  • Page 1 User Manual Garment Steamer MY-GJ15B2W READ AND SAVE THESE INSTRUCTIONS Attention: Pictures in the IM are for reference only.

  • Page 2: Safety Cautions

    Safety Cautions Before using, please read the Safety Cautions completely, and use the appliance in accordance with the requirements to avoid any injury or damage of properties. WARNING Never use this appliance for any purpose other than ironing clothes. Never use other high-power electric appliance on the same socket to avoid overload of circuits.
  • Page 3 Safety Cautions WARNING When the garment steamer is operating, its ironing head, steam duct and steam duct joint will become very hot. Therefore, never touch them to avoid scald. When the garment steamer is operating, it may produce steam of high temperature, which may cause deformation and discoloration of cloths with poor heat resistance (such as fur clothing).

  • Page 4: Component Description

    Safety Cautions CAUTIONS To prevent the hose from forming a U-shape,always place the steamer on the floor to ensure that the hose is straight. If you hear an excessive croaking sound or if the steam output is irregular, lift the steamer head from time to time to straighten the hose.

  • Page 5: Parts Descriptions

    Component Description Parts Descriptions Drain plug Trousers seam clip Brush Ironing board Gloves (The schematic above is for reference only, and the actual product shall be based.) Warm Tips: It is recommended to use purified water or filtered water, which makes the Garment Steamer more durable.
  • Page 6 Installation Instructions Hanger assembly conduit Insert 插入 Insert the upper end of hanger assembly into the slot of steamer headstock. Installation of the steam conduit 2.Rotate the fastener clockwise, 1.Align the boss of windpipe and lock by aligning the boss fastener with the “...
  • Page 7 Instructions for use Preparations 3.Replace the water tank, 1.Hang the clothes 2.Fill in the water tank. requiring for and power on. ironing. Knob type control 1. Rotate the knob clockwise, and start the machine. 2.Choose different functions by adjusting the knob. 3.The stream reaches maximum on “3”...
  • Page 8 Ironing method Common ironing Ironing board can be used as an auxiliary tool for ironing corners such as collars, cuffs. Wear gloves or glove boards to prevent from being scalded. A brush can be used for removing the fluffing. Warm tips: Do not iron one place for a long time, so as not to damage the clothes.
  • Page 9 Ironing method Trousers ironing Trousers seam clip can be used to help iron crease or axis. Use clamping piece or clip to fix trousers or clothes. Install the trousers seam clip. Clamp the crease or axis with the trousers seam clip, and slowly move down while ironing.

  • Page 10: Basic Parameters

    Basic parameters Product name Garment steamer Model MY-GJ15B2W 220-240V~ voltage frequency 50/60Hz power 1500-1785W Water tank capacity 1.5L Weight 3.0kg 292X255X1600mm Dimensions(DxWxH) Safety Protection 1. Temperature detection protection: The Garment Steamer is equipped with a built-in temperature sensing element. When there is abnormal temperature,...

  • Page 11: Circuit Diagram

    Circuit Diagram Input power 220-240V 50Hz Line set Line set Switch assembly Thermal fuse Heating body working indicator light Line set Temperature controller Troubleshooting Phenomenon Cause Troubleshooting The power plug is not inserted. Insert the power plug. The domestic circuit fails or the Please contact the professionals for The product does not fuse is burnt.
  • Page 12 When the steam conduit is in the In use, lift the hot head and vertically U-shaped state, the steam straighten the steam conduit, and condenses in the steam conduit. shake the hot head. In operation, there is a "grunt" sound. The product is placed on a high table, for example, on a table or a Place the product on the ground.
  • Page 13 MY-GJ15B2W 使用本産品前，請仔細閱讀本說明書 ，並妥善保存以借日後參考查閱。 注：此說明書內圖片只供參考。...
  • Page 14 超 觸摸不到 觸電 刮...
  • Page 15 所 此 本電器禁止與常規家用垃圾一起進行處理。在使用壽命結束時， 本電器必須放在電器和電子設備的回收點。通過對舊電器的收集 和回收，你爲自然資源的保護做出了重要貢獻，並且對環境進行 了無害和環保的處理。...
  • Page 19 掛...
  • Page 20 示 害...
  • Page 21 於 於...
  • Page 22 MY-GJ15B2W 220-240V~ 50/60Hz 1500-1785 （深闊高） 292X255X1600 3.防幹燒保護 當整機幹燒時會有缺水警告並且自動斷電。當水泵在幹燒時，警告蜂 鳴器會立即啟動。同時，整機會在指示器閃爍三次之後自動斷電以保 護機器。 下 於適當的位置。...
  • Page 23 電氣原理圖 輸入電源 220-240V 50Hz 熱熔斷器 線組 線組 開關組件 發熱體 工作指示燈 線組 溫控器 異常現象檢查 現 象 原 因 排除方法 未插電源插頭。 插上電源插頭。 開機後産品 家庭電路故障或保險 不工作 請專業人員檢查、維修。 絲燒斷。 産品電路故障 請專業人員檢查、維修。 水箱沒水或水太少。 給水箱加水。 開機後産品工 內部蒸汽通道彎折或脫開。 請專業人員檢查、維修。 作，但沒有蒸 發熱盤損壞。 汽出 請專業人員檢查、維修。 指示燈亮，不出蒸汽。 請專業人員檢查、維修。 使用時，提起燙頭垂直拉直 蒸汽冷凝，屬正常現象。 導氣管，並抖動燙頭幾下...
  • Page 24 除燙頭處外， 重新檢查安裝是否到位。 導氣管未安裝到位。 其他部位有出 請專業人員檢查、維修。 密封損壞。 汽現象 遙控器不能使 電池沒電，更換電池； 用（僅限有遙 遙控器不能使用。 將遙控器底部透明膠片去掉。 控器的型號） 待供電電壓正常後可自動恢 開機後檔位燈 電壓過高或過低保護。 複加熱。 閃爍 開機1分鍾後此功能不響 應。 智感控汽異常 非正常離手或握手操作。 重新正常操作即可。 （離手不斷汽 電磁環境幹擾。 更換電池。 或握手不出汽） 正常安裝好遙控盒。 電池沒電。 遙控盒沒裝上手柄。...
