- Page 1 Total Edge Management System INSPECTION MANUAL Version 1.1:2012 Document ID: 00131-AU-V1.2:2012 Published: May 2012 Certified to CE 0123; EN795 B in 3 & 4 leg configurations for maximum 2 persons...
-
Page 2: Table Of Contents
INSPECTION MANUAL VERSION: 1.2:2012 contents CE Compliance Information Service & Repairs Glossary INTRODUCTION ARACHNIPOD COMPONENTS & PART NUMBERS SAFETY INFORMATION REPAIRS CARE, MAINTENANCE & STORAGE LIFE CYCLE PRODUCT UPDATE ARACHNIPOD DISASSEMBLY LEG INSPECTION Extend and Inspection of Legs and Pins... -
Page 3: Ce Compliance Information
INSPECTION MANUAL VERSION: 1.2:2012 CE COMPLIANCE INfORMATION The Arachnipod is certified to CE 0123; EN795B in the following configurations: CE Certifying Organisation: • Tripod TÜV Süd Product Servicer GmbH • Quadpod Ridlerstr. 65 • Quadpod with bridge *(Stabilisation rigging required for this configuration D-80339 MÜNCHEN... -
Page 4: Introduction
INTRODUCTION The Arachnipod must be inspected prior to and after each use, and should be inspected at least once a year by a competent person. Record the date of the inspection and the results in the equipment log. Each user should be trained as a competent person in equipment inspection. - Page 5 42-1019 Feet Rope & Rope Grab 42-1011 Arachnipod Bag 26-0007-0 Rigging Plate 90-0120 Spike Feet APOD -AKIT Arachnipod Full Accessory Kit APOD-BR2 2m Bridge Kit APOD-BR3 3m Bridge Kit APOD-BR4 4m Bridge Kit INCLUDED IN BRIDGE KITS: Bridge 2m Bridge...
-
Page 6: Safety Information
VERSION: 1.2:2012 SAfETy INfORMATION WARNING If the Arachnipod has been subjected to impact or a fall, it should be The Arachnipod has been withdrawn from service immediately and must be tested and inspected by a engineered and tested using the competent person or the supplier of the System. -
Page 7: Arachnipod Disassembly
INSPECTION MANUAL VERSION: 1.2:2012 ARACHNIPOD DISASSEMBLy The disassembly and rigging process for the Arachnipod depends upon a number of factors including: • The type of Arachnipod kit • The configuration that is used. It is recommend that two or more people work together to disassemble the... -
Page 8: Inspecting The Heads Of Each Leg
Inspect the entire head for damage and indentations. Normal wear and tear is acceptable. However if obvious damage is noticeable, return to Ferno or an authorised agent for repair or replace the entire leg unit. Detent pins are used to... -
Page 9: Lazy Leg
180˚. Remove the Detent Pin and Stabilisation Attachment Point (D-shackle) from the head. If a Lazy Leg Adaptor is present, remove it. Refer to Arachnipod Operators’ Instructions regarding the Lazy Leg Adaptor application and use. Ensure the Lazy Leg Head can pivot 180˚ and that there is no binding up or stiffness in the pivot action. -
Page 10: Soft Ground Shoe
Soft Ground Shoe moves freely and stays in place once inserted on to the leg. Replacement/ additional Soft Ground shoes part number: ARACHNIPOD SOfT GROUND DISC #34-0032 HOLD DOWN STAKE INSPECTION (Fig 12) -
Page 11: Rigging Plate Inspection
If there is damage to the label, replace it. EQUIPMENT BRACKET LABEL #51-0064 CABLE, 150mm with rings #91-0004 ARACHNIPOD BALL LOCK Leg Pin #68-0054 REVERSE HEAD (Fig 16) Remove the Qik Link pin from the head and inspect the pin for any damage or deformation. -
Page 12: Bridge Beam & Trolley Inspection
Inspect the pulleys through which the trolley guide rope runs at each end of the Bridge. Ensure that pulleys move freely and do not bind up. If the bearings need replacing, return the unit to Ferno or an authorised Ferno repair agent. -
Page 13: Thorough Inspection Of Winch Wire Rope Cable
The cable should be replaced if there are six or more randomly broken wires in one lay, or three or more broken wires in one strand in one lay. If the cable needs replacing, return the complete winch to Ferno or a Ferno authorised repair agent. -
Page 14: Arachnipod Kit Records
VERSION: 1.2:2012 ARACHNIPOD KIT RECORDS Each Arachnipod Kit is assigned a Kit Number. This is one collective number recorded on Ferno Australia’s database, which references all individual serial numbers contained within the Arachnipod kit. A kit contains more than one item with a serial number. It can be just a tripod, a tripod plus accessories, a Bridge Kit, a full TEMS kit etc. -
Page 15: Regular & Annual Inspections
• The unit must be inspected before and after every use by the operator. • Additionally, the Arachnipod must be inspected by a competent, instructed, accredited person at least once a year to ensure the unit is fully functional. •... - Page 16 • The unit must be inspected before and after every use by the operator. • Additionally, the Arachnipod must be inspected by a competent, instructed, accredited person at least once a year to ensure the unit is fully functional. •...
- Page 17 • The unit must be inspected before and after every use by the operator. • Additionally, the Arachnipod must be inspected by a competent, instructed, accredited person at least once a year to ensure the unit is fully functional. •...
-
Page 18: Specifications: Working Load Limits (Wll)
The weight of a rescue load typically ranges from 200kg to 280kg (440lb to 617lb) depending on a number of factors. The Arachnipod offers many configurations that match or exceed the 280kg load with only a few exceptions. The table below outlines the safe working loads of the Arachnipod in various configurations.
