Page 11
All the content in the manual have been checked carefully. If there are any errors in printing or misunderstanding in the content, please contact Midea customer service center. Note: Where there is a technical improvement on the product, it will be included in the new edition of the manual.
Safety Instructions • Do not put the steam mop close to the heat source, radiation source or burning cigarette. • Keep the appliance away from the reach of children when it is operating or cooling down. • The appliance shall not be left unattended while it is connected to the power source.
Functional Operation Safety instructions and precautions! • represent that there will be steam sprayed. Caution! Hot. • Do not dismantle the machine unless it is done by professionals. Do not dismantle the machine while it is in use, otherwise it may cause injury.
Page 15
1-3. Put the sealing plug back to water tank, as shown in Figure 3; 1-4. Put the water tank back to the main body, as shown in Figure 4. Figure 3 Figure 4 Use in mop state Attention! Check and make sure that the water tank has been filled with appropriate amount of purified water.
Page 16
2-2. Install mopping nozzle: Note: When machine is applied to hard floor or carpet, please install the mopping nozzle and mop cloth firstly. Installing mop cloth: Attach the mop cloth to the bottom of mop, as shown in Figure 6; Figure 6 2-3.
Page 17
3) Use in handheld state 3-1. Hose Mode: Install the hose and straight nozzle: Align the notch of the hose with the button in the front of main body. a. When you hear a “click” sound, it is installed in place. Note: If you don't hear a “click”...
Page 18
3-3. Install accessories (hanging ironing head, brush head, small scraper, scouring head, etc.): Align the sliding notch on the accessory with the latch on the straight nozzle and push in. Then rotate the accessory until the latch enters the notch, which indicates it is installed in place, as shown in Figure 12, Figure 13.
2. After the machine is work. water tank causes the completely cooled down, boiler to dry burn, thus refill purified water activating the protective regularly. measure. Product specification Model Rated Voltage Frequency Power Product size (WxHxD) Net Weight VCS2 220-240V~ 50-60Hz 1400W 310x1080x200mm 2.1kg...
