- Page 1 User and maintenance manual Anchorage bipod Model Eagle Nest 2 Read this manual Rel.01072019English carefully and keep it for future reference...
-
Page 2: Ferno Technical Support
(repairs) on all Ferno products in exclusivity. Any corrective action MUST necessarily be carried out by FERNO The information in this manual is the property of Ferno S.R.L. - personnel and the operations must be carried out using original Via Benedetto Zallone 26, 40066 Pieve di Cento (Bologna) Italy. -
Page 3: Table Of Contents
5.2 Leg positioning and assembly ______________ 10 5.3 Head assembly _________________________ 13 5.4 Loop anchorage device installation _________ 13 5.5 Eagle Nest 2 installation in the field _________ 14 6 - MAINTENANCE___________________________ 16 6.1 Routine and preventive maintenance ________ 16 6.2 Cleaning the device ______________________ 17... -
Page 4: Safety Information
Do Not Lubricate Unauthorised overhauls and repairs carried out by people not approved by Ferno S.r.l. will render all warranties null and void and Lubricate may compromise the safety of the device. Non-original spare parts and inadequate repairs may cause damage and/or injury. -
Page 5: Definitions
Eagle Nest 2 1.7 Definitions • TRANSPORT BAG: allows to carry the device once it has been disassembled and reconditioned • FOOT: leg supporting system equipped with spherical joint, smooth bearing surface (with 14-22-40 mm diameter drills according to the type of pole) to fix the device on uneven or slippery surfaces •... -
Page 6: 2- Operator Training And Skills
2- OPERATOR TRAINING AND SKILLS 2.1 Skills Important Operators who use the device must: Ferno S.r.l. is not liable for damages caused to users have adequate training knowledge to face the risks ● and / or third parties arising from improper use of the arising from preparation and use of the device. -
Page 7: The Device
3 - THE DEVICE EAGLE NEST 2 3.1 Description EAGLE NEST 2 is a device made of titanium falling into LIST OF COMPONENTS the category of fixed anchorage devices, tested according to standards EN 795:2012 type A and CEN/TS 16415:2013 •... -
Page 8: Components (Eagle Nest 2)
Eagle Nest 2 4 - COMPONENTS (EAGLE NEST 2) EAGLE NEST 2 FRONT VIEW Wind bracing rope Head Leg - fixed element Anchorage point Locking pin extractable element 5-point adjustment Foot © Ferno S.r.l. Rel.01072019... -
Page 9: General Specifications
Distance between A and B 70.9 in 1800 mm • The head must always be at the centre of Eagle Nest 2 **Each hole corresponds to a shift of 150 mm. • The anchorage device may only be used for fall-... -
Page 10: Eagle Nest 2 Configuration
Eagle Nest 2 5 - EAGLE NEST 2 CONFIGURATION 5.1 Initial setup Before using the Eagle Nest device: WARNING Wear suitable anchorage device against foreseeable ● risks. In a fall-arresting system, the harness EN 361 must be used in combination with an energy absorber EN Check good conditions of each element composing the ●... - Page 11 Eagle Nest 2 Lock the leg - extractable element - on the hole and insert the locking pin. Follow the red line to find the hole and insert the pin quickly to adjust the bipod height. Insert the leg - extractable element - inside the fixed element.
- Page 12 Eagle Nest 2 Insert the foot. Lock the two elements with the specially provided pin. Repeat the previous operation for both legs - extractable element. © Ferno S.r.l. Rel.01072019...
-
Page 13: Head Assembly
Eagle Nest 2 5.3 Head assembly Lock the head on the leg holes and insert the pin. Insert the head on the terminal end of the leg - fixed element and secure the elements with the specific pin. 5.4 Loop anchorage device installation Insert the loop anchorage device steel cable into one of the two black forks of the bipod head. -
Page 14: Eagle Nest 2 Installation In The Field
Eagle Nest 2 5.5 Eagle Nest 2 installation in the field 5.5.1 Foot installation Minimum and required fixing configuration • Check that the surface, where the bipod is installed, is as flat as possible. Install 12-mm diameter expansion bolt Each foot of the bipod must be fixed with at least 4 •... - Page 15 Eagle Nest 2 • Make sure that the wind bracing rope, after installation and positioning of the device, is always positioned centrally to the poles (see image on the side). 5.5.3 Distance between poles • Install the feet of the bipod poles at a distance of more than 1.8 m...
-
Page 16: Maintenance
1. ROUTINE maintenance: must be performed by the Presence of dents or signs of perforation, even ● minimum, in the leg tubes Manufacturer at intervals not exceeding 12 months. Ferno engineers will issue a conformity certificate of the medical Presence of deformations which could alter the ●... -
Page 17: Cleaning The Device
You are thus invited After disinfection / cleaning, ensure that the device to be wary of those who present themselves as Ferno's and its components are completely dry before use. authorised technician. We suggest you to directly contact our SOS service using the reference contacts. -
Page 18: Technical Support
TRANSPORT: Protect the product from the risks mentioned above. The legal guarantee is applicable to all products sold by Ferno S.R.L. and being so defined according to the law, it has to be fully referred to: - Private Customers, namely subjects purchasing for purposes unrelated to their professional or business activity;... - Page 19 Terms and Conditions”. - The warranty does not cover consumables or parts subject - Ferno S.R.L. cannot, in any event, be held liable for direct to wear and tear due to normal use of the product, all parts or indirect damage due to usage that is non-compliant with...
-
Page 20: Main Rules For Usage Of The Eagle Nest And Of Fall-Arresting Anchorage Device
Eagle Nest 2 8 - MAIN RULES FOR USAGE OF THE EAGLE NEST AND OF FALL- ARRESTING ANCHORAGE DEVICE • The anchorage device must be used by duly trained and informed personnel. • The anchorage device cannot be used by personnel judged unfit further to a technical evaluation or by inadequately trained personnel. - Page 21 Eagle Nest 2 to be performed by the personnel in charge of this The use of the anchorage device is forbidden if the relevant control sheet has not been duly filled in. The device must be equipped with adequate instructions for use made by the Manufacturer, to be written in the language of the country where it has been sold.
-
Page 22: Inspection Sheet
Eagle Nest 2 The Eagle Nest has been submitted to a dynamic resistance and integrity test. This table shows the peak displacement values. These data allow the user to calculate the minimum air draught under their feet so that any impact is avoided on the way down. -
Page 23: Periodical Inspection Log
Eagle Nest 2 PERIODICAL INSPECTION LOG Date Periodical (P) or Defects noted, repairs carried out and any other Signature of Date of next extraordinary relevant information the person in inspection inspection (S) charge © Ferno S.r.l. Rel.01072019... -
Page 24: Training Record
Eagle Nest 2 TRAINING RECORD Date Instructor Name Training Type TRAINING RECORD Date Instructor Name Training Type © Ferno S.r.l. Rel.01072019... - Page 25 Eagle Nest 2 TRAINING RECORD Date Instructor Name Training Type TRAINING RECORD Date Instructor Name Training Type © Ferno S.r.l. Rel.01072019...
- Page 26 Eagle Nest 2 Product User and Maintenance Manual, required to operate the product safely, maintain its efficiency and reliability, and comply with the terms of the warranty. Rel.01072019 English Ferno S.r.l. Via Benedetto Zallone 26 40066 - Pieve di Cento (BO) - ITALY Telephone (toll-free for Italy) 800.501.711...
