DK-12
PRESENCE SENSOR
INSTRUCTION MANUAL FOR INDUSTRIAL APPLICATIONS
We can be reached from anywhere in the world:
US & Canada Toll Free 800-523-2462 (EST)
US & Canada Toll Free 877-232-9378 (PST)
Mexico Toll Free 001-800-711-1398
Latin America 412-782-5191
Email: sales@beainc.com
B.E.A., Inc. • 300 South Main Street • Pittsburgh PA 15215 • USA
Tel. 412-782-5150 • Fax 412-782-5154
75.1034 V1 Feb 2001

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DK-12 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for BEA DK-12

Summary of Contents for BEA DK-12

  • Page 1 DK-12 PRESENCE SENSOR INSTRUCTION MANUAL FOR INDUSTRIAL APPLICATIONS We can be reached from anywhere in the world: US & Canada Toll Free 800-523-2462 (EST) US & Canada Toll Free 877-232-9378 (PST) Mexico Toll Free 001-800-711-1398 Latin America 412-782-5191 Email: sales@beainc.com B.E.A., Inc.
  • Page 2 For smaller openings, the DK-12's pattern can be reduced by shutting off one or two of the four zones available, making it ideal for narrow doors or areas. When a door opening is 8 feet or less, one DK-12 should be used and when a door opening is greater than 8 feet, two DK-12 s’s should be used.

  • Page 3: Installing The Sensor

    2. Select a mounting position for the sensor. For door opening narrower than 8 feet, the sensor should be centered in relation to the door opening. If the DK-12 is used on any door with an opening greater than 8’, it is highly recommended to use more than one DK-12. Pattern selections will depend on the door and the mounting position.

  • Page 4: Wall Mount

    IMPORTANT NOTE: BEA strongly recommends the use of the WHU (weather protection hood) on any DK-12 that is installed outside and is exposed to the elements. The circuit board of the DK-12 is not waterproof; therefore, it is susceptible to water damage. Any DK-12 that is returned due to water damage will be considered out of warranty.
  • Page 5 To adjust the DK-12, stand to the left of the detector, pointing the remote towards the left side of the detector (without end cap installed) at a distance less than 6 feet from the DK-12. Each adjustment requires pushing two buttons on the remote;...
  • Page 6 Please note: When two DK-12’s are installed on the same door, place the end cap on one DK-12 and program the open DK-12. Once the first DK-12 is programmed, install its end cap and remove the second DK-12’s end cap and repeat the programming procedure.
  • Page 7 Function Actions Factory LED Status Buttons Settings SENSITIVITY – Press this key followed by the number LED flashes button (0-9) of the sensitivity desired. This setting can be Door closed = 8 selected for both states of the door, DOOR OPEN or DOOR CLOSED Door open = 7 9 –...

  • Page 8: Pattern Selection

    This time delay begins counting down once a change in the detection zone occurs. If the object is removed from the zone before the time delay has expired the DK-12 will not save it as part of its memory.
  • Page 9 • Relay is in the fixed OFF position. Select a relay output of active or passive. DK-12 LED flashes very fast • DK-12 has only received the first half of a two button remote input. Enter second half of code or wait 20 seconds for LED to go out.
