BEA BEAMBOX User Manual

DESCRIPTION
1
2
3
4
TECHNICAL SPECIFICATIONS
Technology:
Detection mode:
Detection zone:
(mounting height 6.5 ft; tilt angle 20°)
Reaction time:
Supply voltage:
Mains frequency:
Power consumption:
Output:
Max. contact voltage:
Max. contact current:
Max. switching power:
Monitoring input:
Input voltage:
Input current:
Connection on sensor side:
Hold time:
LED-signal:
Mounting height:
Degree of protection:
Temperature range:
Dimensions:
Tilt angles:
Cable length:
Material:
Weight:
75.5791.01 BEAMBOX 20140326
A
B
1. mounting bracket
2. cable
3. adjustment pin
4. push buttons A, B
active infrared
motion and presence
3.3 ft (W) x 3.9 ft (D)
15 independent IR-spots with a diameter of typ. 0.43 in
< 100 ms
12V - 30V AC ±10%; 12V - 45V DC ±10%
50 - 60 Hz
< 3 W (VA)
relay (free of potential change-over contact)
42 V AC - 60 V DC
1A (resistive)
30 W (DC) / 60 VA (AC)
optocoupled, free of potential
10V-24V DC
<10mA (@ 24V)
unpluggable integrated 7-pin connector
0.5 s to 9 s (adjustable)
red and green
max. 8.2 ft (flush-mounting)
IP41
-13 °F to + 136 °F (operating); -22 °F to + 140 °F (storage)
5.5 in (W) x 1.5 in (H) x 2.2 in (D)
0° to 20° vertical in steps of 5°
8 ft
Polycarbonate
3.5 oz
Specifications are subject to changes without prior notice - Measured in specific conditions.
BEAMBOX
Universal activation and presence sensor
User's Guide
5. detection zone tilt angle adjustment
6. front face
7. LED
8. RC receiver
5
6
7
8
Page 1 of 4
