 137 Parameter Description your actual situation. If you enter other value, for example, 70, and then you should enter 70 after the IP address when logging in the Device by browser. User Name Enter the user name of the remote device. Password Enter the password of the user for the remote device.
Page 138 Figure 5-87 Step 2 In the Channel list, select the channel that you want to modify settings for. Step 3 Click OK to save the settings. Click Copy to copy the user name and password to other channels. To delete one or more added devices, do the following: ...
Page 139 Figure 5-88 Step 2 Configure the settings for IP address, subnet mask, default gateway, user name, and password. Step 3 Enable the Add function to add the device into the Added Device area. Step 4 Click OK to save the settings. ...
Page 140 5.6.1.6 Exporting IP Address You can export the added IP address to the USB storage device. The exported information is saved in .csv file, which includes IP address, port number, channel number, manufacturer, user name, and password. Step 1 Insert the USB storage device to the USB port of the Device. Step 2 Click Export.
Page 141: Managing Remote Devices
Figure 5-91 Step 3 Select the file that you want to import. Step 4 Click OK to start importing. After importing is completed, a pop-up message indicating "The import succeeded" is displayed. If the IP address that you want to import already exists in the Device, the system will pop up a message to ask you whether to overwrite the existing content.
Page 142 Figure 5-92 5.6.2.2 Viewing Firmware Information You can view the device firmware information such as channel number, IP address, manufacturer, system version, video input, audio input, and alarm in. Select Main Menu > CAMERA > REGISTRATION > Firmware, the Firmware interface is displayed.
Page 143 Figure 5-93 5.6.2.3 Upgrading Remote Devices Step 1 Select Main Menu > CAMERA > REGISTRATION > Upgrade. The Upgrade interface is displayed. See Figure 5-94. Local Configurations 127...
Page 144: Configuring Record Settings
Figure 5-94 Step 2 Upgrade the device. File Upgrade  Insert a USB storage device containing the upgrade files into the USB port of the Device. Select the devices that you want to upgrade. Click File upgrade. The File Upgrade interface is displayed. Select the upgrading files and click Apply.
Page 145: Enabling Record Control
5.7.1 Enabling Record Control  Manual recording operation requires the user have the permission to access STORAGE settings. Check to ensure the HDD installed in the Device has been formatted properly.  To enter the record control interface, do the following: Step 1 Right-click on the live view screen, the shortcut menu is displayed.
Page 146: Configuring Recorded Video Storage Schedule
5.7.2 Configuring Recorded Video Storage Schedule You need to configure the storage schedule for the recorded video so that the recorded video can be saved. For details, see "5.1.4.9 Configuring Recorded Video Storage Schedule." Configuring Snapshot Settings 5.8.1 Configuring Snapshot Trigger The snapshot is divided into scheduled snapshot, event triggered snapshot, and face detection triggered snapshot.
Page 147 Figure 5-97 Step 6 Click Apply to save the settings. If you have configured the snapshot schedule, the configuration has been  completed. If you have not configured the snapshot schedule, see "5.1.4.10 Configuring  Snapshot Storage Schedule." 5.8.1.2 Configuring Event Triggered Snapshot Step 1 Select Main Menu >...
Page 148 Figure 5-98 Step 3 Select Main Menu > ALARM > VIDEO DETECT, and select the event type to configure, for example, select the Motion Detect tab. See Figure 5-99. Figure 5-99 Local Configurations 132...
Page 149 Step 4 Select the Snapshot check box and select the corresponding channel. Step 5 Click Apply. 5.8.1.3 Configuring Face Detection Triggered Snapshot Step 1 Select Main Menu > CAMERA > ENCODE > Snapshot. The Snapshot interface is displayed. Step 2 In the Mode list, select Human Face, and then configure other parameters.
Page 150: Configuring Snapshot Storage Schedule
Figure 5-101 Step 4 Select the Snapshot check box and select the corresponding channel. Step 5 Click Apply. 5.8.2 Configuring Snapshot Storage Schedule You need to configure the storage schedule for the snapshot so that the snapshot can be saved. For details, see "5.1.4.10 Configuring Snapshot Storage Schedule."...
Page 151: Playing Back Video
Figure 5-102 Step 2 Enable the FTP function and configure the parameters. For details, see "5.18.9 Configuring FTP Storage Settings." The snapshots will be uploaded to FTP for backup. Playing Back Video 5.9.1 Enabling Record Control  Manual recording operation requires the user have the permission to access STORAGE settings.
Page 152: Instant Playback
Figure 5-103 Step 2 Configure the settings for the record control parameters. See Table 5-32. Parameter Description Displays all the analog channels and the connected digital channels. Channel You can select a single channel or select All. Auto: Automatically record according to the record type and ...
Page 153 Figure 5-104 Function Description Display the searched recorded video or picture. It supports playing single-channel, 4-channel, 9-channel, 16-channel simultaneously. Display Window When playing back in a single channel mode, hold down the left mouse button to select the area that you want to enlarge. The area is enlarged after the left mouse button is released.
Page 154 Function Description Display the type and time period of the current recorded video. In the 4-channel layout, there are four time bars are displayed;  in the other view layouts, only one time bar is displayed. Click on the colored area to start playback from a certain time. ...
Page 155 Function Description This area includes Mark List and File List.  : Click the Mark List button, the marked recorded video list is displayed. Double-click the file to start playing. List Display  : Click the File List button, the searched recorded video list is displayed.
Page 156 Icon Function Play Backward.  During playing back, click the Play Backward button to backward play the recorded video, the button switches to ; click to stop playing backward.  During playing back, click to start playing forward. Previous Frame/Next Frame. ...
Page 157 Icon Function Add Mark for the recorded view. For details about adding mark, see "5.9.5 Marking and Playing Back Video." Hide POS Hide. During single-channel playback, click to display or hide POS information on the screen. Table 5-34 5.9.3.2 Selecting Search Type You can search the recorded videos, splice, or snapshots from HDD or external storage device.
Page 158 Step 3 Click on the time bar to select the end time, and then click to stop clipping. Step 4 Click The BACKUP dialog box is displayed. You can back up the files. You can clip the video of a single-channel or multiple channels. ...
Page 159: Smart Search
5.9.4 Smart Search During playback, you can analyze a certain area to find if there was any motion detection event occurred. The system will display the images with motion events of the recorded video. Not all models support this function. To use the Smart Search function, you need to enable the motion detection for the channel by selecting Main Menu >...
Page 160 Figure 5-110 Step 3 In the Name box, enter a name. Step 4 Click OK. This marked video file displays in the Mark List. Playing Back Marked Video This function is supported on single-channel playback. Step 1 In the CAME NAME list, select one channel. Step 2 Click The Mark List interface is displayed.
Page 161 Playing Back Time before the Mark You can configure to play N seconds of the marked video before the marked time. Step 1 In the Name box, enter the name of a marked video. Step 2 In the Playback time before the mark box, enter N seconds. Step 3 Click The playback starts from N seconds before the marked time.
Page 162: Playing Back Snapshots
5.9.6 Playing Back Snapshots You can search and play back the snapshots. Step 1 Select Main Menu > VIDEO, the video search interface is displayed. Step 2 In the Search Type list, select PIC. Step 3 In the Channel list, select a channel number. Step 4 In the Calendar area, select a date.
Page 163: Using The File List
5.9.8 Using the File List You can view all the recorded videos within a certain period from any channel in the File List. Step 1 Select Main Menu > VIDEO, the video search interface is displayed. Step 2 Select a channel(s). Step 3 Click The File List interface is displayed.
Page 164: Alarm Events Settings
To lock the recorded video, on the File List interface, select the check box of the recorded  video, and then click . The locked video will not be covered. To view the locked information, click , the FILE LOCKED interface is displayed. ...
Page 165: Alarm Input Settings
Figure 5-117 Step 2 In the Type list, select the event type; In the Start Time box and End Time box, enter the specific time. Step 3 Click Search. The search results are displayed. Step 4 Click Backup to back up the search results into the external storage device. Click to play the recorded video of alarm event.
Page 166 Figure 5-118 Step 2 Configure the settings for the local alarms. See Table 5-35. Parameter Description Alarm In Select the channel number. Alarm Name Enter the customized alarm name. Enable Enable or disable the local alarm function. Type In the Type list, select NO or select NC as the voltage output type. Click Setting to display setting interface.
Page 167 Parameter Description Select the Alarm Upload check box to enable the system to upload the Alarm Upload alarm signal to the network (including alarm center) when an alarm event occurs. Select the Send Email check box to enable the system to send an email notification when an alarm event occurs.
Page 168 5.10.2.2 Configuring Alarms from Alarm Box You can connect the alarm box to the RS-485 port of the Device. When the alarm is detected by the alarm box, the alarm information will be uploaded to the Device, and then the Device outputs the alarms in the way that you configure in this section.
Page 169 Figure 5-120 Step 2 Configure the alarm input settings from the external IPC. For details, see Table 5-35. Step 3 Click Apply to complete the settings. Click Default to restore the default setting.  Click Copy to copy the settings to other channels. ...
Page 170 Figure 5-121 Step 2 Configure the alarm input settings from the offline IPC. For details, see Table 5-35. Step 3 Click Apply to complete the settings. Click Default to restore the default setting.  Click Copy to copy the settings to other channels. ...
Page 171 Figure 5-122 Step 2 In the Channel list, select a channel or all. Step 3 Click The Setting interface is displayed. See Figure 5-123. Figure 5-123 Step 4 Configure the settings for other parameters of the Alarm Box. For details, see Table 5-35.
Page 172: Alarm Output Settings
Step 6 Click Apply to complete the settings. 5.10.3 Alarm Output Settings 5.10.3.1 Configuring Alarm Output When the Device activates alarms, the connected alarm device generates alarms in the way that you can configure in this section. You can connect to the output port of the Device or connect wirelessly.
Page 173 Parameter Description Alarm Release Click OK to clear all alarm output status. Table 5-36 Step 3 Click Apply to save the settings. 5.10.3.2 Configuring White Light When the motion detection alarm is activated, the system links the camera to generate white light alarm.
Page 174 Parameter Description When setting the alarm mode of white light to be Flash, you can Flash Frequency select the flash frequency from Low, Middle, and High. Table 5-37 Step 3 Click Apply to complete the settings. 5.10.3.3 Configuring Siren When the motion detection alarm is activated, the system links the camera to generate sound alarm.
Page 175: Video Detection
Parameter Description Select the volume for the audio clip. You can select the flash frequency Volume from Low, Middle, and High. Import the upgrade audio file (.bin) to upgrade the alarm audio file of the Update File camera. For details, see "Upgrade Audio File of Camera ."...
Page 176 Step 1 Select Main Menu > ALARM > VIDIEO DETECT > Motion Detect. The Motion Detect interface is displayed. See Figure 5-128. Figure 5-128 Step 2 Configure the settings for the motion detection parameters. See Table 5-39. Parameter Description Channel In the Channel list, select a channel to set the motion detection.
Page 177 Parameter Description Configure the time period from end of event detection to the stop of Anti-Dither alarm. Click Setting to display setting interface. General Alarm: Enable alarm activation through the alarm  devices connected to the selected output port. Alarm Out ...
Page 178 Parameter Description Select the check box to enable the function. When an alarm event occurs, the extra screen outputs the settings configured in Main Menu > DISPLAY > TOUR > Extra Screen. Extra Screen Not all models support this function. ...
Page 179 Parameter Description The bigger the value is, the easier the alarms can be activated. Adjust the threshold for motion detect. Every region of every channel Threshold has an individual threshold. Figure 5-130 When anyone of the four regions activates motion detect alarm, the channel where this region belongs to will activate motion detect alarm.
Page 180  Define the period by editing. Take Sunday as an example. Click The Period interface is displayed. See Figure 5-132. Figure 5-132 Enter the time frame for the period, and then select the check box to enable the settings.  There are six periods for you to set for each day. ...
Page 181 Figure 5-133 To configure the settings for the video loss detection parameters, see “5.10.4.1 Step 2 Configuring Motion Detect Settings.” For PTZ activation, different from motion detection, the video loss detection can activate PTZ preset, tour, and pattern. Step 3 Click Apply to complete the settings.
Page 182 Figure 5-134 To configure the settings for the tampering detection parameters, see “5.10.4.1 Step 2 Configuring Motion Detect Settings.” For PTZ activation, different from motion detection, the video loss detection can activate PTZ preset, tour, and pattern. Step 3 Click Apply to complete the settings. Click Default to restore the default setting.
Page 183 Figure 5-135 Step 2 To configure the settings for the diagnosis parameters, see "5.10.4.1 Configuring Motion Detect Settings." Step 3 Click Apply to complete the settings. Click Default to restore the default setting. Setting the Types for Diagnosing Targets Step 1 Next to Rule, click Setting.
Page 184: System Events
Parameter Description A horizontal, vertical or diagonal stripe that might appear in the Stripe video because of device aging or electronic interruption. Such stripe brings visual interruption. Video noises such as blurriness or quality reduction that is caused Noise by optical distortion or device problem during camera shooting. Color Cast Variances in the normal proportions of RGB colors.
Page 185 Figure 5-137 Step 2 Configure the settings for the HDD event. See Table 5-41. Parameter Description In the Event Type list, select No HDD, HDD Error, or HDD No Space Event Type as the event type. Enable Enable or disable the HDD event detection function. Click Setting to display setting interface.
Page 186 Parameter Description Select the Send Email check box to enable the system to send an email notification when an alarm event occurs. Send Email To use this function, make sure the email function is enabled in Main Menu > NETWORK > EMAIL. Buzzer Select the check box to activate a buzzer noise at the Device.
Page 187 Parameter Description Click Setting to display setting interface. General Alarm: Enable alarm activation through the alarm devices  connected to the selected output port. Alarm Out External Alarm: Enable alarm activation through the connected  alarm box. Wireless Siren: Enable alarm activation through devices ...
Page 188 Figure 5-139 Step 2 Configure the settings for the User event. See Table 5-43. Parameter Description Event Type In the Event Type list, select Illegal Login. Enable the user error detection function. If you do not enable this function, there will be no limit for wrong Enable password entry and the account cannot be locked because of the wrong password.
Page 189 Parameter Description Select the Send Email check box to enable the system to send an email notification when an alarm event occurs. Send Email To use this function, make sure the email function is enabled in Main Menu > NETWORK > EMAIL. Buzzer Select the check box to activate a buzzer noise at the Device.
Page 190 Figure 5-141 Step 4 Configure the settings for the Device event. See Table 5-44. Parameter Description Network Security Exception, including brute force attack of  Web path, brute force attack of session ID, session connection over-limit and abnormal program in trusted environment. ...
Page 191: Smart Detection
Parameter Description Select the Send Email check box to enable the system to send an email notification when an alarm event occurs. Send EMAIL To use this function, make sure the email function is enabled in Main Menu > NETWORK > EMAIL. Select to enable audio broadcast/voice prompts in response to a user Voice Prompts account alarm event.
Page 192 Figure 5-142 Step 2 Select the channel and enable. Step 3 Set parameters. See Figure 5-50. Parameter Description Set sensitivity, including high, middle, and low. The higher the Sensitivity sensitivity is, the bigger alarm probability will be, the bigger false alarm rate will be.
Page 193 Figure 5-143 Step 2 Select channel, type, begin time and end time, and then click Search. The search result is displayed. See Figure 5-144. Click to play back the video.  Tick the check box before the video, and then click Export to export the video to ...
Page 194: Configuring Face Detection
Figure 5-144 5.11.2 Configuring Face Detection You can configure the face detection settings and search the detected faces in the defined time period. Not all models support this function.  Only the analog channel 1 supports this function. The IP channel does not support this ...
Page 195 Figure 5-145 Step 2 Configure the settings for the face detection parameters. See Table 5-46. Parameter Description In the Channel list, select the channel that you want to configure the face detection settings. Channel Only the analog channel 1 supports this function. Enable Enable or disable the face detection function.
Page 196 Parameter Description Select the Show Message check box to enable a pop-up message Show Message in your local host PC. Select the Alarm Upload check box to enable the system to Alarm Upload upload the alarm signal to the network (including alarm center) when an alarm event occurs.
Page 197 Parameter Description Select to enable audio broadcast in response to a human face Voice Prompts detection event. Select the check box to activate a white light camera to trigger White Light white light alarm. Select the check box to activate an audio camera to trigger audio Siren alert Table 5-46...
Page 198 Figure 5-147 Figure 5-148 Local Configurations 182...
Page 199: Configuring Ivs Function
5.11.2.3 Playing the Detected Faces Step 1 On the displayed faces as shown in Figure 5-147, double-click on the face. The VIDEO interface is displayed. See Figure 5-149. Figure 5-149 Step 2 Click to start playing the recorded detected face. Step 3 Click Back to exit the playing interface and return to the faces displaying interface.
Page 200 Figure 5-150 Step 2 In the Channel list, select the channel number that you want to configure the IVS function. Step 3 Click Add. One line of rule is displayed. See Figure 5-151. Local Configurations 184...
Page 201 Figure 5-151 Step 4 Configure the parameters for the rule that you selected. Step 5 Select the check box of the rule to enable it. Step 6 Click Apply to complete the settings. 5.11.3.1.1 Configuring Tripwire Rules When the target object crosses the tripwire in the defined direction, the system activates alarms.
Page 202 Figure 5-152 Step 2 Draw a tripwire. In the Channel list, select the channel that you want to configure the rules for. Click The monitoring screen to configure the tripwire rules is displayed. See Figure 5-153 for analog camera and the IP camera without preset, and see Figure 5-154 for IP camera with preset.
Page 203 Figure 5-153 Figure 5-154 Configure the settings for the parameters of drawing rules. See Table 5-47. Parameter Description Name Enter the customized rule name. Set the direction of the tripwire. You can choose A to B (left to Direction right), B to A (right to left), and Both. Local Configurations 187...
Page 204 Parameter Description Click to draw areas to filter the target. You can configure two filtering targets (maximum size and Filtering Target minimum size). When the target that is crossing the tripwire is smaller than the minimum size or larger than the maximum size, no alarms will be activated.
Page 205 Parameter Description Click Setting to display setting interface. General Alarm: Enable alarm activation through the alarm  devices connected to the selected output port. Alarm Out External Alarm: Enable alarm activation through the  connected alarm box. Wireless Siren: Enable alarm activation through devices ...
Page 206 Parameter Description Select the check box to activate a buzzer noise at the Device when Buzzer an alarm event occurs. Select the check box to enable the Device to record a local alarm log when an alarm event occurs. Select the check box to enable audio broadcast in response to an Voice Prompts alarm event.
Page 207 Figure 5-156 Step 2 Draw an area. In the Channel list, select the channel that you want to configure the rules for. Click The monitoring screen to configure the intrusion rules is displayed. See Figure 5-157 for analog camera and the IP camera without preset, and see Figure 5-158 for IP camera with preset.
Page 208 Figure 5-157 Figure 5-158 Configure the settings for the parameters of drawing rules. See Table 5-49. Parameter Description Local Configurations 192...
Page 209 Parameter Description Name Enter the customized rule name. Configure the actions that are defined as intrusion. You can select Action the Appear check box and the Cross check box. In the Direction list, select the direction of crossing the configured Direction area.
Page 210 Figure 5-159 Step 2 Draw an area. In the Channel list, select the channel that you want to configure the rules for. Click The monitoring screen to configure the abandoned rules is displayed. See Figure 5-160 for analog camera and see Figure 5-161 for IP camera. Local Configurations 194...
Page 211 Figure 5-160 Figure 5-161 Configure the settings for the parameters of drawing rules. See Table 5-50. Parameter Description Local Configurations 195...
Page 212 Parameter Description Name Enter the customized rule name. Configure the minimum time period for activating alarms by Period detecting the abandoned objects. Click to draw areas to filter the target. You can configure two filtering targets (maximum size and Filtering Target minimum size).
Page 213 Figure 5-162 Step 2 Draw an area. In the Channel list, select the channel that you want to configure the rules for. Click The monitoring screen to configure the missing rules is displayed. See Figure 5-163 for analog camera and the IP camera without preset, and see Figure 5-164 for IP camera with preset.
Page 214 Figure 5-163 Figure 5-164 Configure the settings for the parameters of drawing rules. See Table 5-51. Parameter Description Local Configurations 198...
Page 215 Parameter Description Name Enter the customized rule name. Configure the minimum time period for activating alarms by Period detecting the missing objects. Click to draw areas to filter the target. You can configure two filtering targets (maximum size and Filtering Target minimum size).
Page 216 Figure 5-165 Step 1 Click SMART PLAN. The SMART PLAN interface is displayed. Step 2 In the Channel list, select the IP camera channel that you have configured the intelligent settings. For the IP camera with preset, see Figure 5-166. ...
Page 217 Figure 5-166 For the IP camera without preset, see Figure 5-167.  Figure 5-167 Step 3 Enable the IVS function. Local Configurations 201...
Page 218  For the IP camera with preset, do the following: In the Preset list, select 1_Preset1. All the presets that the IP camera has are displayed in the Preset list, and you just need to select the preset that you have configured the intelligent settings as shown in Figure 5-165.
Page 219 Figure 5-169 Step 2 In the Channel list, select the channel that you want to search for the events. Step 3 In the Type list, select the event type that you want to search. Step 4 In the Begin Time box and End Time box, enter the date and time. Step 5 Select the display mode of the search results by clicking Graph or List.
Page 220 Figure 5-170 Figure 5-171 Step 7 Double-click the video or click Local Configurations 204...
Page 221: Iot Function
The video playback interface is displayed. See Figure 5-172. Figure 5-172 Step 8 Click to play back the recorded video. Step 9 Click Back to stop the playback and return to the SMART SEARCH interface. Click Export to export the recorded video files. 5.12 IoT Function 5.12.1 Configuring Sensor Settings...
Page 222 Figure 5-173 Step 2 In the Access Type list, select USB Gateway. Step 3 Click Add. The Add interface is displayed. See Figure 5-174. Figure 5-174 Step 4 Click Pair. The Device starts pairing with the sensor. After pairing is completed, see Figure 5-175. Local Configurations 206...
Page 223 Figure 5-175 Step 5 Click Back to exit the pairing interface. The added sensor information is displayed. See Figure 5-176. Click to modify the sensor name; click to delete sensor information. Figure 5-176 Local Configurations 207...
Page 224 5.12.1.2 Connecting Sensor through Camera with Gateway Only the camera with gateway supports this function. Step 1 Select Main Menu > IoT > MANAGER > Sensor Pairing. The Sensor Pairing interface is displayed. See Figure 5-177. Figure 5-177 Step 2 In the Access Type list, select Camera Gateway.
Page 225 Figure 5-178 Step 5 Click Pair. The Device starts pairing with the sensor. After pairing is completed, see Figure 5-179. Figure 5-179 Step 6 Click Back to exit the pairing interface. The added sensor information is displayed. See Figure 5-180. Click to modify the sensor name;...
Page 226 Figure 5-180 5.12.1.3 Configuring Alarm Linkage Step 1 Select Main Menu > IoT > MANAGER > Wireless Detector. The Wireless Detector interface is displayed. See Figure 5-181. Local Configurations 210...
Page 227 Figure 5-181 Step 2 In the Access Type list, select USB Gateway, Camera Gateway, or All. When Access Type is Camera Gateway, you can select Channel to filter the status of present wireless detector. Step 3 Click The Setting interface is displayed. See Figure 5-182. Figure 5-182 Local Configurations 211...
Page 228 Step 4 Configure the settings for alarm linkage. For details, see Table 5-52. Parameter Description Name Enter the customized alarm name. Click Setting to display setting interface. Define a period during which the motion detection is active. For details, Period see "Setting Motion Detection Period"...
Page 229: Configuring Temperature And Humidity Camera
Parameter Description Show Message: Select the Show Message check box to enable a  pop-up message in your local host PC.  Buzzer: Select the check box to activate a buzzer noise at the Device.  Video Matrix: Select the check box to enable the function. When an alarm event occurs, the video output port outputs the settings configured in "Main Menu >...
Page 230 Figure 5-183 Step 2 Select the Enable check boxes to enable IoT function. See Figure 5-184. Figure 5-184 Local Configurations 214...
Page 231 The Device starts detecting the temperature and humidity data from the camera and display on the Realtime Display interface. 5.12.2.2 Viewing Temperature and Humidity Data You can view the temperature and humidity data on the REALTIME DISPLAY interface after the IoT function is enabled. In the Refresh Interval box, select data refresh interval.
Page 232 Figure 5-186 Step 3 Click Locked to lock the data. The export button is enabled. Step 4 Click Export. The system starts exporting the data. After exporting is finished, a Message dialog box is displayed. Step 5 Click OK. You can find the exported data on your USB device. 5.12.2.4 Configuring Alarm Linkage You can configure alarm linkage settings for temperature and humidity data.
Page 233 Figure 5-187 Step 2 On the temperature information line, click The Setting interface is displayed. See Figure 5-188. Figure 5-188 Step 3 Configure the settings for alarm linkage. See Table 5-53. Parameter Description Access Point Indicates the channel that the camera is connected to. Local Configurations 217...
Page 234 Parameter Description Type Temperature by default. Detect Position Set the detect position name. Name Select the channel that you want to preview to help monitor the channel of access point. This channel could be the channel of Preview Channel access point or any other channels according to your actual situation.
Page 235 Parameter Description Select the check box to enable a tour of the selected channels. Tour To use this function, make sure the tour is enabled and configured in Main Menu > DISPLAY > TOUR. Select to enable audio broadcast/voice prompts in response to a Voice Prompts temperature alarm event.
Page 236 Figure 5-189 Step 2 On the humidity information line, click The Setting interface is displayed. See Figure 5-190. Figure 5-190 Step 3 Configure the settings for the following parameters. See Table 5-54. Parameter Description Access Point Indicates the channel that the camera is connected to. Local Configurations 220...
Page 237 Parameter Description Type Humidity by default. Detect Position Set the detect position name. Name Select the channel that you want to preview to help monitor the channel of access point. This channel could be the channel of Preview Channel access point or any other channels according to your actual situation.
Page 238 Parameter Description Select the check box to enable a tour of the selected channels. Tour To use this function, make sure the tour is enabled and configured in Main Menu > DISPLAY > TOUR. Select to enable audio broadcast/voice prompts in response to a Voice Prompts temperature alarm event.
Page 239 Figure 5-191 Step 2 Configure the parameters settings. See Table 5-55. Parameter Description Access Point Indicates the channel that the camera is connected to. Display Type In the Display Type list, select List or Graph. Select the information type that you want to search. You can select Type Humidity or Temperature.
Page 240 Figure 5-192 For the data displayed in graph, see Figure 5-193.  Figure 5-193 Step 4 Click Backup. The system starts exporting the data. Local Configurations 224...
Page 241: Configuring Wireless Siren
After exporting is finished, a Message dialog box is displayed. Step 5 Click OK. You can find the exported data on your USB device. 5.12.3 Configuring Wireless Siren You can connect the wireless siren to the Device, when there is an alarm event activated on the Device, the wireless siren generate alarms.
Page 242: Configuring Pos Settings
5.13 Configuring POS Settings You can connect the Device to the POS (Point of Sale) machine and receive the information from it. This function applies to the scenarios such as supermarket POS machine. After connection is established, the Device can access the POS information and display the overlaid text in the channel window.
Page 243: Configuring Pos Settings
5.13.2 Configuring POS Settings Step 1 Select Main Menu > POS > POS SETUP. The POS SETUP interface is displayed. See Figure 5-196. Figure 5-196 Step 2 Configure the settings for the POS parameters. See Table 5-57. Parameter Description In the POS Name list, select the POS machine that you want to configures settings for.
Page 244 Parameter Description In the Connect Type list, select the connection protocol type. Click , the IP Address interface is displayed. Connect Type In the Source IP box, enter the IP address (the machine that is connected to the Device) that sends messages. Convert Select a character encoding mode.
Page 245: Configuring Backup Settings
5.14 Configuring Backup Settings 5.14.1 Finding USB Device When you inset a USB storage device into the USB port of the Device, the Device detects the USB storage device and pops up "Find USB device" interface, which provides you a shortcut to perform backup and upgrading operations.
Page 246 Figure 5-198 Step 2 Configure the settings for the backup parameters. See Table 5-58. Parameter Description In the Device Name list, select the device that you want to back up Device Name the files to. Click Format, the Format interface is displayed. If the capacity of external storage device is less than 2TB, you ...
Page 247: Network Management
Click Clear to remove all the searched results. 5.15 Network Management 5.15.1 Configuring Network Settings You can ensure the network interworking between the Device and other devices through configuring the network settings. 5.15.1.1 Configuring TCP/IP Settings You can configure the settings for the Device such as IP address, DNS according to the networking plan.
Page 248 The CONNECTION interface is displayed. See Figure 5-200. Figure 5-200 Step 2 Configure the settings for the connection parameters. See Table 5-59. The parameter setting can take effect without need to reboot the device. Parameter Description The allowable maximum clients accessing the Device at the same Max Connection time, such as WEB, Platform, and Mobile Phone.
Page 249 Step 3 Click Apply to complete the settings. 5.15.1.3 Configuring Wi-Fi Connection Settings You can make wireless connection between the Device and the other devices in the same network through Wi-Fi settings, facilitating the devices connection and mobility. Only the Device with Wi-Fi module supports this function. Step 1 Select Main Menu >...
Page 250 Step 3 Click Apply to complete the settings. After the Device is connected to a Wi-Fi hotspot, in the Wi-Fi Working Info area, the current hotspot, IP address, subnet mask, and default gateway are displayed. 5.15.1.4 Configuring 3G/4G Settings You can connect a wireless 3G/4G module to the USB port of the Device and then access the Device with the IP address provided by the module.
Page 251 Parameter Description Network Type Displays the network type. Different type represents different supplier. Displays the default APN number. Dial No. Displays the default dial No. AUTH Authentication mode. You can select PAP, CHAP, or NO_AUTH. Table 5-61 Step 4 Select the Enable check box. Step 5 Click Dial to start connecting.
Page 252  The Ethernet card names that are displayed on the 3G/4G interface are not constant, and they could be ppp5, ppp6, ppp7 or ppp8 and are different depending on the USB2.0 port on the Device that is connected to the 3G module. ...
Page 253 When the PPPoE function is enabled, the IP address on the TCP/IP interface cannot be modified. 5.15.1.6 Configuring DDNS Settings When the IP address of the Device changes frequently, the DDNS function can dynamically refresh the correspondence between the domain on DNS and the IP address, ensuring you access the Device by using the domain.
Page 254 Parameter Description Enable the DDNS function. Enable After enabling DDNS function, the third-party might collect your Device information. DDNS Type Type and address of DDNS service provider.  Type: Dyndns DDNS; address: members.dyndns.org Host IP  Type: NO-IP DDNS; address: dynupdate.no-ip.com ...
Page 255 Figure 5-206 Step 2 Configure the settings for the email parameters. See Table 5-64. Parameter Description Enable Enable the email function. SMTP Server Enter the address of SMTP server of sender’s email account. Enter the port value of SMTP server. The default value setting is Port 25.
Page 256 Parameter Description This is the interval that the system sends an email for the same type of alarm event, which means, the system does not send an email upon any alarm event. Interval (Sec.) This setting helps to avoid the large amount of emails caused by frequent alarm events.
Page 257 Figure 5-207 Step 2 Configure the settings for the UPnP parameters. See Table 5-65. Parameter Description Enable the UPnP function. Indicates the status of UPnP function. Status  Offline: Failed. Online: Succeeded.  Enter IP address of router on the LAN. LAN IP After mapping succeeded, the system obtains IP address automatically without performing any configurations.
Page 258 Parameter Description The settings in PAT table correspond to the UPnP PAT table on the router. Service Name: Name of network server.  Protocol: Type of protocol.  Int. Port: Internal port that is mapped on the Device.  Ext. Port: External port that is mapped on the router. ...
Page 259 Figure 5-208 Step 2 Configure the settings for the SNMP parameters. See Table 5-66. Parameter Description Enable Enable the SNMP function. Select the check box of SNMP version(s) that you are using. Version The default version is V3. There is a risk of select V1 or V2. SNMP Port Indicates the monitoring port on the agent program.
Page 260 Parameter Description In the Encryption Type list, select an encryption type. The default Encryption Type setting is CBC-DES. Table 5-66 Step 3 Compile the two MIB files by MIB Builder. Step 4 Run MG-SOFT MIB Browser to load in the module from compilation. Step 5 On the MG-SOFT MIB Browser, enter the Device IP that you want to manage, and then select the version number to query.
Page 261 Enter the port for the multicast. The port ranges from 1025 through Port 65000. Table 5-67 Step 3 Click Apply to complete the settings. You can use the multicast IP address to login the web. See Figure 5-210. On the web login dialog box, in the Type list, select MULTICAST. The web will automatically obtain the multicast IP address and join.
Page 262 Figure 5-211 Step 2 Configure the settings for the register parameters. See Table 5-68. Parameter Description Enable Enable the register function. Enter the server IP address or the server domain that you want to Server IP Address register to. Port Enter the port of the server.
Page 263 Figure 5-212 Step 2 Configure the settings for the alarm center parameters. See Table 5-69. Parameter Description Enable Enable the alarm center function. In the Protocol Type list, select protocol type. The default is Protocol Type ALARM CENTER. Host IP The IP address and communication port of the PC installed with Port alarm client.
Page 264 Figure 5-213 Figure 5-214 Step 2 Select the Ethernet card you want to certify. Step 3 Select Enable and configure parameters. See Table 5-70. Local Configurations 248...
Page 265: Configuring Network Testing Settings
Parameter Description PEAP: protected EAP protocol.  Authentication TLS: Transport Layer Security. Provide privacy and data integrity  between two communications application programs. Identity It can be configured when Authentication is TLS. CA Certificate Enable it and click Browse to import CA certificate from flash drive. Username The username shall be authorized at server.
Page 266 Step 2 In the Destination IP box, enter the IP address. Step 3 Click Test. After testing is completed, the test result is displayed. You can check the evaluation for average delay, packet loss, and network status. See Figure 5-216. Figure 5-216 5.15.2.2 Capturing Packet and Backing up Packet capture means the operations such as capturing, resending, and editing data that are...
Page 267 Figure 5-217 Step 2 Connect a USB storage device to the Device. Step 3 Click Refresh. The Device starts detecting the USB storage device and displays its name in the Device Name box. Step 4 Select the route of the data that you want to capture and back up. In the Network Sniffer Packet Backup area, click Browse.
Page 268 Figure 5-218 Select the route.  If there are several USB storage devices are connected to the Device, you can select from the Device Name list.  Click Refresh to total space, free space and the file list in the selected USB storage device.
Page 269: Configuring Account Settings
Figure 5-219 5.16 Configuring Account Settings You can add, modify and delete user accounts, groups, and ONVIF users, and set security questions for admin account. The user name supports 31 characters and group name supports 15 characters. The user  name can be consisted of letter, number, "_", "@", ".".
Page 270 Figure 5-220 Step 2 Click Add User. The Add User interface is displayed. See Figure 5-221. Figure 5-221 Step 3 Configure the settings for the parameters of adding a user account. See Table 5-71. Parameter Description User Name Enter a user name and password for the account. Password Confirm Password Re-enter the password.
Page 271 Parameter Description Optional. Memo Enter a description of the account. User MAC Enter user MAC address Select a group for the account. Group The user rights must be within the group permission. Click Set to display Set interface. Define a period during which the new account can login the device. Period The new account cannot login the device during the time beyond the set period.
Page 272  Define for several days of a week: Click before each day, the icon switches to . On the timeline of any selected day, click the half-hour blocks to select the active periods, all the days with will take the same settings. ...
Page 273 Figure 5-224 Step 2 Click for the user account that you want to modify. The Modify User interface is displayed. See Figure 5-225. Figure 5-225 Step 3 Change the settings for password, user name, user group, user MAC, memo, period, and authority.
Page 274 For the admin account, you can enter or modify email address, enable/disable the unlock pattern, modify the security questions. In the Email Address box, enter the email address, and the click Save to save the  setting. To use the unlock pattern, enable Unlock Pattern, click , draw a pattern in the ...
Page 275: Configuring Group Account
Figure 5-227 Step 2 Click for the user account that you want to delete. A Message is displayed. Step 3 Click OK to delete a user account. 5.16.2 Configuring Group Account 5.16.2.1 Adding a Group Step 1 Select Main Menu > ACCOUNT > GROUP. The GROUP interface is displayed.
Page 276 Figure 5-228 Step 2 Click Add Group. The Add Group interface is displayed. See Figure 5-229. Figure 5-229 Step 3 Configure the settings for the parameters of adding a group. See Table 5-72. Parameter Description Group Name Enter a name for the group. Optional.
Page 277 Parameter Description In the Authority area, select the check boxes in the System tab, Authority Playback tab, and Monitor tab. Table 5-72 Step 4 Click OK to complete the settings. 5.16.2.2 Modifying a Group Step 1 Select Main Menu > ACCOUNT > GROUP. The GROUP interface is displayed.
Page 278 Figure 5-231 Step 4 Change the settings for group name, memo, and authority. Step 5 Click OK to complete the settings. 5.16.2.3 Deleting a Group Step 1 Select Main Menu > ACCOUNT > GROUP. The GROUP interface is displayed. See Figure 5-232. Figure 5-232 Local Configurations 262...
Page 279: Configuring Onvif Users
Step 2 Click for the user account that you want to delete. A Message is displayed. Step 3 Click OK to delete a group. 5.16.3 Configuring ONVIF Users The device manufactured by other company can connect to the Device through ONVIF protocol by an authorized ONVIF account.
Page 280: Audio Management
Figure 5-234 Step 3 Enter user name, password, and select the group that you want this account to belong Step 4 Click OK to save the settings. Click to modify the account; Click to delete the account. 5.17 Audio Management Audio management function manages audio files and configures the playing schedule.
Page 281 Figure 5-235 Step 2 Click Add. The Add interface is displayed. See Figure 5-236. Figure 5-236 Step 3 Select the audio files that you want to import. Step 4 Click OK to start importing audio files from the USB storage device. Local Configurations 265...
Page 282: Configuring Playing Schedule For Audio Files
If the importing is successful, the audio files will display in the FILE MANAGER interface. See Figure 5-237. Figure 5-237 The imported audio files are automatically saved into the HDD, so you do not need to connect to the USB storage device to get the file next time. Click to play the audio file.
Page 283 Figure 5-238 Step 2 Configure the settings for the schedule parameters. See Table 5-73. Parameter Description In the Period box, enter the time. Select the check box to enable Period the settings. You can configure up to six periods. In the File Name list, select the audio file that you want to play for File Name this configured period.
Page 284: Storage Management
5.18 Storage Management Storage management function manages the stored resources such as recorded video files and storage space. The function aims at providing easier operation and improving the storage efficiency. 5.18.1 Configuring Basic Settings Step 1 Select Main Menu > STORAGE > BASIC. The BASIC interface is displayed.
Page 285: Configuring The Recording And Snapshot Schedule
5.18.2 Configuring the Recording and Snapshot Schedule The system starts recording and taking snapshot according to the configured schedule. For details, see "5.1.4.9 Configuring Recorded Video Storage Schedule" and "5.1.4.10 Configuring Snapshot Storage Schedule." 5.18.3 Configuring HDD Manager You can view the HDD information, format HDD, and configure the HDD type through HDD manager.
Page 286: Configuring Record
5.18.4 Configuring Record Record type includes auto and manual record. You can configure record type of main stream and sub stream. See "5.7 Configuring Record Settings". 5.18.5 Configuring Advance Settings Create HDD group, and save main stream, sub stream and snapshot of designated channels to the HDD group.
Page 287 Figure 5-242 Figure 5-243 Local Configurations 271...
Page 288: Configuring Quota
Figure 5-244 Step 4 Click Apply to complete the settings. 5.18.6 Configuring Quota By configuring quota, allocate fixed storage capacity to each channel, and distribute the storage space of each channel reasonably.  If the interface displays that "Current HDD Mode is HDD Group", click "Change to Quota Mode", and then configure quota.
Page 289 Figure 5-245 Step 2 Select the channels you want to configure, and select quota from the drop-down list of corresponding HDD. Step 3 Click Apply to complete the settings. Click Statistics to view the quota of each channel in HDD. See Figure 5-246. Figure 5-246 Local Configurations 273...
Page 290: Configuring Hdd Detecting Settings
5.18.7 Configuring HDD Detecting Settings Not all models support this function. HDD detecting function detects the current status of HDD to let you know the HDD performance and replace the defective HDD. 5.18.7.1 Detecting HDD You can detect HDD by key area detect and global detect. Key area detect: Detect the files saved in HDD.
Page 291 Figure 5-248 5.18.7.2 View Detecting Results After the detecting is completed, you can view the detecting reports to find out the problem and replace the defective HDD to avoid data loss. Step 1 Select Main Menu > STORAGE > HDD DETECT > Report. The Report interface is displayed.
Page 292 Figure 5-249 Step 2 Click The Details interface is displayed. You can view detecting results and S.M.A.R.T reports. See Figure 5-250 and Figure 5-251. Figure 5-250 Local Configurations 276...
Page 293: Configuring Record Estimate
Figure 5-251 5.18.8 Configuring Record Estimate Record estimate function can calculate how long you can record video according to the HDD capacity, and calculate the required HDD capacity according to the record period. Step 1 Select Main Menu > STORAGE > REC ESTIMATE. The REC ESTIMATE interface is displayed.
Page 294 Step 2 Click The Edit dialog box is displayed. See Figure 5-253. You can configure the resolution, frame rate, bit rate and record time for the selected channel. Figure 5-253 Step 3 Click OK to save the settings. Then the system will calculate the time period that can be used for storage according to the channels settings and HDD capacity.
Page 295: Configuring Ftp Storage Settings
Calculating HDD Capacity for Storage Step 1 On the REC ESTIMATE interface, click the Known Time tab. The Known Time interface is displayed. See Figure 5-256. Figure 5-256 Step 2 In the Time box, enter the time period that you want to record. In the Capacity box, the required HDD capacity is displayed.
Page 296 Figure 5-258 Step 2 Configure the settings for the FTP settings parameters. See Table 5-75. Parameter Description Enable Enable the FTP upload function. Select FTP type. FTP type  FTP: Plaintext transmission. SFTP: Encrypted transmission (recommended)  Server IP address of FTP server. FTP: The default is 21.
Page 297: Configuring System Settings
Parameter Description Enter the length of the uploaded recorded video. If the entered length is less than the recorded video length,  only a section of the recorded video can be uploaded. File Length(M) If the entered length is more than the recorded video length, ...
Page 298 Figure 5-259 Step 2 Click Add a Holiday. The Add a Holiday interface is displayed. See Figure 5-260. Figure 5-260 Step 3 Configure the holiday name, repeat mode, time range according to your actual situation. Step 4 Click Add. The added holiday information is displayed. See Figure 5-261. Enable the Add More function, so you can continue adding holiday information.
Page 299: Configuring Rs232 Settings
Figure 5-261 5.19.2 Configuring RS232 Settings You can configure serial port function, Baud rate and so on. Only some series products support this RS232. Select Main Menu > SYSTEM > RS232. The RS232 interface is displayed. See Figure 5-262. Local Configurations 283...
Page 300: Configuring Security Settings
Figure 5-262 Parameter Description Select serial port control protocol.  Console: Upgrade the program and debug with the console and mini terminal software.  Keyboard: Control this Device with special keyboard.  Adapter: Connect with directly transparent Function transmission of data. ...
Page 301 5.19.3.1 Configuring Firewall Step 1 Select Main Menu > SYSTEM > SECURITY > Firewall. The Firewall interface is displayed. See Figure 5-263. Figure 5-263 Step 2 Select Enable to enable function in the Type list. Step 3 Configure the parameters. See Table 5-77. Parameter Description In the Type list, you can select Network Access, Sync...
Page 302 End Port When Type is IP Address, they can be configured. Start Port and End Port can be configured only in Network Access Type. Start Address Enter Start Address and End Address of IP Segment. End Address When Type is IP Segment, they can be configured. Enter MAC Address that is allowed or forbidden.
Page 303: Configuring System Maintenance Settings
Parameter Description If you enable this function, the snapshots that are activated by the alarm event on the Device can be sent to mobile Mobile Phone Push phone. This function is enabled by default. If this function is enabled, the remote devices can be added through the CGI protocol.
Page 304: Exporting And Importing System Settings
Figure 5-265 Step 2 Configure the settings for the system maintenance parameters. See Table 5-79. Parameter Description Auto Reboot In the Auto Reboot list, select the reboot time. In the Case Fan Mode list, you can select Always run or Auto. If you select Auto, the case fan will stop or start according to the external conditions such as the Device temperature.
Page 305 Exporting System Settings Step 1 Select Main Menu > SYSTEM > IMP/EXP. The IMP/EXP interface is displayed. See Figure 5-266. Figure 5-266 Step 2 Insert a USB storage device into one of the USB ports on the Device. Step 3 Click Refresh to refresh the interface.
Page 306: Restoring Default Settings
Figure 5-267 Step 4 Click Export. There is a folder under the name style of "Config_[YYYYMMDDhhmmss]". Double-click this folder to view the backup files. Importing System Settings Step 1 Insert a USB storage device containing the exported configuration files from another Device) into one of the USB ports on the Device.
Page 307: Upgrading The Device
Figure 5-268 Step 2 Restore the settings.  Select the settings that you want to restore, and then click Apply. The system starts restoring the selected settings. Click Factory Default, and then click OK. The system starts restoring the whole ...
Page 308 Figure 5-269 Step 3 Click System Upgrade. The System Upgrade interface is displayed. See Figure 5-270. Figure 5-270 Step 4 Click the file that you want to upgrade. The selected file is displayed in the Update File box. Step 5 Click Start.
Page 309 5.19.7.2 Performing Online Upgrade When the Device is connected to Internet, you can use online upgrade function to upgrade the system. Before using this function, you need to check whether there is any new version by auto check or manual check. Auto check: The Device checks if there is any new version available at intervals.
Page 310: Viewing Information
Figure 5-272 Step 3 Click Upgrade now. 5.19.7.3 Uboot Upgrading Under the root directory in the USB storage device, there must be "u-boot.bin.img" file and  "update.img" file saved, and the USB storage device must be in FAT32 format. Make sure the USB storage device is inserted; otherwise the upgrading cannot be ...
Page 311: Viewing Log Information
Figure 5-273 5.20.2 Viewing Log Information You can view and search the log information. If there is no HDD installed, the system can save up to 10,000 logs.  If there is HDD installed and has been formatted, the system can save up to 500,000 logs. ...
Page 312 Figure 5-274 Step 2 In the Type list, select the log type that you want to view (System, Config, Storage, Record, Account, Clear, Playback, and Connection) or select All to view all logs. Step 3 In the Start Time box and End Time box, enter the time period to search, and then click Search.
Page 313: Viewing Event Information
Figure 5-275  Click Details or double-click the log that you want to view, the Detailed Information interface is displayed. Click Next or Previous to view more log information. Click Backup to back up the logs into the USB storage device. ...
Page 314: Viewing Network Information
Figure 5-276 5.20.4 Viewing Network Information You can view the online users, network data transmission details, and test network. For details about testing network, see "5.15.2.1 Testing the Network." 5.20.4.1 Viewing Online Users You can view the online user information and block any user for a period of time. Select Main Menu >...
Page 315 Figure 5-277 To block an online user, click and then enter the time that you want to block this user. The maximum value you can set is 65535. The system detects every 5 seconds to check whether there is any user added or deleted, and update the user list timely.
Page 316: Viewing Hdd Information
Figure 5-278 Step 2 Click the LAN name that you want to view, for example, LAN1. The system displays the information of data sending speed and receiving speed. The default display is LAN1 load.  Only one LAN load can be displayed at one time. ...
Page 317: Viewing Channel Information
Figure 5-279 Parameter Description Indicates the number of the currently connected HDD. The asterisk (*) means the current working HDD. Device Name Indicates name of HDD. Physical Position Indicates installation position of HDD. Type Indicates HDD type. Total Space Indicates the total capacity of HDD. Free Space Indicates the usable capacity of HDD.
Page 318: Viewing Data Stream Information
Figure 5-280 5.20.7 Viewing Data Stream Information You can view the real-time data stream rate and resolution of each channel. Select Main Menu > INFO > BPS, the BPS interface is displayed. See Figure 5-281. Local Configurations 302...
Page 319: Viewing Device Status
Figure 5-281 5.20.8 Viewing Device Status Not all models support this function. You can view the information about device status. Step 1 Select Main Menu > ALARM > ABNORMALITY > Device. The Device interface is displayed. See Figure 5-282. Local Configurations 303...
Page 320 Figure 5-282 Step 2 Select Battery Low Space for Event Type, tick the switch behind Enable, and then click Apply. Step 3 Select Main Menu > INFO > DEVICE STATUS. The DEVICE STATUS interface is displayed. See Figure 5-283. Local Configurations 304...
Page 321: Viewing Poc Information
Figure 5-283 Status Battery Charging Above 60% 30%–60% Below 30% Charging Capacity completed Table 5-81 5.20.9 Viewing PoC Information Not all models support this function. You can view the information about PoC camera, such as quantity, mode, and power consumption. Select Main Menu >...
Page 322: Logout The Device
Table 5-82 5.21 Logout the Device On the top right of the Main Menu interface or on any interface after you have entered the Main Menu, click Select Logout, you will log out the device.  Select Reboot, the Device will be rebooted. ...
Page 323: Web Operations
Web Operations The interfaces in the Manual are used for introducing the operations and only for reference.  The actual interface might be different dependent on the model you purchased. If there is inconsistency between the Manual and the actual product, the actual product shall govern. The Manual is a general document for introducing the product, so there might be some ...
Page 324: Resetting Password
Figure 6-1 Step 2 Enter the user name and password. The default administrator account is admin. The password is the one that was  configured during initial settings. To security your account, it is recommended to keep the password properly and change it regularly. ...
Page 325 Figure 6-2 Step 2 Click Forgot Password. The Reset Password interface is displayed. See Figure 6-4. Figure 6-3 Step 3 Click OK. The reset type interface is displayed. See Figure 6-4. Web Operations 309...
Page 326 Figure 6-4 Step 4 Follow the onscreen instructions to scan the QR code and get the security code. You can get the security code twice by scanning the same QR code. If you need to  get the security code once again, please refresh the interface. Please use the security code received in your email box to reset the password ...
Page 327 Figure 6-5 Step 7 In the Password box, enter the new password and enter it again in the Confirm Password box. The new password can be set from 8 characters through 32 characters and contains at least two types from number, letter and special characters (excluding"'", """, ";", ":" and "&").
Page 328: Introducing Web Main Menu
Introducing Web Main Menu After you have logged in the Web, the main menu is displayed. See Figure 6-6. For detailed operations, you can refer to "5 Local Configurations." Figure 6-6 Icon Description Includes configuration menu through which you can configure camera settings, network settings, storage settings, system settings, account settings, and view information.
Page 329 Icon Description Displays Cell Phone Client and Device SN QR Code. Cell Phone Client: Use your mobile phone to scan the QR code to add  the device into the Cell Phone Client, and then you can start accessing the Device from your cell phone. Device SN: Obtain the Device SN by scanning the QR code.
Page 330: Faq
1. DVR cannot boot up properly. There are following possibilities: Input power is not correct.  Power connection is not correct.  Power switch button is damaged.  Program upgrade is wrong.   HDD malfunction or something wrong with HDD jumper configuration. Seagate DB35.1，...
Page 331 There are following possibilities:  HDD jumper is damaged.  HDD is broken.  Upgraded program is not compatible.  The recorded file has been overwritten.  Record function has been disabled. 7. Video is distorted when searching local records. There are following possibilities: Video quality setup is too low.
Page 332  Sensitivity is too low.  For some versions, there is hardware limit. 13. Cannot log in client-end or web. There are following possibilities: For Windows 98 or Windows ME user, please update your system to Windows 2000 sp4.  Or you can install client-end software of lower version.
Page 333  Some program versions might have this problem. Please upgrade your system. 19. Alarm function is null. There are following possibilities: Alarm setup is not correct.  Alarm cable connection is not correct.  Alarm input signal is not correct. ...
Page 334  For the product supports analog standard definition camera/HD camera, you need to go to the Main Menu > CAMERA > CHANNEL TYPE to select corresponding channel type and then restart the DVR. 29. I cannot connect to the IP channel. There are following possibilities: Check the camera is online or not.
Page 335  Check the device P2P function is enabled or not. (Main menu->Setting->Network->P2P)  Check the device is in the WAN or not.  Check cell phone P2P login mode is right or not.  It is the specified device P2P login port or not when you are using P2P client. ...
Page 336: Glossary
Appendix 1 Glossary The abbreviations in this glossary are related to the Manual. Abbreviations Full term Bayonet Nut Connector Constant Bit Rate Common Intermediate Format DDNS Dynamic Domain Name Service DHCP Dynamic Host Configuration Protocol Domain Name System Daylight Saving Time Digital Video Recorder File Transfer Protocol Hard Disk Drive...
Page 337 Abbreviations Full term Video Graphics Array Wide Area Network Glossary 321...
Page 338: Appendix 2 Hdd Capacity Calculation
Appendix 2 HDD Capacity Calculation Calculate total capacity needed by each DVR according to video recording (video recording type and video file storage time). Step 1 According to Formula (1) to calculate storage capacity that is the capacity of each channel needed for each hour, unit MB.
Page 339 Bit stream size（max） File size Bit stream size（max） File size 640Kbps 281MB 768Kbps 337MB 896Kbps 393MB 1024Kbps 450MB 1280Kbps 562MB 1536Kbps 675MB 1792Kbps 787MB 2048Kbps 900MB HDD Capacity Calculation 323...
Page 340: Appendix 3 Compatible Backup Devices
Appendix 3 Compatible Backup Devices Appendix 3.1 Compatible USB list Manufacturer Model Capacity Sandisk Cruzer Micro 512MB Sandisk Cruzer Micro Sandisk Cruzer Micro Sandisk Cruzer Freedom 256MB Sandisk Cruzer Freedom 512MB Sandisk Cruzer Freedom Sandisk Cruzer Freedom DataTraveler Ⅱ Kingston DataTraveler Ⅱ...
Page 341: Appendix 3.2 Compatible Sd Card List
Manufacturer Model Capacity Kingston Data Traveler Kingston Data Traveler 16GB Kingston Data Traveler 32GB Aigo L8315 16GB Sandisk 16GB Kingston Data Traveler Locker+ 32GB Netac U228 Appendix 3.2 Compatible SD Card list Manufacturer Standard Capacity Card type Transcend SDHC6 16GB Kingston SDHC4 Kingston...
Page 342: Appendix 3.6 Compatible Sata Hdd List
Manufacturer Model Samsung TS-H653 Ver.A Samsung TS-H653 Ver.F Samsung SH-224BB/CHXH SONY DRU-V200S SONY DRU-845S SONY AW-G170S Pioneer DVR-217CH Appendix 3.6 Compatible SATA HDD List Please upgrade the DVR firmware to latest version to ensure the accuracy of the table below. Here we recommend HDD of 500GB to 4TB capacity.
Page 343 Manufacturer Series Model Capacity Port Mode Seagate SkyHawk HDD ST100000VX0004 10TB SATA Seagate SkyHawk HDD ST1000VX003 SATA (Support HDD data recovery offered by Seagate) Seagate (Support HDD data ST2000VX005 SATA recovery offered by Seagate) Seagate (Support HDD data ST3000VX005 SATA recovery offered by Seagate) Seagate...
Page 344 Manufacturer Series Model Capacity Port Mode TOSHIBA Mars DT01ABA300V SATA TOSHIBA Sonance MD03ACA200V SATA TOSHIBA Sonance MD03ACA300V SATA TOSHIBA Sonance MD03ACA400V SATA TOSHIBA Sonance MD04ABA400V SATA TOSHIBA Sonance MD04ABA500V SATA Seagate Constellation ES series ST1000NM0033 SATA (SATA interface) Seagate Constellation ES series ST2000NM0033 SATA (SATA interface)
Page 345 Manufacturer Series Model Capacity Port Mode Seagate Constellation ES series ST2000NM0045 SATA (SAS interface) Seagate Constellation ES series ST3000NM0025 SATA (SAS interface) Seagate Constellation ES series ST4000NM0025 SATA (SAS interface) Seagate Constellation ES series ST6000NM0095 SATA (SAS interface) Seagate Constellation ES series ST6000NM0034 SATA (SAS interface)
Page 346 Manufacturer Series Model Capacity Port Mode HITACHI Ultrastar series (SAS HUS726060AL5210 SATA interface) Seagate Pipeline HD Mini ST320VT000 320GB SATA Seagate Pipeline HD Mini ST500VT000 500GB SATA Seagate Pipeline HD Mini ST2000LM003 (EOL) SATA TOSHIBA 2.5-inch PC series MQ01ABD050V 500GB SATA TOSHIBA 2.5-inch PC series...
Page 347: Appendix 4 Compatible Cd/Dvd Burner List
Appendix 4 Compatible CD/DVD Burner List Please upgrade the DVR firmware to latest version to ensure the accuracy of the table below. And you can use the USB cable with the model recommended to set USB burner. Manufacturer Model Port Type Type Sony DRX-S50U...
Page 348: Appendix 5 Compatible Displayer List
Appendix 5 Compatible Displayer List Please refer to the following table form compatible displayer list. Brand Model Dimension (Unit: inch) BENQ (LCD) ET-0007-TA 19-inch (wide screen) DELL (LCD) E178FPc 17-inch BENQ (LCD) Q7T4 17-inch BENQ (LCD) Q7T3 17-inch HFNOVO (LCD) LXB-L17C 17-inch SANGSUNG (LCD)
Page 349: Appendix 6 Compatible Switcher
Appendix 6 Compatible Switcher Brand Model network working mode D-LinK DES-1016D 10/100M self-adaptive D-LinK DES-1008D 10/100M self-adaptive Five network modes: AUTO  HALF-10M  Ruijie RG-S1926S FULL-10M  HALF-100M   FULL-100M H3C-S1024 10/100M self-adaptive TP-LINK TL-SF1016 10/100M self-adaptive TP-LINK TL-SF1008+ 10/100M self-adaptive Compatible Switcher 333...
Page 350: Appendix 7 Earthing
Appendix 7 Earthing Appendix 7.1 What Is the Surge Surge is a short current or voltage change during a very short time. In the circuit, it lasts for microsecond. In a 220V circuit, the 5KV or 10KV voltage change during a very short time (about microseconds) can be called a surge.
Page 351: Appendix 7.2 The Earthing Modes
arrestor with the signal port, it can cut the channel of the thunderstorm to the device, and on the other hand, it can discharge the current to the ground to guarantee the device proper work. The signal lightning arrester has many specifications, and widely used in many devices such as telephone, network, analog communication, digital communication, cable TV and satellite antenna.
Page 352: Appendix 7.3 Thunder Proof Ground Method In The Monitor System
Mixed ground: The mix ground consists of the feature of the one-point ground and  multiple-point ground. For example, the power in the system needs to use the one-point ground mode while the radio frequency signal requires the multiple-point ground. So, you can use the following figure to earth.
Page 353: Appendix 7.4 The Shortcut Way To Check The Electric System By Digital Multimeter
more than 4mm  The monitor system usually can adopt the one-point ground.  Please connect the ground end of 3-pin socket in the monitor system to the ground port of the system (protection ground cable) Appendix 7.4 The Shortcut Way to Check the Electric System by Digital Multimeter For 220V AC socket, from the top to the bottom, E (ground cable), N (neutral cable), L(live cable).
Page 354 For L (live cable) Turn the digital multimeter to 750V AC, use your one hand to hold the metal end, and then the other hand insert the pen to the L port of the socket. See the following figure. If the multimeter shows 125, then you can see current live cable connection is standard.
Page 355 Earthing 339...
Page 356: Appendix 8 Rj45-Rs-232 Connection Cable Definition
Appendix 8 RJ45-RS-232 Connection Cable Definition Here we are going to make standard RS-232 port and standard RJ45 (T568B). Please refer to the following figure for RJ45 cable definition. Please refer to the following figure for RS-232 pin definition. Cross Connection Please refer to the following figure for connection information.
Page 357 Please refer to the following table for straight connection information. RJ45 (T568B) RJ45 (Network cable) RS-232 Signal Description Blue White and blue White and green Dahua Technology USA 23 Hubble Irvine, CA 92618 Tel: (949) 679-7777 Fax: (949) 679-5760 Support: 877-606-1590 Sales: sales.usa@dahuatech.com Support: support.usa@dahuatech.com...

This manual is also suitable for:

Xvr4 series Xvr5 series Xvr7 series Dh-xvr1b04 Dh-xvr1b04h Dh-xvr1b08 ... Show all

Dahua Technology XVR Cooper Series User Manual

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Dahua Technology XVR Cooper Series

Summary of Contents for Dahua Technology XVR Cooper Series

This manual is also suitable for:

Table of Contents
