Everpure MRS-600HE Installation And Operation Manual

IntroductIon
The Everpure MRS-600HE Mineral Reduction System is a pre-
engineered, pre-assembled Reverse Osmosis (RO) system designed
to provide high purity water for multiple applications, such as
premium espresso, coffee, blended beverages and steam, to name a
few. It combines a number of water treatment technologies into one
easy to install package. The system provides superior protection
against taste and odor causing contaminants while removing dirt,
particulates and dissolved solids that can foul or scale equipment.
Initial System Production
Water production depends on supply water pressure and temperature.
See PERFORMANCE section (page 9) for normalized production.
Influent Water characteristics
The following table lists the allowable operating range of various
water properties within which the MRS-600HE will function
properly.
Total Dissolved Solids (TDS)
pH
Chlorine
1
Chloramines
Turbidity
Iron
Reverse osmosis membrane filter used in this system will be damaged by chlorine. An
1
activated carbon filter should be provided with this system to protect the reverse osmosis
membrane from chlorine attack. Influent chlorine should not exceed 3 mg/I.
the system consists of 5 major components:
1. 2SR-BW Water Conditioning cartridge
2. Dual-Head booster pump
3. MR-600 Reverse Osmosis (RO) membrane cartridge.
4. 6-Gallon (22.7 l) RO Water Storage Tank
5. Control System with Power Supply
The 2SR-BW water conditioning cartridge contains media that
reduces the scaling tendency of hard water minerals found in many
water supplies, extending RO membrane life.
The Dual-Head booster pump increases the inlet pressure to
maintain consistent permeate production, plus eliminates back-
pressure on the permeate output. This innovative approach to
both boosting and eliminating back-pressure maximizes system
efficiency.
The MR-600 RO membrane cartridge contains a semi-permeable
reverse osmosis membrane. It's here that most of the dissolved
impurities are separated from the water and flushed down the drain.
The water that is able to pass through the membrane, which is very
low in dissolved impurities, is referred to as permeate, RO water, or
product water.
Once the RO water is produced, it is stored in the 6-Gallon (22.7
l) RO water storage tank. This tank serves two key functions; 1) it
acts as a buffer between the system and the connected equipment,
providing ample volumes of water instantaneously, 2) it reduces
the on-off cycling of the RO system, which produces better quality
water, and prolongs the system's life.
.
Installation and Operation Guide
0-1,000 ppm (0-1,000 mg/l)
5-10
0-3 ppm (0-3 mg/I)
0-3 ppm (0-3 mg/I)
0-1 NTU
0-1 ppm (0-1 mg/I)
MRS-600HE High Efficiency Reverse Osmosis System
Mineral Reduction System For Foodservice Applications
oPeratIng SPecIfIcatIonS
• Dynamic Operating Pressure: 25-80 psi (1.7-5.5 bar)
[Pressure below 50 psi (3.4 bar) may affect blend system performance]
• Static Operating Pressure: 100 psi (6.9 bar)
• Operating Temperature: 40-100°F (4.4-37.8°C)
• Plumbing Connections:
Inlet/Outlet: 3/8" (9.5 mm) OD tube ("push-in" quick-connect),
3/8" (9.5 mm) barb or 1/2" (12.7 mm) barb
Reject: 3/8" (9.5 mm) OD tube ("push-in" quick-connect)
Tank Drain: 3/8" (9.5 mm) OD tube ("push-in" quick-connect)
• Electrical:
Rated Voltage & Power Cord Plug Type:
Sys. Part No. EV997038: 100-120VAC/50-60Hz - NEMA 5-15P
Sys. Part No. EV997044: 220-240VAC/50-60Hz - GB 2099
Sys. Part No. EV997047: 220-240VAC/50-60Hz - CEE 7/7 -
Sys. Part No. EV997050: 220-240VAC/50-60Hz - AS 3112
Watts:
Stand-by: 25 // Flush: 60 // Run/Fill: 320
Branch Circuit Protection:
10 AMP Minimum. To minimize personnel shock hazards,
install on a GFI, RCD, or equivalent protected circuit.
Pre-Installation checklist
1. Can the unit be mounted within a reasonable distance of the
water supply and drain facilities?
2. Is there an un-switched receptacle available for powering the
system?
3. Is there adequate clearance and support to install the unit
and permit access for maintenance? The total system weight
will vary based on model and storage tank selected. See
specification table for approximate operating weights.
4. Doe s the inlet water supply meet the requirements listed in the
table under "Influent Water Characteristics"?
5. Is there a minimum of 25 psi (1.7 bar) pressure on a consistent basis?
EV3128-25 Rev C MY10
