ASSEMBLY INSTRUCTIONS
Quadro Loop
2P workstation
Sizes: 1200, 1400, 1600, 1800 mm
STEP 03
Adjust extendable beam (D) to desired
length using markers and secure beam
at that length using screws provided
All manuals and user guides at all-guides.com
www.jasonl.com.au
Need help!
Call us on
1300 527 665
2000
1900
1800
1700
1600
1500
1400
1300
1200
50
50
Page 4 of 6
