Disclaimer
KOMFORT
english
Our commitment: excellence
S I G N A T U R E

Advertisement

loading
Need help?

Need help?

Do you have a question about the Komfort 1000 and is the answer not in the manual?

Questions and answers

Related Manuals for Astralpool Komfort 1000

Summary of Contents for Astralpool Komfort 1000

  • Page 1 Disclaimer KOMFORT english Our commitment: excellence S I G N A T U R E...
  • Page 2 1. Product data sheet and technical characteristics 1.1. Table of technical characteristics 1.2. Packaging 1.3. General dimensions (mm) 1.3.1. Komfort 1000 ladder 1.3.2. Komfort 650 ladder 1.3.3. Komfort Split ladder 2. Quality control checklist 3. Available certificates about the product, the production process and the systems implemented in the company 4.

  • Page 3: Technical Characteristics

    S I G N A T U R E 1. Product data sheet and technical characteristics 1.1. Table of technical characteristics Komfort ladders Comfortable and safe. All of the models incorporate the new Komfort steps designed by Astrapool. This system gives better security, resistance and a larger supporting surface which reduces effort and eases access into the swimming pool.
  • Page 4 S I G N A T U R E NR. OF STEPS KOMFORT SPlIT lADDER KOMFORT 1000 lADDER KOMFORT 650 lADDER 41324 42867 43269 41325 42868 43270 1.2. Packaging CODE PACKAGING DIMENSIONS (mm) VOluME (m 41324 420x770x200 0,065 41325 310x1020x200...
  • Page 5 S I G N A T U R E 1.3. General dimensions (mm) 1.3.1. KOMFORT 1000 lADDER 1000 8 Máx. Plastic non-skid steps Code Steps 42867 1710 42868 1960 1210...
  • Page 6 S I G N A T U R E 1.3.2. KOMFORT 650 lADDER 8 Máx. Code Steps 43269 1710 Plastic 43270 1960 1210 non-skid steps...
  • Page 7 S I G N A T U R E 1.3.3. KOMFORT SPlIT lADDER 8 Máx. Plastic non-skid steps Code Steps 41324 41325 1210...
  • Page 8 S I G N A T U R E 2. Quality control checklist QUALITY CONTROL CHECK LIST Quality certificate: Receipt of materials Receipt control: Tube and injected pieces Production process RANDOM CHECK Components Piece manufacture Quality control/ random check Assembly 100 % Finish control Packaging...
  • Page 9 S I G N A T U R E METALAST S.A.U CERTIFIES THAT: The KOMFORT ladders, manufactured by METALAST S.A.U. have been designed following the standards set by METALAST S.A.U. These include: - Control points and necessary tests to ensure the conformity of the product, in accordance with the requirements established by regulation ISO 9001:2000 in its points on: - Product production.
  • Page 10 S I G N A T U R E 3. Available certificates about the product, the production process and the systems implemented in the company...

  • Page 11: Warranty Certificate

    S I G N A T U R E 4. Warranty certificate 4.1. GENERAl PROVISIONS 4.1.1 In accordance with these provisions, the vendor guarantees the products that it sells against any manufacturing defect that affects its conformity or suitability for the use for which they have been designed.
  • Page 12 S I G N A T U R E 4.2.3 Total or partial modifications to the product without written authorisation from the manu- facturer. 4.2.4 Causes of force majeure, such as fire, frost, flooding, lightning or any other unforeseen catastrophe of any origin. 4.2.5 Wear and tear caused by normal use of the product. 4.2.6 Causes external to or beyond the scope of the product, such as storing the product outdoors or in enclosed places alongside chemical products where there may be adverse envi- ronmental conditions.
  • Page 13 S I G N A T U R E 5. Design standard and general characteristics KOMFORT ladder steps have an innovative design with an ergonomic support surface. Their ribbed interior offers sturdiness and their striking colour (Orange RAL-2010) makes it easy to see the steps in the water. The ladders are easy to assemble. The necessary tools are provided with the product. The handrails are made of AISI-316 stainless steel.
  • Page 14 S I G N A T U R E 6. Diagram Komfort 1000 ladder Codes: 42867 42868 POS. CODE DESCRIPTION ITEM 4401012901 FIXING SET FOR STEP 4401012902 SET DOUBLE STEP 4401012903 FIXING KEY 4401012904 STEP KIT 4401012905 LADDER END CAP...
  • Page 15 S I G N A T U R E Komfort 650 ladder Codes: 43269 43270 POS. CODE DESCRIPTION ITEM 4401012901 FIXING SET FOR STEP 4401012902 SET DOUBLE STEP 4401012903 FIXING KEY 4401012904 STEP KIT 4401012905 LADDER END CAP 4401010101 LADDER ANCHOR 4401010102 ESCUTCHEON AISI 304 43269R0200...
  • Page 16 S I G N A T U R E Komfort Split ladder Codes: 41324 41325 POS. CODE DESCRIPTION ITEM 4401012901 FIXING SET FOR STEP 4401012902 SET DOUBLE STEP 4401012903 FIXING KEY 4401012904 STEP KIT 4401012905 LADDER END CAP 4401012906 FLANGE SET 01457R0200 SHORT 3 TREAD LADDER HANDRAIL AISI-316 01458R0200...
  • Page 17 S I G N A T U R E 7. Recommendations 7.1. PACKAGING Komfort ladders are delivered in an adequately packed and sealed cardboard box, on which the positioning and stacking logistics are indicated, so as to ensure correct storage of the ladder. Any failure to follow the instructions for storage could result in imperfections of the product.

  • Page 18: Installation

    S I G N A T U R E 7.4. INSTAllATION 7.4.1 COMPONENTS KOMFORT KOMFORT 650/1000 KOMFORT SPLIT 41324,42867, 43269 41325, 42868, 43270 KOMFORT 650/1000 KOMFORT SPLIT...
  • Page 19 S I G N A T U R E 7.4.2 ASSEMBlE EXTERIOR WEDGES 7.4.3 ASSEMBlE INTERIOR WEDGES 7.4.4 ASSEMBlE STEP BODy AND NuTS...
  • Page 20 S I G N A T U R E 7.4.5 SEQuENCE FOR ASSEMBlING STEPS (repeat steps 2 to 6 for each step) 4º 3º 2º 1º 7.4.6 TIGHTENING THE NuTS 7.4.7 ASSEMBly OF END CAPS AND ANCHORS Komfort 650/1000...
  • Page 21 S I G N A T U R E 180 mm...
  • Page 22 S I G N A T U R E Komfort SPlIT 387 mm 387 mm 180 mm...

  • Page 23: Maintenance

    S I G N A T U R E 7.5. MAINTENANCE AND DISMANTlING 7.5.1 MAINTENANCE: • Maintenance of the ladder should be done as often as the owner of the installation sees as appropriate, depending on the environmental conditions to which the ladder is subjected. Cleaning should be done with fresh water.
  • Page 24 S I G N A T U R E 7.5.2 DISMANTlING: Komfort 650/1000 1.- Dismantle the ladder from the anchors, loosening the screws. 2.- Clean with fresh water and dry. 3.- Store the ladder in a safe and humidity free place.
  • Page 25 S I G N A T U R E Komfort SPlIT 1.- Dismantle the ladder from the anchors, loosening the screws. 2.- Clean with fresh water and dry. 3.- Store the ladder in a safe and humidity free place.
  • Page 26 S I G N A T U R E 8. Table of chemical resistance PRODuCT CONCENTRATION TEMPERATuRE °C RESISTANCE Chlorine 0,5 - 2 gr/m3 27º Bromine 2 - 5 gr/m3 27º Salt electrolysis NA Cl + Concentration NA Cl 3500 - 27º (VCC 12-24 V) 5500 ppm Attention: Values valid for swimming pools with: Water pH: 7,2 - 7,6. Water hardness: 150 - 250 ppm...
  • Page 27 S I G N A T U R E 9. Table of errors 1. Stair is not stable 4. Rust on the steel hand-rails 2. The close nut does not turn 5. Small discharge of electric static 3. Deterioration of the step CAuSES SOluTIONS The anchor screw is not...
  • Page 28 S I G N A T U R E 10. Table “DO AND DON’T” DO NOT Check the packing and that the stac- Leave the box outside or in humid spa- king instructions have been fulfilled. ces. Transport and storage Always transport the ladder in its box Drag the ladder.
