ASSEMBLY INSTRUCTIONS
Quadro Loop
2P workstation
Sizes: 1200, 1400, 1600, 1800 mm
COMPONENTS
A
Table top x2
B
Leg Quadro x2
C
Leg Quadro Loop x2
D
Beam x2
E
Plastic bracket x8
SCREWS
F
M8x20MM CSK x4
G
M8x20MM Socket head x4
H
M6x20MM Socket head x8
I
M6x30MM Socket head x8
J
Allen key x2
All manuals and user guides at all-guides.com
www.jasonl.com.au
D
Need help!
Call us on
1300 527 665
A
B
E
F
G
H
C
I
