The Model T32733 Skew Grinding Attachment
allows you to securely position skew chisels in
two additional V-holders at offset angles for preci-
sion sharpening. The left and right V-holders are
adjustable to allow you to maintain bevels at exact
skew angles.
To reduce your risk of
serious injury, read this
entire
using machine.
Inventory
Description
A. Skew Attachment ....................................... 1
B. Button Head Cap Screws M6-1 x 10 .......... 2
C. Hex Wrench 4mm ....................................... 1
A
C
Figure 1. Inventory.
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
manual
BEFORE
B
COPYRIGHT © OCTOBER, 2021 BY GRIZZLY INDUSTRIAL, INC.
NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
(FOR MODELS MFD. SINCE 10/21) #CS22113 PRINTED IN TAIWAN
MODEL T32733
SKEW GRINDING
ATTACHMENT FOR T32732
Assembly
The Model T32733 must be attached to the long
arm of the T32732 Bench Grinder Sharpening
System before use.
To assemble:
1.
Attach skew attachment to long arm with
(2) M6-1 x 10 button head cap screws (see
Figure 2).
Qty
Figure 2. Attaching skew attachment to long
INSTRUCTIONS
Wear safety glasses during
the entire setup process!
Long
Arm
x 2
Skew Attachment
arm.
V1.10.21
