Setup > Screen
Overview
Modify screen settings and display behavior
1. The screen behavior can be set to
react in 3 steps when the room is
active. These settings can be set to a
timeframe (hours, minutes, seconds,
or never)
A. First the SCREEN TIMEOUT IN
will send the display to a logo
screen
B. Next the BACKLIGHT DIM IN
will dim the logo screen
C. Finally the screen will go dark
with BACKLIGHT OFF IN
2. BACKLIGHT INTENSITY adjust the
overall intensity of the screen during
normal use
3. PROXIMITY SENSITIVITY adjust the
sensitivity of the station IR sensor
that awakes the station when the
screen is dark
4. SHOW buttons display control
buttons on the home screen for 3rd
party system control. These are not
currently supported
5. START ON "LIGHTS ON" PAGE will
make this page the primary screen
for turning lights on in the space
6. SHOW LOGO PAGE will display
if the screen is setup to timeout.
DEFAULTS sets all screen behavior
settings to factory defaults
Acuity Brands | One Lithonia Way Conyers, GA 30012 Phone: 800.535.2465 www.acuitycontrols.com © 2014-2015 Acuity Brands Lighting, Inc. All rights reserved. 08/17/15
13 of 27
